Displaying Interfaces

Top-Level Menu
system
ethernet
interface
fddi
display
route
atm
define
arp
bridge
modify
atmArpServer
remove
ip
multicast
addPvc
ipx udpHelper
removePvc
appletalk routing
snmp
icmpRouterDiscovery
analyzer ospf
script
rip
logout ping
statistics
IP forwarding is enabled, RIP is active, ICMP discovery is disabled.
Index
Index
LIS interface information — When you select
type, the system prompts you for LIS interface information. The
information you enter depends on whether you define permanent
virtual circuits (PVCs), switched virtual circuits (SVCs), or both on the
LIS interface. See the CoreBuilder 2500 Operation Guide for more on
PVCs and SVCs.
If you define only SVCs, enter an ATM ARP server address. This
server maintains the IP-to-ATM address translation table. You can
enter the maximum number of SVCs allowed on this interface. The
minimum holding time determines the least amount of time that
an SVC connection remains open. The inactivity timer determines
how long the connection can remain open with no activity after
the minimum holding time has expired. You also need to enter the
ATM port number for this interface.
If you define only PVCs on the interface, you need to enter only
the PVC numbers and the ATM port number. The other prompts do
not appear because you ned not enter an ATM ARP server address.
If you define SVCs and PVCs, enter all LIS interface information.
You can display a table that shows all of the IP interfaces that are
configured for the system, including their parameter settings. The IP
interface display screen includes the values that you select when you
define the interface.
1 From the top level of the Administration Console, enter:
ip interface display
2 Enter the interface index numbers or
Select interface index(es) (1-2|all): all
Example:
Type IP address
1 VLAN 158.101.1.1
Type IP address
2 LIS 158.101.112.1
atmArpServer
47-0000-00-000000-0000-0000-00cc-080001200054-ff
maxSvcCount
0
.
all
Subnet mask
255.255.255.0
Subnet mask
255.255.255.0
inactivityTime
1200
Administering Interfaces
as the interface
lis
State VLAN index
Down
State Port
Up 1
minHoldingTime
60
10-3
