Introduction To The Switch 4210 Family Pwr Switches - 3Com 4210 Getting Started

8 C 1: P
HAPTER RODUCT
Introduction to the
Switch 4210 Family
PWR Switches
Switch 4210 9-port PWR
I
NTRODUCTION
Table 2 Non Power over Ethernet models
Model Power supply
Switch 4210 AC input
9-port
Switch 4210 AC input
18-port
Switch 4210 AC input
26-port
Switch 4210 AC input
52-port (not
shown)
Front panel
Each Switch 4210 9-port PWR unit provides eight 10/100Base-TX autosensing
Ethernet ports, one 10/100/1000Base-T Ethernet port, one 100/1000Base SFP
ports, and one Console port. The SFP port and the 10/100/1000BASE-T Ethernet
port form a Combo port. You can use either the SFP port or the
10/100/1000BASE-T Ethernet port at one time.
Figure 3 shows the front panel of a Switch 4210 9-port PWR.
Figure 3 Front panel of a Switch 4210 9-port PWR
1
5
(1) 10/100Base-TX autosensing Ethernet port status LED
(2) Link LED for Combo port
(4) Power LED (PWR)
(6) D/S LED
(8) Active LED for Combo port
Number of
10/100 Mbps
ports
8
16
24
48
( 1 ) ( 2 )
4
8
( 8 )
Number of 1000 Mbps
uplink ports
One Combo port
Two Combo ports
Two Combo ports
Two 10/100/100 ports
Two SFP ports
( 3 ) ( 4 )
( 7 ) ( 6 ) ( 5 )
(3) Console port
(5) A/L LED
(7) Mode button
Number of
Console
ports
1
1
1
1
