Summary of Contents for Endress+Hauser Waterpilot FMX21
- Page 1 Products Solutions Services XA02555P-A/00/EN/ 01.21 71533911 2021-07-05 Safety Instructions Waterpilot FMX21 II 2 G Ex ia IIC T6...T4 Gb...
-
Page 3: Table Of Contents
Waterpilot FMX21 XA02555P-A Waterpilot FMX21 Table of contents Associated documentation ......... 4 Supplementary documentation . -
Page 4: Associated Documentation
BA00380P/00 Supplementary Explosion-protection brochure: CP00021Z/11 documentation The Explosion-protection brochure is available: • In the download area of the Endress+Hauser website: www.endress.com -> Downloads -> Brochures and Catalogs -> Text Search: CP00021Z • On the CD for devices with CD-based documentation Manufacturer's UK Declaration of Conformity... - Page 5 Waterpilot FMX21 XA02555P-A Structure of the extended order code FMX21 – ************* A*B*C*D*E*F*G*.. (Device (Basic (Optional type) specifications) specifications) * = Placeholder At this position, an option (number or letter) selected from the specification is displayed instead of the placeholders.
-
Page 6: Safety Instructions: General
XA02555P-A Waterpilot FMX21 Basic specifications Position 1, 2 (Approval) Selected option Description FMX21 UK Ex II 2G Ex ia IIC T4...T6 Gb Position 4 (Probe Tube) Selected option Description FMX21 316L, d=22mm/0.87in 316L, d=42mm/1.66in, flush mount PPS/Polyolefin>316L, d=29mm/1.15in, application salt-water Optional specifications No options specific to hazardous locations are available. -
Page 7: Safety Instructions: Installation
Waterpilot FMX21 XA02555P-A Safety instructions: Installation (–) A0033644 1 Zone 1, Zone 2 Zone 1 Only for Basic specification, Position 4 = 1, 2 • When the devices are connected to certified intrinsically safe circuits of Category Ex ib, the type of protection changes to Ex ib. -
Page 8: Temperature Tables
XA02555P-A Waterpilot FMX21 Terminal box A0033645 2 Functional earth terminals Isolation plates Signal terminals • Continuous service temperature of the connecting cable: ≥ +85 °C. • Do not remove or move terminal blocks, isolation plates or fastening elements. • Do not build in additional components. -
Page 9: Connection Data
Waterpilot FMX21 XA02555P-A Connection data Electrical data ≤ 30 V ≤ 133 mA ≤ 1 W Sensor: ≤ 10.3 nF, L Cable: ≤ 180 pF/m, L ≤ 1 µH/m Endress+Hauser... - Page 12 *71533911* 71533911 www.addresses.endress.com...
