Before operating the unit, please read this Instruction Book thoroughly, and retain it for future reference. Use only approved battery packs. Otherwise, there is a danger of overheating, fire or explosion. Samsung is not responsible for problems occurring due to using unapproved batteries. DVD+ReWritable DVD+R DL...
ENGLISH Contents Contents Notes and Safety Instructions ... 6 Notes regarding the Rotation of the LCD Screen ...6 Notes regarding the LCD Screen, Viewfinder, Lens ...6 Notes regarding Disc Cleaning and Handling ...7 Notes regarding DVD Camcorder ...8 Notices regarding Copyright (VP-DC171i/DC171Bi/DC171Wi/ DC173i/DC175Wi/DC575Wi only) ...8 Servicing &...
Page 3
Contents Initial Setting : System Menu Setting ... 30 Setting the Clock (Clock Set) ...30 Setting the Wireless Remote Control Acceptance (Remote) . (VP-DC172W/DC173(i)/DC175WB/DC175W(i)/DC575WB/ DC575Wi only) ...31 Setting the Beep Sound (Beep Sound) ...32 Setting the Shutter Sound (Shutter Sound) ...33 (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) ...33 Selecting the OSD Language (Language) ...34...
Page 4
ENGLISH Contents DVD Camcorder: Thumbnail index and Playlist 63 What is the Thumbnail Index? ...63 What’s a Playlist? DVD-RW(VR mode) ... 63 DVD Camcorder ... 64 Playing Title Scenes DVD-RW/+RW/-R/+R DL ... 64 Adjusting the Volume DVD-RW/+RW/-R/+R DL ... 64 Various Functions while in Player Mode Playback/Still ...65 Skip Playback (Forward/Reverse) ...65...
Page 5
Contents Memory Card Functions ...89 Inserting a Memory Card ...89 Ejecting a Memory Card ...89 Structure of Folders and Files on the Memory Card ...90 Image Format ...90 Selecting the Photo Quality (Photo Quality) ...91 Select the Photo Quality ...91 Number of Images that can be stored on a Memory Card Setting the Photo Size (Photo Size) (VP-DC575WB/DC575Wi only) ...92...
ENGLISH Notes and Safety Instructions Notes regarding the Rotation of the LCD Screen Please rotate the LCD Screen carefully as illustrated. Over-rotation may cause damage to the inside of the hinge that connects the LCD Screen to the DVD Camcorder. 1.
Notes and Safety Instructions Notes regarding Disc Cleaning and Handling Take care not to touch the recording side (the rainbow coloured side) of the disc with your fingers. Discs contaminated by fingerprints or foreign substances may not play properly. ...
Television programmes, video tapes, DVD titles, films, and other programme materials may be copyrighted. Unauthorized copying of copyrighted material may be against the law. All the trade names and registered trademarks mentioned in this manual or other documentation provided with your Samsung product are trademarks or registered trademarks of their respective holders.
Getting to Know Your DVD Camcorder Features DVD Disc Camcorder DVD-VIDEO recording with 8cm DVD-RW/+RW/DVD- R/+R DL(Dual Layer) discs. High Power Zoom Lens Offers you High Power Zoom Lens with 34x (VP- DC171(i)/DC171Bi/DC171W(i)/DC171WB/DC172W/ DC173(i)/DC175WB/DC175W(i) only) Zoom Lens, 26x Zoom Lens (VP-DC575WB/DC575Wi only).
ENGLISH Getting to Know Your DVD Camcorder Learning available Discs and Their Features This DVD Camcorder can record or play back by using only the 8cm DVD-R/+R DL/-RW/+RW disc (not supplied). Please check whether your disc is proper for use. Which discs are available? DVD-R DVD+ReWritable...
Page 11
Getting to Know Your DVD Camcorder Which discs recorded on the DVD Camcorder can be played in DVD players/recorders/drives? Discs must be finalised before they can be played on common DVD player/recorders. Finalising is a process required to make the DVD discs you recorded playable on common DVD players. DVD-R DVD+ReWritable DVD+R DL...
ENGLISH Getting to Know Your DVD Camcorder How to use the DVD Camcorder easily You can record any desired image and edit and playback the disc on a DVD Camcorder, most common DVD players, and PCs after finalising the disc. Recording ...
12. Carrying Case Notes The contents can vary depending on the sales region. Parts and accessories are available at your local Samsung dealer. 1. Lithium Ion Battery Pack 2. AC Power Adapter (SB-LSM80) (AA-E9 TYPE) 4. Instruction Book 5.
ENGLISH Getting to Know Your DVD Camcorder Right & Top View 1. PHOTO Button (VP-DC173(i)/DC175WB/DC175W(i)/ DC575WB/DC575Wi only) page 94 2. Focus Adjustment Knob page 39 3. Viewfinder 4. Record Start/Stop Button page 44 5. Power Switch (ON/OFF/ (Camera)/ 6. USB Jack (VP-DC173(i)/DC175WB/DC175W(i)/ DC575WB/DC575Wi only) 7.
Preparation Using the Hand Strap & Lens Cover It is very important to ensure that the Hand Strap has been correctly adjusted before you begin your recording. The Hand Strap enables you to: Hold the DVD Camcorder in a stable, comfortable position. Press the [Zoom] lever and [Record Start/Stop] button without having to change the position of your hand.
ENGLISH Preparation Lithium Battery Installation Lithium Battery Installation for the Internal Clock 1. Remove the Battery Pack from the rear of the DVD Camcorder. 2. Open the Lithium Battery Cover on the rear of the DVD Camcorder. 3. Position the Lithium Battery in the Lithium Battery Holder, with the positive (+) terminal face up.
Preparation Using the Lithium Ion Battery Pack Use SB-LSM80 or SB-LSM160 (not supplied) Battery Pack only. The Battery Pack may be charged a little at the time of purchase. Charging the Lithium Ion Battery Pack 1. Turn the [Power] switch to [OFF]. 2.
ENGLISH Preparation Charging, Recording Times based on Battery Type If you close the LCD Screen, it switches off and the Viewfinder switches on automatically. The continuous recording times given in the table below are approximations. Actual recording time depends on usage. ...
Preparation Battery Level Display The battery level display indicates the amount of power remaining in the Battery Pack. a. Fully charged b. 20~40% used c. 40~80% used d. 80~95% used (red) e. Completely used (Blinking) (The DVD Camcorder will turn off soon, change the battery as soon as possible.) The Finalise/Format functions are not available at battery level ‘d’...
The remaining battery time may differ from the approximate continuous recording times given in the instructions. When replacing the battery pack, only use the same type as is supplied with this camcorder and is available from your SAMSUNG retailer. When the Battery reaches the end of its life, please contact your local dealer.
Preparation Connecting a Power Source There are two types of power source that can be connected to your DVD Camcorder. - The AC Power adapter: used for indoor recording. - The Battery Pack: used for outdoor recording. Using a Household Power Source Connect to a household power source to use the DVD Camcorder without having to worry about the battery power.
ENGLISH Preparation About the Operating Modes The operating modes are determined by the position of the [Power] and [Mode] (VP-DC173(i)/DC175WB/DC175W(i)/ DC575WB/DC575Wi only) switch. Set the Operation Mode by adjusting the [Power] and [Mode] (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) switches before operating any functions. ...
Preparation Using the Q.MENU Q.MENU is used to access DVD Camcorder functions by using the [Q.MENU] button. Q.MENU provides easier access to frequently used menus without using the [MENU] button. Functions available using the Q.MENU are as below: Program AE White Balance <Camera Mode>...
ENGLISH Initial Setting : System Menu Setting Setting the Clock (Clock Set) Clock setup works in Camera Mode/Player Mode/M.Cam Mode/M.Player Mode. page 26 The date/time is automatically recorded onto a disc. Before recording, please set the date/time. 1. Set the [Mode] switch to [DISC] or [CARD]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2.
Initial Setting : System Menu Setting Setting the Wireless Remote Control Acceptance (Remote) (VP-DC172W/DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) The Remote function works in Camera Mode/Player Mode/M.Cam Mode/M.Player Mode. page 26 The Remote function allows you to enable or disable the remote control for use with the DVD Camcorder. 1.
ENGLISH Initial Setting : System Menu Setting Setting the Beep Sound (Beep Sound) The Beep Sound function works in Camera Mode/Player Mode/M.Cam Mode/M.Player Mode. page 26 You can turn the Beep Sound on or off, when on, each press of a button sounds a beep. 1.
Initial Setting : System Menu Setting Setting the Shutter Sound (Shutter Sound) (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) The Shutter Sound function works only in M.Cam Mode. page 26 You can turn the Shutter Sound on or off, when on, with each press of the [PHOTO] button the Shutter will sound. 1.
ENGLISH Initial Setting : System Menu Setting Selecting the OSD Language (Language) The Language function works in Camera Mode/Player Mode/M.Cam Mode/M.Player Mode. page 26 You can select the desired language to display the menu screen and the messages. 1.
Initial Setting : System Menu Setting Viewing the Demonstration (Demonstration) The Demonstration function may only be used in the Camera Mode with no disc inserted in the unit. page 26 Before you begin: Make sure that there is no disc inserted in the DVD Camcorder. page 41 ...
ENGLISH Initial Setting : Display Menu Setting Adjusting the LCD Screen (LCD Bright/LCD Colour) Adjusting the LCD Screen works in Camera Mode/Player Mode/M.Cam Mode/M.Player Mode. page 26 Your DVD Camcorder is equipped with a 2.5 inch (VP-DC171(i)/DC171Bi/DC173(i) only) / 2.7 inch wide (VP-DC171W(i)/ DC171WB/DC172W/DC175WB/DC175W(i)/DC575WB/DC575Wi only) colour Liquid Crystal Display (LCD) Screen, which enables you to view what you are recording or playing back directly.
Initial Setting : Display Menu Setting Displaying the Date/Time (Date/Time) The Date/Time function works in Camera Mode/Player Mode/M.Cam Mode/M.Player Mode. page 26 The date and time are automatically recorded on a special data area of the disc. 1. Set the [Mode] switch to [DISC] or [CARD]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2.
ENGLISH Initial Setting : Display Menu Setting Setting the TV Display (TV Display) The TV Display function works in Camera Mode/Player Mode/M.Cam Mode/M.Player Mode. page 26 You can select the output path of the OSD (On Screen Display). This allows you to set the OSD for viewing on the viewfinder, LCD screen or an external TV.
DVD Camcorder: Before Recording Using the Viewfinder You can view pictures through the viewfinder to avoid running down the battery, or to see correct images when the picture on the LCD Screen is poor. In the [ (Camera)] or [ (Player)] mode, the Viewfinder will work when the LCD Screen is closed.
ENGLISH DVD Camcorder: Before Recording Various Recording Techniques In some situations, different recording techniques may be required for more dramatic results. 1. General recording. 2. Downward recording. Making a recording with a top view of the LCD Screen. 3. Upward recording. Making a recording viewing the LCD Screen from below.
DVD Camcorder: Before Recording Inserting and Removing a Disc When inserting a disc or closing the disc cover, do not apply excessive force. It may cause a malfunction. You cannot open the disc cover while loading. Set the [Mode] switch to [DISC] (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) and the [Power] switch to [ the LCD Screen.
Page 42
ENGLISH DVD Camcorder: Before Recording When using a New Disc: Formatting a new Disc Formatting may be required if a new disc is inserted. Recognition of the disc will start. For a DVD-R/+R DL disc: Formatting will automatically begin. For a DVD-RW disc: You are prompted with the <Disc is not formatted. Format?> message. Video (Video Mode) : If the disc has been fi...
DVD Camcorder: Before Recording Selecting the Record Mode (Rec Mode) The Record Mode function works in both Camera Mode and Player Mode. page 26 This DVD Camcorder can film in the XP (extra play), the SP (standard play) and the LP (long play) modes. The SP mode is set as the factory default.
ENGLISH DVD Camcorder: Basic Recording Making your First Recording 1. Connect a power source to the DVD Camcorder. pages 21, 25 (A Battery Pack or a AC Power adapter) Insert a disc. page 41 2. Remove the Lens Cover. 3.
DVD Camcorder: Basic Recording Recording with Ease for Beginners (EASY.Q Mode) The EASY.Q function works only in Camera Mode. page 26 The EASY.Q function allows a beginner to easily make good recordings. 1. Set the [Mode] switch to [DISC]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2.
ENGLISH DVD Camcorder: Basic Recording Zooming In and Out The Zoom function works in both Camera Mode and M.Cam Mode. page 26 Zooming is a recording technique that lets you change the size of the subject in a scene. ...
DVD Camcorder: Basic Recording Using the Fade In and Out (FADE) The Fade function works only in Camera Mode. page 26 You can give your recording a professional look by using special effects such as fade in at the beginning of a sequence or fade out at the end of a sequence.
ENGLISH DVD Camcorder: Basic Recording Using Back Light Compensation Mode (BLC) BLC works in both Camera Mode and M.Cam Mode. page 26 Back lighting exists when the subject is darker than the background: - The subject is in front of a window. - The person to be recorded is wearing white or shiny clothes and is placed against a bright background;...
DVD Camcorder: Basic Recording Using the Colour Nite Colour Nite function works only in Camera Mode. page 26 You can make the subject recorded appear to be in slow motion by controlling the shutter speed, or a brighter image in dark places without a compromise in colours. ...
ENGLISH DVD Camcorder: Basic Recording Using the LIGHT (VP-DC175WB/DC175W(i)/DC575WB/DC575Wi only) The LIGHT function works only in Camera Mode. page 26 The LIGHT enables you to record a subject in dark places. The LIGHT can be used with Colour Nite function only. ...
DVD Camcorder: Advanced Recording Cutting Off Wind Noise (Wind Cut) The Wind Cut function works only in Camera Mode. page 26 Use the Wind Cut when recording in windy places such as the beach or near buildings. The Wind Cut function minimizes wind noise or other noise while recording. - When the Wind Cut is on, some low pitched tones are eliminated along with the sound of the wind.
ENGLISH DVD Camcorder: Advanced Recording Setting the Shutter Speed & Exposure (Shutter/Exposure) The Shutter Speed function works only in Camera Mode. page 26 The Shutter Speed refers to to the amount of time it takes the shutter to open and close. The faster the speed is set, the less light enters the lens.
DVD Camcorder: Advanced Recording Auto Focus / Manual Focus The Auto Focus/Manual Focus function works in both Camera Mode and M.Cam Mode. page 26 In most situations, it is better to use the automatic focus feature, as it enables you to concentrate on the creative side of your recording.
ENGLISH DVD Camcorder: Advanced Recording Programmed Automatic Exposure Modes (Program AE) The Program AE function works only in Camera Mode. page 26 The Program AE mode allows you to adjust shutter speeds and apertures to suit different recording conditions. ...
DVD Camcorder: Advanced Recording Setting the Program AE 1. Set the [Mode] switch to [DISC]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2. Set the [Power] switch to [ (Camera)]. 3. Press the [MENU] button. The menu list will appear. 4. Move the [Joystick] up or down to select <Camera>, then press the [Joystick]. 5.
ENGLISH DVD Camcorder: Advanced Recording Setting the White Balance (White Balance) The White Balance function works in both Camera Mode and M.Cam Mode. page 26 The White Balance is a recording function that preserves the unique image colour of the subject in any recording condition. ...
DVD Camcorder: Advanced Recording Setting the Custom White Balance You can adjust the white balance as you wish based on the recording environment. 1. Set the [Mode] switch to [DISC] or [CARD]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2. Set the [Power] switch to [ (Camera)].
ENGLISH DVD Camcorder: Advanced Recording Applying Digital Effects (Digital Effect) The Digital Effect function works only in Camera Mode. page 26 The Digital Effects enable you to give a creative look to your recording. Select the appropriate Digital Effect for the type of picture that you wish to record and the effect you wish to create. ...
DVD Camcorder: Advanced Recording Selecting the Digital Effects 1. Set the [Mode] switch to [DISC]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2. Set the [Power] switch to [ (Camera)]. 3. Press the [MENU] button. The menu list will appear. 4. Move the [Joystick] up or down to select <Camera>, then press the [Joystick]. 5.
ENGLISH DVD Camcorder: Advanced Recording Setting the 16:9 Wide mode (16:9 Wide) The 16:9 Wide function works only in Camera Mode. page 26 Select to record a picture to be played back on a 16:9 Wide TV. 16:9 Wide is the default setting for models VP-DC171W(i)/DC171WB/DC172W/DC175WB/DC175W(i)/DC575WB/ DC575Wi.
DVD Camcorder: Advanced Recording Setting the Digital Image Stabilizer (DIS) The DIS function works only in Camera Mode. page 26 DIS (Digital Image Stabilizer) is a function that compensates for any shaking or hand movement while holding the DVD Camcorder (within reasonable limits).
ENGLISH DVD Camcorder: Advanced Recording Zooming In and Out with Digital Zoom (Digital Zoom) The Digital Zoom works only in Camera Mode. page 26 Zooming more than 34x (VP-DC171(i)/DC171Bi/DC171W(i)/DC171WB/DC172W/DC173(i)/DC175WB/DC175W(i) only) or 26x (VP-DC575WB/DC575Wi only) is achieved digitally, up to 1200x when combined with optical zoom. ...
DVD Camcorder: Thumbnail index and Playlist What is the Thumbnail Index? The thumbnail index displays multiple titles scenes that have been recorded. A title scene is created between the points where you start and stop a recording. Once deleted, you cannot recover the title scene again. What’s a Playlist? DVD-RW(VR mode) ...
ENGLISH DVD Camcorder Playing Title Scenes DVD-RW/+RW/-R/+R DL The recorded title scenes are displayed as a thumbnail index (multiple images) on the LCD Screen. You can fi nd the desired scene quickly using this convenient index. If the TFT LCD screen is closed, you can view the recording through the viewfi nder. Use the Playback related buttons on the DVD Camcorder or on the remote control.
DVD Camcorder Various Functions while in Player Mode These functions work only in Player Mode. page 26 Play, Still, Stop, Fast Forward, Rewind, Forward Skip, and Reverse Skip functions are accessible using the remote control. (VP-DC172W/DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Slow playback is accessible only using the remote control. (VP-DC172W/DC173(i)/DC175WB/DC175W(i)/DC575WB/ DC575Wi only) Playback/Still ...
ENGLISH DVD Camcorder Picture Search (Forward/Reverse) Moving the [Joystick] left/right once while a disc is playing back will increase the play speed to approximately X2, and pressing twice plays at approx x16. When the number 1 appears on the OSD, it means X2 speed. When the number 2 appears on the OSD, it means X16 speed.
DVD Camcorder Deleting a Title Scene (Delete) Delete function works only in Player Mode. page 26 Individual or all title scenes can be deleted. 1. Set the [Mode] switch to [DISC]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2. Set the [Power] switch to [ (Player)].
ENGLISH DVD Camcorder Deleting a Section of a Title Scene (Partial Delete) Partial Delete function works only in Player Mode. page 26 A title scene can be partially deleted. The editing function only works on a DVD-RW (VR Mode). You should format the DVD-RW to VR Mode before recording.
DVD Camcorder: Playlist Creating a New Playlist (New Playlist) This function works only in Player Mode. page 26 The editing function only works on a DVD-RW (VR Mode). You should format the DVD-RW to VR Mode before recording. page 42 1.
ENGLISH DVD Camcorder: Playlist Playing the Playlist DVD-RW(VR mode) This function works only in Player Mode. page 26 The playlist scenes are displayed in the form of a thumbnail index on the LCD Screen. If the LCD Screen is closed, you can view the recording through the viewfi nder. Use the playback related buttons on the DVD Camcorder or on the remote control.
DVD Camcorder: Playlist Deleting a Playlist (Delete) DVD-RW(VR mode) Delete function works only in Player Mode. page 26 You can delete undesired playlists. The editing function only works on a DVD-RW (VR Mode). You should format the DVD-RW to VR Mode before recording. page 42 1.
ENGLISH DVD Camcorder: Playlist Adding Scenes to Playlist (Scene-Add) This function works only in Player Mode. page 26 You can add more scenes in an existing playlist. The editing function only works on a DVD-RW (VR Mode). You should format the DVD-RW to VR Mode before recording.
DVD Camcorder: Playlist Changing the Order of Scene Playing within a Playlist (Scene-Move) This function works only in Player Mode. page 26 You can change the order of scene playing within a playlist. The editing function only works on a DVD-RW (VR Mode). You should format the DVD-RW to VR Mode before recording.
ENGLISH DVD Camcorder: Playlist Deleting Scenes from Playlist (Scene-Delete) This function works only in Player Mode. page 26 You can delete the scenes inside the playlist. The editing function only works on a DVD-RW (VR Mode). You should format the DVD-RW to VR Mode before recording. page 42 1.
DVD Camcorder: Playlist Deleting a Section of a Playlist (Scene-Partial Delete) This function works only in Player Mode. page 26 A scene inside the playlist can be partially deleted. The editing function only works on a DVD-RW (VR Mode). You should format the DVD-RW to VR Mode before recording.
Page 76
ENGLISH DVD Camcorder: Playlist 8. Use the [Joystick] to search the start point of deletion. Whenever you press the [Joystick] right, it toggles between forward at speed 1 and 2. Whenever you press the [Joystick] left, it toggles between backward at speed 1 and 2. (When the number 1 appears on the OSD, it means X2 speed.
DVD Camcorder: Disc Manager Disc Information (Disc Info) DVD-RW/+RW/-R/+R DL This function works in both Camera Mode and Player Mode. page 26 It shows you the disc information as disc name, disc type, disc format, etc. 1. Set the [Mode] switch to [DISC]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2.
ENGLISH DVD Camcorder: Disc Manager Editing the Disc Name (Disc Info-Rename) This function works in both Camera Mode and Player Mode. page 26 You can specify a disc name. 1. Set the [Mode] switch to [DISC]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2.
DVD Camcorder: Disc Manager Formatting a Disc (Disc Format) This function works only in Camera Mode. page 26 You can format a recorded disc to be used again. By formatting, all existing data will be deleted. 1. Set the [Mode] switch to [DISC]. (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) 2.
ENGLISH DVD Camcorder: Disc Manager Finalising a Disc (Disc Finalise) This function works only in Camera Mode. page 26 To play the contents of a DVD-RW/-R/+R DL on other DVD Players/Recorders, you must finalise the disc. When finalising, there should be enough power in the batteries.
DVD Camcorder: Disc Manager Playing Back on a PC with DVD drive The DVD disc can be played on a PC with a DVD running media (DVD drive). 1. Turn on your PC. 2. Insert a finalised disc into the DVD drive of the PC. ...
ENGLISH DVD Camcorder: Disc Manager Unfinalising a Disc (Disc Unfinalise) This function works only in Camera Mode. page 26 If a DVD-RW disc had been finalised in the VR mode or Video mode, you can unfinalise the disc for further recording. ...
DVD Camcorder: Connection Setting the AV In/Out (VP-DC171i/DC171Bi/DC171Wi/DC175Wi/DC575Wi only) AV In/Out function works only in Player Mode. page 26 AV In/Out setting enables you to record signals from external sources. Also you can send your videos to external devices to record or playback. 1.
ENGLISH DVD Camcorder: Connection Viewing Recordings on TV The Playback function works only in Player Mode. page 26 Playing back on a TV Monitor To play back a disc, the television must be PAL compatible. page 115 We recommend that you use the AC Power adapter as the power source for the DVD Camcorder. Connecting to a TV that has Audio/Video Input Jacks 1.
Page 85
DVD Camcorder: Connection Connecting to a TV that has no Audio/Video Input Jacks You can connect your DVD Camcorder to a TV through a VCR. 1. Connect the DVD Camcorder to your VCR with the AV cable. The yellow jack: Video ...
ENGLISH DVD Camcorder: Connection Copying a Disc onto a Tape The copying function works only in Player Mode. page 26 Connect your DVD Camcorder to a VCR using the AV jack to dub the recording from a disc onto a VCR tape. ...
DVD Camcorder: Connection Using the Voice Plus The Voice Plus function works only in Player mode. page 26 This function enables you to narrate over a pre-recorded disc via the DVD Camcorder’s microphone. When you want to copy a DVD onto other AV devices (DVD Recorder, VCR), you can dub your voice sound incoming from the internal microphone of your DVD Camcorder to an AV device, instead of copying the audio signals on a pre-recorded disc.
ENGLISH DVD Camcorder: Connection Recording (Copying) a TV Programme or Video Tape onto a Disc (VP-DC171i/DC171Bi/DC171Wi/DC175Wi/DC575Wi only) The Recording (Copying) function works only in Player Mode. page 26 Connect your DVD Camcorder to a VCR or a TV using the AV jack to record a TV programme or copy a video tape to a disc. Set the AV In/Out before Recording (Copying).
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Using a Memory Card (Usable Memory Card) (not supplied) This DVD Camcorder can use SD memory cards and MMC (Multi Media Cards). Some cards are not compatible depending on the memory card manufacturer and memory card type.
The data stored on the Memory Card may be changed or lost as a result of misuse, static electricity, electric noise or repair. Save important images separately. Samsung is not responsible for data loss due to misuse. The DVD Camcorder supports 2GB SD/MMC and lower. SD/MMC above 2GB may not record or play properly.
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Selecting the Photo Quality (Photo Quality) Photo Quality function works in both Player Mode and M.Cam Mode. page 26 You can select the quality of a photo image to be recorded. Select the Photo Quality 1.
ENGLISH Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Setting the Photo Size (Photo Size) (VP-DC575WB/DC575Wi only) Photo Size function works only in M.Cam Mode. page 26 You can select the size of a photo image to be recorded. 1. Set the [Mode] switch to [CARD]. 2.
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Setting the File Number (File No.) File Number setting works only in M.Cam Mode. page 26 File Numbers are given to images in the order they were recorded when they are stored on the Memory Card. ...
ENGLISH Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Taking a Photo Image (JPEG) on a Memory Card You may take photo images while in M.Cam Mode and store the images on the Memory Card. page 26 You can take photo images using the remote control. (VP-DC172W/DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) ...
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Viewing Photo Images (JPEG) This function works only in M.Player Mode. page 26 You can playback and view photo images recorded on a Memory Card. 1. Set the [Mode] switch to [CARD]. 2.
ENGLISH Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Protection from accidental Erasure (Protect) The Protect function works only in M.Player Mode. page 26 You can protect important images from accidental erasure. If you execute format, all images including protected images will be erased. 1.
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Deleting Photo Images and Moving Images (Delete) The Delete function works only in M.Player Mode. page 26 You can erase the photo images and moving images recorded on the Memory Card. If you want to delete protected images, you must first deactivate the image protection. ...
ENGLISH Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Deleting All Images at Once Steps from 1 to 5 are the same as described in p.97 6. Move the [Joystick] up or down to select <Delete All>, then press the [Joystick]. The message <Delete all?> is displayed. 7.
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Formatting the Memory Card (Format) The Format function works only in M.Player Mode. page 26 You can use the Format functions to completely delete all images and options on the Memory Card, including protected images.
ENGLISH Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Recording Moving Images (MPEG) on a Memory Card You can record moving images while in M.Cam Mode. page 26 You can record moving images with audio on the Memory Card. The screen format of the moving image to be recorded is 720X576. Saving Moving Images onto a Memory Card 1.
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Playing the Moving Images (MPEG) on a Memory Card The moving images playback function works only in M.Player Mode. page 26 You can play the moving images stored on a Memory Card. Stereo audio is played back at the same time. ...
ENGLISH Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Recording Still images onto a Memory Card during DVD playback This function works only in Player Mode. page 26 If you press the [PHOTO] button during DVD disc playback, the disc stops and the image on the DVD disc is saved on the Memory Card.
Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Marking Images for Printing (Print Mark) The Print Mark function works only in M.Player Mode. page 26 This DVD Camcorder supports the DPOF (Digital Print Order Format) print format. You can automatically print images recorded on a Memory Card with a printer supporting DPOF. ...
ENGLISH Digital Still Camera Mode (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Removing the Print Mark To remove all Print Marks, select <All Off>. To remove an individual file’s Print Mark, select the file and set <This File> to <000>. Notes You can directly access the Print Mark function by using the [Q.MENU] button. page 27 ...
PictBridge™ (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Printing Your Pictures-Using PictBridge™ PictBridge function works only in M.Player Mode. page 26 By connecting the DVD Camcorder to printers with PictBridge support (sold separately), you can send images from the Memory Card directly to the printer with a few simple operations. ...
ENGLISH PictBridge™ (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Setting the Number of Prints 1. Move the [Joystick] up or down to select <Copies>, then press the [Joystick]. 2. Move the [Joystick] up or down to set the number of prints, then press the [Joystick]. Setting the Date/Time Imprint Option 3.
USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Using USB Interface Transferring a Digital Image through a USB Connection The DVD Camcorder supports both USB 1.1 and 2.0 standards. (Depends on the PC specification) You can transfer a recorded file in memory Card to a PC via a USB connection. ...
Page 108
ENGLISH USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Notes On a slower PC than recommended, movie playback may not be smooth or video editing may take a long time. On a slower PC than recommended, movie playback may skip frames or operate unexpectedly. ®...
USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Selecting the USB Device (USB Connect) The USB Connect function works only in M.Player Mode. page 26 Using the USB cable, you can connect your DVD Camcorder to a computer to copy your moving images and photo images from the Memory Card, or to a printer to print your images.
ENGLISH USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Installing DV Media PRO Program When you install the DV Media PRO software on your Windows computer, you can enjoy the following operations by connecting your DVD Camcorder to your computer via a USB cable. - View Movie Recordings and Photos on PC: DV Driver - DirectX9.0 - Video Codec - PC Camera/USB Streaming function: DV Driver - DirectX9.0 - Video Codec - Photo Editing: Photo Express...
Page 111
USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Application Installation – Photo Express 1. Click <Photo Express> on the Setup screen. It is a photo editing tool that allows users to edit images. Application Installation – Quick Time 1. Click <Quick Time> on the Setup screen. ...
ENGLISH USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Connecting to a PC 1. Connect a USB cable to the USB jack on the PC. 2. Connect the other end of the USB cable into the USB jack on the DVD Camcorder. (USB jack) ...
USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Using the PC Camera Function This function works only in Camera Mode. page 26 To use the PC Camera function, the DV Driver, Video Codec and DirectX 9.0 programs must be installed in the PC. ...
ENGLISH USB Interface (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Using the USB Streaming Function This function works in both Camera Mode and Player Mode. page 26 To use USB streaming, the DV Driver, Video Codec and DirectX 9.0 programs must be installed in the PC. ...
Maintenance Using Your DVD Camcorder Abroad Each country or region has its own electric and colour systems. Before using your DVD Camcorder abroad, check the following items. Power sources You can use your DVD Camcorder in any country or area with the supplied AC Power adapter within 100V to 240V, 50/60 Hz. ...
ENGLISH Troubleshooting Troubleshooting Before contacting a Samsung authorized service centre, perform the following simple checks. They may save you the time and expense of an unnecessary call. Self Diagnosis Display in <Camera/Player> Modes Display Blinking Informs that... Slow The Battery Pack is almost discharged. Change to a charged one.
Page 117
Troubleshooting Self Diagnosis Display in <M.Cam/M.Player> Modes (VP-DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only) Display Blinking No memory card! Slow (M.Cam) (M.Player) Memory card full Slow Memory card read error Slow Memory card write error Slow Not formatted! Slow No file! Write protect ! Slow Caution When there is dew condensation, put aside for a while before using ...
Page 118
ENGLISH Troubleshooting If these instructions do not solve your problem, contact your nearest Samsung authorized service certre. Symptom You cannot switch the DVD Camcorder on. The DVD Camcorder shuts off automatically. Charge runs out quickly. A vertical strip appears on the screen when recording a dark background.
Page 119
Troubleshooting Symptom Auto focus does not work. When the power is turned off and then turned on, a blue screen appears instead of the normal screen. Pressing the [Record Start/Stop] button does not start recording. Disc is not recognised and the disc cover opens.
Page 120
ENGLISH Troubleshooting Symptom Playback screen interrupted unexpectedly. Cannot play back a recorded DVD-RW/ +RW/-R/+R DL disc. Cannot play back a recorded DVD-RW/ +RW/-R/+R DL disc on a PC. Pushing the [OPEN] switch does not open the Disc Cover. Cannot close the Disc Cover. Explanation/Solution ...
Page 121
Troubleshooting Setting menu items Main Menu Sub Menu Program AE Selecting the Program AE Function White Balance Setting White Balance Digital Effect Setting the Digital special effect Shutter Setting the Shutter speed Camera Exposure Setting the Exposure value 16:9 Wide Setting the 16:9 Wide mode Selecting the Digital Image Stabilizing Performing the backlight compensation...
Page 122
ENGLISH Troubleshooting Main Menu Sub Menu Clock Set Setting the date/time Remote Using the remote control Beep Sound Setting the Beep sound System Shutter Sound* Setting the Shutter sound USB Connect* Selecting the USB device Language Selecting the OSD language Demonstration Demonstration : VP-DC172W/DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi only...
Miscellaneous Information Disc Type Description Disc Type Mode Capacity Formatting a new disc page 42 Recording page 44 Rewrite Playback on other DVD Players (Finalise ) page 80 Playback on other DVD Recorders page 81 Additional recording after finalisation (Unfinalise) page 82 Editing page 72 Reusing a disc by formatting...
Page 124
ENGLISH Specifications Model Name: VP-DC171(i)/DC171Bi/DC171W(i)/DC171WB/DC172W/DC173(i)/DC175WB/DC175W(i)/DC575WB/DC575Wi System Video signal Picture Compression format Audio Compression format Recording Quality Image device Lens Filter diameter LCD Screen/Viewfinder Size/dot number LCD Screen Method Viewfinder Connectors Video output Audio output USB output (VP-DC173(i)/DC175WB/ DC175W(i)/DC575WB/DC575Wi only) General Power source Power source type Power consumption (Recording)
Page 125
Index - A - Accessories ... 13 Add ... 72 AF/MF ... 53 AV In/Out ... 83 - B - Beep Sound ... 32 BLC ... 48 - C - Clock Set ... 30 Colour Nite ... 49 Connection ... 83 Copying ...
Page 126
ENGLISH Power Sources (United Kingdom Only) The mains lead on the power adapter is supplied with a moulded plug incorporating a fuse. The value of the fuse is indicated on the pin face of the plug and, if it requires replacing, a fuse approved to BS1362 of the same rating must be used.
Page 127
UNITED KINGDOM This Samsung product is warranted for the period of twelve (12) months from the original date of purchase, against defective materials and workmanship. In the event that warranty service is required, you should return the product to the retailer from whom it was purchased.
Page 128
Το προϊόν αυτό της SAMSUNG είναι εγγυημένο για περίοδο δώδεκα (12) μηνών από την ημερομηνία αγοράς του για ανταλλακτικά και εργατικά. Στην περίπτωση που θα χρειαστεί επισκευή, το προϊόν αυτό της SAMSUNG θα πρέπει να σταλεί ή να μεταφερθεί στο εξουσιοδοτημένο service, με έξοδα του αγοραστή.
Page 129
προϊόντος Β. Επισκευή που έγινε από μη εξουσιοδοτημένα συνεργεία service Γ. Ατυχήματα, θεομηνίες ή οποιαδήποτε αιτία πέρα του ελέγχου της SAMSUNG, συμπεριλαμβανομένων αλλά μη περιορισμένων των κεραυνών, του νερού, της φωτιάς, των δημοσίων αναταραχών, του κακού αερισμού κλπ. Δ. Η εγγύηση αυτή δεν επηρεάζει τα δικαιώματα του...
Page 131
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Region Country CANADA North America MEXICO U.S.A ARGENTINE BRAZIL CHILE COSTA RICA ECUADOR EL SALVADOR GUATEMALA Latin America...
Page 132
ENGLISH THIS DVD CAMCORDER IS MANUFACTURED BY: RoHS compliant Our product complies with “The Restriction Of the use of certain Hazardous Substances in electrical and electronic equipment”, and we do not use the 6 hazardous materials- Cadmium(Cd), Lead (Pb), Mercury (Hg), Hexavalent Chromium (Cr ), Poly Brominated Biphenyls (PBBs), Poly Brominated Diphenyl Ethers(PBDEs)- in our products.
