Display Contour Lines and Adjust the Contour Interval
You can display or hide the contour lines on the map, and you can adjust the distance between each contour line. Contour Interval
is also affected by the Water Level Offset setting.
Display the Contour Lines and Adjust the Contour Interval
1. From the AutoChart Options menu, select Contour Lines.
2. Select Visible (LakeMaster) or press the CHECK/INFO key or the RIGHT Cursor key to add a check mark (CoastMaster).
3. Select Contour Intervals.
4. Press the RIGHT or LEFT Cursor keys to adjust the setting.
Change the Contour Lines Color
1. From the AutoChart Options menu, select Contour Colors.
2. Select a color.
Changing the AutoChart Live Map Display Colors (Map Source: Humminbird LakeMaster)
contour
intervals
contour line depth label
(depth of contour)
