*LVDS (30-pin): 24-bit dual channel LVDS Header
*LVDS
Pin Define
Pin No. Pin No.
VDD
VDD
GND
R2AN
R2BN
R2CN
GND
R2CLKN
R2DN
R1AN
R1BN
R1CN
GND
R1CLKN
R1DN
Pin Define
1 2
VDD
3 4
GND
5 6
GND
7 8
R2AP
9 10
R2BP
11 12
R2CP
13 14
GND
15 16
R2CLKP
17 18
R2DP
19 20
R1AP
21 22
R1BP
23 24
R1CP
25 26
GND
27 28
R1CLKP
29 30
R1DP
18
Pin1
Pin2
