JETWAY R3399X-2C Series User Manual page 11

Rear Connectors:
DCIN
HDMI1
USB1
USB20_1(R3399XL-2C)
LAN2 (R3399X-2C)
LAN
J19
J9100
SIM1
Internal Connector, Headers & Jumpers:
P/N
JP8
RESETKEY
FAN
UART1
DEBUG
UART3
UART4
UART5
FP_USB2/FP_USB3
FP_USB20 (R3399X-2C) USB 2.0 Connector
SPK
GPIO
GPIO_VCC
CSI (R3399X-2C)
EDP
EDP_VCC
P/N
12V DC–In Power Jack
Top: HDMI-In Port
Bottom: HDMI-Out Port
Top: USB 3.0/OTG Co-Lay Port
Bottom: USB 3.0 Port
USB 2.0 Port x2
10/100 Mbps RJ-45 LAN Port
10/100/1000 Mbps RJ-45 LAN Port
Audio Line-out & MIC Combo Jack
Micro-SD (TF) Card Socket
SIM Card Socket
Power Switch/Recovery Connector
Reset Connector
CPUFAN Connector
UART TTL/ RS485 Connector
Debug Connector
RS232/ UART TTL Connector
UART TTL/ RS232 Connector
UART TTL Connector
USB 2.0 Connector
3W Speaker Connector
GPIO & I2C Combo Header
GPIO_VCC Select Jumper
MIPI CSI Connector
EDP Header
EDP LCD Power VCC Select Jumper
Name
Name
6
Description
3-pin Block
2-pin Block
2-pin Block
4-pin Block
4-pin Block
4-pin Block
4-pin Block
4-pin Block
9-pin Block
9-pin Block
4-pin Block
16-pin Block
3-pin Block
15-pin Block
20-pin Block
4-pin Block
