Dual indication
This template provides indication of 2 process values. Variations of this template are available providing dual PV with totalization,
dual totalization or dual level indication. The example in Fig. 15 shows a single CM15 providing indication of both the flow
through, and temperature of, a heat exchanger.
Steam Outlet
PV1
TT
PV2
Product Inlet
Product Output
FT
Steam
Fig. 15: Dual indication
DIN | DS/CM15–EN Rev. J
11
ControlMaster CM15 | Universal process indicator,
