User Guide – Basic Functionality IM/CM/B–EN Rev. H
ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/
,
1
/
and
1
/
DIN
8
4
2
The Company
We are an established world force in the design and manufacture of instrumentation for industrial process control,
flow measurement, gas and liquid analysis and environmental applications.
As a part of ABB, a world leader in process automation technology, we offer customers application expertise, service
and support worldwide.
We are committed to teamwork, high quality manufacturing, advanced technology and unrivalled service and
support.
The quality, accuracy and performance of the Company's products result from over 100 years experience, combined
with a continuous program of innovative design and development to incorporate the latest technology.
