sure the fuel ignites as quickly as possible. Practical tip: Chop
the wood into much smaller pieces and use an extra fi relighter.
NB: If the stove has not been used for some considerable time,
it is important to check the chimney pipe for blockage.
6.0 Service
Warning! Any unauthorised changes to the product are illegal!
Only original spare parts may be used!
6.1 Replacing the burn plates
Fig. 20
A
Fig. 21
A Ø10mm
1. Remove the side burn plates by lifting them slightly and
pulling out at the bottom (Fig 3).
2. Remove the screws (Fig 20A) and pull the back burn plate
out. Hold simutaneously the baffl e (Fig 20B) up so it does
not fall down. Please note that the seal on the back burn
plate needs to be replaced if damaged .
3. To install the burn plates, follow the same procedure in
reverse order
ENGLISH
B A
B
15
