- Page 1 Jøtul C 550 CB Rockland 139656_04 5/15/15 40” 1016 mm Jøtul C 550 CB 31 5/8” 803 mm Rockland Fireplace Insert Installation and Operating Instructions for the United States & Canada Keep these instructions for future reference.
-
Page 2: Table Of Contents
Jøtul C 550 CB Rockland 139656 5/15/15 Table of Contents For Your Records... Record the following information to help your Standards and Safety Notices dealer determine what you will need should Standards / Codes ............3 your fireplace ever require parts or service. Safety Notices ...............4 The serial number and manufacturing date Preparation ..............4... -
Page 3: Standards / Codes
Jøtul C 550 CB Rockland 139656_04 5/15/15 Standards WARNING ! The Jøtul C 550 CB Rockland fireplace insert has been THIS WOOD HEATER HAS A MANUFACTURER- tested and listed to the following standards: SET MINIMUM LOW BURN RATE THAT MUST U.S: ANSI/UL 1482-2011 and ANSI/UL 737-2011 NOT BE ALTERED. -
Page 4: Safety Notices
Jøtul C 550 CB Rockland 139656 5/15/15 Preparation We strongly urge you to have your authorized Jøtul Safety Notices dealer install your new Jøtul C 550 CB Fireplace Insert. • Check with local building officials to determine what • BURN SOLID WOOD FUEL ONLY permits may be required before installation. -
Page 5: Specifications
Jøtul C 550 CB Rockland 139656_04 5/15/15 Jøtul C 550 CB Rockland Specifications Performance Maximum Heat Output based on total kilograms of dry wood burned in a one hour period. Under Fuel: up to 24” Logs specific EPA test conditions, this heater has Heat Output up to 65,000 BTU/Hr. -
Page 6: Installation
Jøtul C 550 CB Rockland 139656 5/15/15 Installation Masonry Fireplace Requirements Factory-Built Fireplace Requirements The Jøtul C 550 CB Rockland may be installed into a • The entire fireplace and chimney must be cleaned and inspected to NFPA 211 Level II standards before factory-built fireplace with the following conditions: installation. -
Page 7: Hearth Protection
Jøtul C 550 CB Rockland 139656_04 5/15/15 Hearth Protection Requirements Factory-Built Fireplace Requirements, cont’d. The floor area in front of fireplace insert must be • The convection chamber/louvers of the zero- protected from live sparks and radiant heat. clearance fireplace MUST NOT be blocked off. The use •... -
Page 8: Clearance To Combustibles
Jøtul C 550 CB Rockland 139656 5/15/15 Clearance to Combustible Materials • There may be no combustible materials located • Specific clearance (open space) must be anywhere within 36” (914 mm) of the front of maintained between the fireplace insert and the fireplace insert. -
Page 9: Clearance To Combustibles
Jøtul C 550 CB Rockland 139656_04 5/15/15 Minimum Clearances for units with serial numbers before 11903 Serialized labels are located on the shipping crate, firebox floor, and firebox shroud. These older units may be updated for installation at the reduced clearances on the preceding page with installation of Jøtul C 550 CB Clearance Reduction Kit 157705. -
Page 10: Chimney Connection
Jøtul C 550 CB Rockland 139656 5/15/15 Chimney Connection Requirements 5. For external chimneys, (one or more sides are exposed to the outside below the roof line, including garages), a positive connection to the first flue tile is The insert must be connected to a code-approved acceptable provided the tile is no larger than 8”... - Page 11 Jøtul C 550 CB Rockland 139656_04 5/15/15 Fireplace Chimney Preparation 1. Remove the existing damper and linkage components from the fireplace. Alternatively, you can wire the damper plate to lock it in the open position. Thoroughly clean the firebox and smokeshelf area with a wire brush.
-
Page 12: Firebox Installation
Jøtul C 550 CB Rockland 139656 5/15/15 Installing the Fireplace Insert Quik-connectors Inner Shroud Power Cord Orientation 1. Determine to which side the blower power cord will be routed. DO NOT ROUTE THE POWER CORD ACROSS THE FRONT OF THE FIREPLACE. Phillips 2. -
Page 13: Surround Assembly
Jøtul C 550 CB Rockland 139656_04 5/15/15 Figure 13. Left Breastplate Right Breastplate Surround Panel assembly viewed from backside. Tools Required: • 10 mm socket or wrench Alignment Set Screw ENAMEL CAUTION NOTE: The assembled surround is very heavy. Enamel All fasteners are M6 x 10 mm hex Right Leg head bolts, pre-installed. -
Page 14: Operation
Jøtul C 550 CB Rockland 139656 5/15/15 Operation A seasoned log will have check marks on the ends and be lighter than an unseasoned log which will show little or no check marks. We recommed using a moisture meter to determine Read the following section carefully before building a fire the moisture content of your wood. -
Page 15: Break-In Procedure
Jøtul C 550 CB Rockland 139656_04 5/15/15 Blower Settings / Air Control effectiveness of the air wash over the glass; the higher the setting, the cleaner the glass will remain. Additional air Use the following guide for best performance. is separately directed into the top of the fire chamber to Burn Rate Air Control Setting Blower Speed... -
Page 16: Starting / Maintaining The Fire
Jøtul C 550 CB Rockland 139656 5/15/15 Starting and Maintaining a Fire Adding Fuel to the Fire Burn only solid wood directly on the bottom grate of the stove. When reloading the stove while a bed of hot embers still Do not elevate the fire in any way. -
Page 17: Blower Operation
Jøtul C 550 CB Rockland 139656_04 5/15/15 It is also important to remember that chimney size, temperature and height all affect draft which in turn WARNING ! affects the formation of creosote. An exterior chimney, whether masonry or prefabricated steel, will be exposed ... -
Page 18: Maintenance
Jøtul C 550 CB Rockland 139656 5/15/15 Maintenance Glass Replacement Always operate the doors slowly and cautiously to avoid cracking or breaking the glass. Never use the door to Ash Removal push wood into the firebox. If the glass becomes cracked or broken follow the replacement procedure below. -
Page 19: General Maintenance
Jøtul C 550 CB Rockland 139656_04 5/15/15 General Maintenance Canada Installations (Full Reline): Regular maintenance will assure proper performance and prolong the life of your fireplace insert.. The follow- The chimney liner can be swept directly into a bucket ing procedures do not take long and are generally inex- placed under the flue outlet, with removal of the two pensive. -
Page 20: Blower Maintenance
Jøtul C 550 CB Rockland 139656 5/15/15 Replacement Gaskets Glass LD .250 Fiberglass Rope 66” 200024 Door LD2 .350 Fiberglass Rope 70” 100038 Front LD2 .360 Fiberglass Rope 90.5” 117587 Air Manifold, Outer LD2 .250 SA Fiberglass Rope 30” 129644 Air Manifold, Inner .125 x 8 mm Flat SA 24”... - Page 21 Jøtul C 550 CB Rockland 139656_04 5/15/15 This page is intentionally blank.
-
Page 22: Exploded View
Jøtul C 550 CB Rockland 139656 5/15/15 Jøtul C 550 CB Rockland Illustrated Parts Diagram Use only genuine Jøtul replacement parts. Do not substitute parts from any other manufacturer. See your local Authorized Jøtul Dealer or contact us directly: Jøtul North America 55 Hutcherson Dr. -
Page 23: Parts Listing
Jøtul C 550 CB Rockland 139656_04 5/15/15 Jøtul C 550 CB Rockland Parts List Description Part Number Description Part Number Rear Shroud 222027 Roll Pin, 5 mm x 24 mm 117733 Screw, #8 x 1/2” Hex Slt 117917 Washer, Insulating 124385 Nut, M6 Flange 117968... -
Page 24: Alternate Hearth Protection
Jøtul C 550 CB Rockland 139656 5/15/15 Appendix A Alternate Hearth Protection Leg Leveler Installation Two leg leveler bolts are contained within the All hearth protection materials must be noncombustible; i.e: Miscellaneous Kit included inside the firebox. The bolts metal, brick, stone, or mineral fiber boards. Any combustible are intended to help level and plumb the firebox if material may not be used. -
Page 25: Warranty Statement
Jøtul C 550 CB Rockland 139656_04 5/15/15 Jøtul C 550 CB Rockland can also be identified by warped plates, rust-colored cast iron, paint pig- Limited LifetimeWarranty ment that has turned dusty white, or bubbling, cracking and discolor- ation of the enamel finish. Misuse includes, without limitation, use that is not in conformance with the operating instructions contained in this Effective January 1, 2013. - Page 26 Jøtul C 550 CB Rockland 139656 5/15/15 This page is intentionally blank.
- Page 27 Jøtul C 550 CB Rockland 139656_04 5/15/15 This page is intentionally blank.
- Page 28 Jøtul C 550 CB Rockland 139656 5/15/15 This appliance must be installed in conformance with local and national building regulations. It is important that the these instructions be carefully read and understood before beginning the instal- lation. Jøtul pursues a policy of continual product development. Consequently, products may differ in specification, color or type of accessories from those illustrated or described in various publications.
