Control Panel

(1) Power button
(2) Function button
(3) Temp increase (+) button
(4) Temp decrease (-) button
(5) LED display screen
Indicator lights:
*heating not applicable for all models.
The light only will be lighten when the unit has heating function

LED Display

• The LED display indicates the current set temperature or the timer setting.
• When the set temperature or the timer is adjusted, the new setting is shown on the
display.
• The LED display is also used to show error codes should a fault occur.
(6) Speed button
(7) Timer button
(8) Sleep button
(9) Swing button
