- Page 1 INSTRUCTION MANUAL Portable Air Conditioner Model: DCP7W For domestic household use only.
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/ OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your Portable Air Conditioner for the first time and keep them in a safe place.
- Page 3 • WARNING: To avoid danger of suffocation please remove all packaging materials particularly plastic and EPS and keep these away from vulnerable people, children and babies. • NEVER drop or insert any object or fingers into any openings. • Do not cover or obstruct the air inlet and outlets. •...
- Page 4 WARNING: For using R290 refrigerant. ThIs symbol shows that this appliance uses a flammable refrigerant. If the refrigerant is leaked and exposed to an external ignition source, there is a risk of fire. CAUTION: RISK OF FIRE/FLAMMABLE MATERIALS. THE APPLIANCE MUST BE INSTALLED, USED &...
- Page 5 • Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. • Please follow the instruction carefully to handle, install, clear, service the air conditioner to avoid any damage or hazard.
- Page 6 • Checks to the refrigeration equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer's maintenance and service guidelines shall be followed. If in doubt consult the manufacturer's technical department for assistance.
- Page 7 • Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans.
- Page 8 Decommissioning • Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.
- Page 9 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children If an extension Where the power may be left unattended lead may become cable may be overloaded damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 10: Specification
Specification Model no. DCP7W Colour White Power supply 220-240V~, 50Hz Operating temperature 17-35°C Thermostat range 17-30°C Rated Input Power 0.98kW Cooling Capacity 1.93kW Dehumidification Capacity 1.93L/hour Noise Level Minimum (Lo) 51dB(A) Noise Level Maximum (Hi) 62dB(A) Air Volume (Lo/Hi) 211/272... - Page 11 Parts (10) (11) (12) (13) front rear Control panel Handle (both sides) Remote signal receptor Air filter Horizontal manual louvre control lever Upper air intake Vertical manual louvre control lever (10) Drain outlet Panel (11) Air outlet Caster (12) Lower air intake (13) Bottom tray drain outlet Note:...
-
Page 12: Control Panel
Control Panel FRESH( Press 3s Mode button Temp decrease (-) button Indicator light LED display screen Temp increase (+) button Power button Mode button: Selects the appropriate operating mode. Each time you press the button, a mode is selected in a sequence that goes from Cool, Fan, Dry, Heat (on some models), and Auto (on some models). -
Page 13: Led Display
LED Display Shows the set temperature while on Cool, Heat or Auto mode (on some models). While on Dry and Fan modes, it shows the room temperature. Error codes: E0 - EEPROM error. E1 - Room temperature sensor error. E2 - Evaporator temperature sensor error. E3 - Condenser temperature sensor error (on some models). - Page 14 Remote Control Mode display COOL AUTO AUTO HEAT Displayed when data transmitted. COOL HIGH Displayed when remote controller is ON. HEAT Displayed when TIMER ON time is set Displayed when TIMER OFF time is set Shows set temperature or room temperature, or time under TIMER setting Indicated all the current settings are locked...
-
Page 15: Exhaust Hose Installation
Installation EXHAUST HOSE INSTALLATION The exhaust hose and adaptor must be installed or removed in accordance with the usage mode. For COOL, HEAT (heat pump type) or AUTO (on some models) mode the exhaust hose must be installed. For FAN, DRY or HEAT (electrical heat type) the exhaust hose should be removed. -
Page 16: Window Kit Installation
Installation WINDOW KIT INSTALLATION The window slider kit has been designed to fit most standard vertical and horizontal window applications, however it may be necessary for you to modify some aspects of the installation procedures for certain types of windows. Step one: Preparing the exhaust hose assembly Press the exhaust hose (or extended exhaust hose) into the window slider adaptor (or wall exhaust... - Page 17 Installation WINDOW KIT INSTALLATION Step two: Install the exhaust hose assembly to the unit Push the Exhaust hose into the air outlet opening of the unit along the arrow direction. Step three: Preparing the adjustable window slider 1. Choose the window sliders according the size of your window. If the sliders need to be cut to meet the window size, please take extra care to cut it properly.
- Page 18 Installation WINDOW KIT INSTALLATION Before assembl y MODEL B Window Slider s After assembl y Bolt 1+2： Bolt Bolt 1+2+3 ： Bolt Bolt Bolt 1+2+3+4 ： Bolt 1+4： Before assembl y MODEL C Window Slider s After assembl y Bolt 1+2：...
- Page 19 Installation WINDOW KIT INSTALLATION Note: Once the exhaust hose assembly and adjustable window lider are prepared, choose from one of the following two installation methods. Type 1: Hung Window or Sliding Window Installation (for some models) Foam seal B Foam seal B (Adhesive type-shorter) (Adhesive type-shorter) Foam seal A...
- Page 20 Installation 5. I nsert the window slider adaptor into the hole of the window slider. Type 2: Wall Installation (for some models) 1. Cut a 125mm (4.9inch) hole into the wall for wall exhaust adaptor B. 2. Secure the wall exhaust adaptor B to the wall using the four anchors and screws provided in the kit.
-
Page 21: Tools Needed
Installation TOOLS NEEDED • Medium Philips screwdriver • Tape measure or ruler • Knife or scissors • Saw (optional, to shorten window kit for narrow windows ACCESSORIES (not all accessories supplied with all models) Shape Qty. Shape Qty. Name of Accessories Name of Accessories Unit Adaptor 1 pc... - Page 22 Operating Instructions COOL operation · Press the "MODE" button until the "COOL" indicator light comes on. · Press the ADJUST buttons "+" or "-" to select your desired room temperature. The temperature can be set within a range of 17°C~30°C/62°F~88°F(or 86°F). ·...
-
Page 23: Auto Restart
Operating Instructions Constant Fan button (On some models) In Cooling or Dry mode, press the button for 3 seconds to turn on or off the constant fan function. When the function is turned on, the constant fan light will illuminate, identifying the fan continuous run for cooling. -
Page 24: Water Drainage
Operating Instructions POWER MANAGEMENT feature (On some models) Under cooling operation, when the ambient temperature is lower than the setting temperature for a period of time, the unit will automatically operate the power management feature. The compressor and fan motor will stop. When the ambient temperature is higher than the setting temperature, the unit will automatically quit the power management feature. - Page 25 Continuous drain hos e Remove the drain plug When the water level of the bottom tray reaches a predetermined level, the unit beeps 8 times, the digital display area shows "P1" . At this time the air conditioning/ dehumidification process will immediately stop. However, the fan motor will continue to operate (this is normal).
-
Page 26: Safety Precautions
Cleaning SAFETY PRECAUTIONS • Always unplug the unit before cleaning or servicing. • DO NOT use flammable liquids or chemicals to clean the unit. • DO NOT wash the unit under running water. Doing so causes electrical danger. • DO NOT operate the machine if the power supply was damaged during cleaning. A damaged power cord must be replaced with a new cord from the manufacturer. -
Page 27: Maintenance
Warranty Please refer to the warranty card in the box for warranty information. For any troubleshooting advice, please contact the relative Customer Care Centre below. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd 8 Lakeview Drive, 38 Harris Road, East Tamaki,... - Page 28 Supplied by Glen Dimplex Australia 8 Lakeview Drive, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
