[FILTER UNIT]
REF PART
NO. NO.
C7511 4030024040 S.CER 0603B472K500CT
RL7001 6330002140 REL G5Q-1A DC5V
RL7002 6330002140 REL G5Q-1A DC5V
RL7003 6330002140 REL G5Q-1A DC5V
RL7004 6330002140 REL G5Q-1A DC5V
RL7005 6330002140 REL G5Q-1A DC5V
RL7006 6330002140 REL G5Q-1A DC5V
RL7007 6330002140 REL G5Q-1A DC5V
RL7009 6330002140 REL G5Q-1A DC5V
RL7011 6330002140 REL G5Q-1A DC5V
RL7012 6330002140 REL G5Q-1A DC5V
RL7013 6330002140 REL G5Q-1A DC5V
RL7014 6330002140 REL G5Q-1A DC5V
RL7015 6330002140 REL G5Q-1A DC5V
RL7016 6330002140 REL G5Q-1A DC5V
RL7017 6330002140 REL G5Q-1A DC5V
RL7018 6330002140 REL G5Q-1A DC5V
RL7020 6330000781 REL AGP2013F
J7001 6510028210 CON SJ050010 (TMP-J01X-V6)
J7311 6510028210 CON SJ050010 (TMP-J01X-V6)
J7321 6510028210 CON SJ050010 (TMP-J01X-V6)
J7501 6510022611 S.CON 16FMN-BMTTR-A-TBT (LF) (SN)
EP7501 6910018240 S.BEA MMZ1608Y152CT
EP7502 6910018240 S.BEA MMZ1608Y152CT
EP7503 6910018240 S.BEA MMZ1608Y152CT
EP7504 6910018240 S.BEA MMZ1608Y152CT
EP7505 6910018240 S.BEA MMZ1608Y152CT
EP7506 6910018240 S.BEA MMZ1608Y152CT
EP7507 6910018240 S.BEA MMZ1608Y152CT
EP7509 6910018240 S.BEA MMZ1608Y152CT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M .
LOCATION
T
T
T
T
T
T
T
T
T
T
H/V
84.9/3.0
69.0/6.8
87.6/3.9
88.4/5.1
89.4/6.4
90.4/7.7
91.3/8.9
58.2/9.2
56.8/3.9
58.2/7.6
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
