Icom IC-M803 Service Manual page 35

[PA UNIT]
REF PART
NO. NO.
C6610 4030024300 S.CER 0805B104K500CT
C6611 4030024340 S.CER 0805B472K500CT
C6612 4030024280 S.CER 0805B102K500CT
C6613 4510011390 ELE 16 ME 2200 WA
C6701 4030023820 S.CER 0603B104K250CT
C6702 4030023820 S.CER 0603B104K250CT
C6703 4030023820 S.CER 0603B104K250CT
C6704 4030024040 S.CER 0603B472K500CT
C6705 4030024040 S.CER 0603B472K500CT
C6706 4030024040 S.CER 0603B472K500CT
C6707 4030024040 S.CER 0603B472K500CT
C6708 4030024040 S.CER 0603B472K500CT
C6709 4030024040 S.CER 0603B472K500CT
C6711 4030023820 S.CER 0603B104K250CT
C6712 4030025230 S.CER TMK107BJ105KAHT
C6713 4030025230 S.CER TMK107BJ105KAHT
C6714 4030025230 S.CER TMK107BJ105KAHT
C6715 4030025230 S.CER TMK107BJ105KAHT
C6716 4030025230 S.CER TMK107BJ105KAHT
C6717 4030025230 S.CER TMK107BJ105KAHT
C6718 4030025230 S.CER TMK107BJ105KAHT
J6101 6510028210 CON SJ050010 (TMP-J01X-V6)
J6401 6510028210 CON SJ050010 (TMP-J01X-V6)
J6501 6510018961 S.CON B2B-PH-SM4-TB (LF) (SN)
J6701 6510022601 S.CON 30FMN-BMTTR-A-TBT (LF) (SN)
J6703 6510018971 S.CON B4B-PH-SM4-TB (LF) (SN)
F6701 5220000440 HOL FHA040-01
F6702 5210001430 FUS 11930011 (BFLP 5A 58V)
EP6201 6910023820 S.BEA MPZ2012S101A-T
EP6202 6910023820 S.BEA MPZ2012S101A-T
EP6203 6910023820 S.BEA MPZ2012S101A-T
EP6602 6510018330 TER F4053A
EP6603 6510018330 TER F4053A
EP6604 6910018930 S.BEA MPZ2012S601A
EP6605 6910014640 S.BEA MPZ2012S221A-T
EP6606 6910014640 S.BEA MPZ2012S221A-T
EP6607 6910014640 S.BEA MPZ2012S221A-T
EP6608 6910014640 S.BEA MPZ2012S221A-T
EP6609 6910019900 S.BEA MPZ1608S601AT
EP6610 6910019900 S.BEA MPZ1608S601AT
EP6611 6910019900 S.BEA MPZ1608S601AT
EP6612 6910019900 S.BEA MPZ1608S601AT
EP6613 6910019900 S.BEA MPZ1608S601AT
EP6614 6910019900 S.BEA MPZ1608S601AT
EP6615 6910019900 S.BEA MPZ1608S601AT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M .
LOCATION
T
T
T
T 186.3/62.4
T 186.3/66.2
T
T 104.5/18.3
T 138.6/10.6
T 173.8/66.5
T 174.6/84.0
T 177.1/84.0
T 119.9/17.8
T 121.3/17.8
T 106.2/19.3
T 107.4/19.3
T 108.6/19.3
T 109.8/19.3
T 111.0/19.3
T 112.3/19.3
T 113.5/19.3
T 24.0/89.3
T 119.5/11.0
T 181.4/74.3
T 118.7/64.5
T 114.9/64.5
T 115.7/82.0
T 139.6/8.5
T 174.8/72.4
T 174.8/68.9
T 185.0/71.8
T 185.0/75.3
T 113.5/15.8
T 112.3/15.8
T 111.0/15.8
T 109.8/15.8
T 108.6/15.8
T 107.4/15.8
T 106.2/15.8
H/V
15.7/69.8
15.7/71.7
15.7/73.5
84.1/10.7
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
