S
C
C
ERIAL
ABLE
ONNECTIONS
Figure 2
Serial cable routing—full height tape drive
Figure 3
Serial cable routing—half height tape drives
P
C
C
OWER
ABLE
ONNECTIONS
Figure 4
Power cable routing—full height tape drive
Half height
tape Drive
Figure 5
Power cable routing—half height tape drives
4
12
OF
Library
Full Height
Tape Drive
Library
HH Tape Drive
HH Tape Drive
Library
FH tape drive
TD carrier
Library
TD carrier
Serial cable
Drive 2
Top serial connector
Bottom serial connector
Drive 1
Serial cable
Drive 2
Top serial connector
Bottom serial connector
Drive 1
Power cable
Middle power connector
(not used in this configuration)
Route cable through tape drive carrier
End power connector
Power cable
End power connector (upper TD)
Middle power connector (lower TD)
Route cable through tape drive carriers
(S)
(S)
(P)
(P)
