Note:
Most of the illustrations show SCSI configurations. Use the same steps to install Fibre Channel tape drives.
Glossary of Abbreviations
FH = Full Height (tape drive)
HH = Half Height
R
I
EFERENCE
LLUSTRATIONS
Figure 1
Internal library serial connectors
T
D
C
APE
RIVE
OVER
Upper SCSI
cover plate
Half Height SCSI
Tape Drive
Cover Plate
Lower SCSI
cover plate
Full Height Fibre Channel
Tape Drive Cover Plate
! Important
TD = Tape Drive
224 = Magnum 224
P
S
LATES AND
ERIAL
Be sure to use the serial cable (S) that came with your replacement kit. The serial
cables are specifically configured (at the factory) for use with the individual tape drives.
Looking inside
back of library
Top library serial
connector
Bottom library serial
connector
C
ABLE
Connect to
tape drive (white)
T24 = StorageLibrary T24
2U = StorageLoader 2U LTO
Full Height SCSI
Tape Drive Cover Plate
Full Height SCSI
cover plate
Serial cable
(S)
Connect to
library (black)
3
12
OF
