GUARANTEE
This Shure product is guaranteed in normal use to be free from
electrical and mechanical defects for a period of one year from
date of purchase. Please retain proof of purchase date. This guar-
antee includes all parts and labor, and is in lieu of any and all other
guarantees or warranties, express or implied. There shall be no re-
covery for any consequential or incidental damages.
SHIPPING INSTRUCTIONS
Carefully repack the unit, have it insured, and return it prepaid to:
Shure Brothers Incorporated
Attention: Service Department
222 Hartrey Avenue
Evanston, Illinois 60202–3696
If outside the U.S.A, return the unit to your dealer or Authorized
Shure Service Center for repair. The unit will be returned to you
prepaid.
MODEL A15TG MICROPHONE LEVEL TONE GENERATOR
This battery-powered 700 Hz signal source can be used for set-
ting up and troubleshooting audio equipment in recording, broad-
casting, or sound reinforcement. The A15TG will drive low-im-
pedance balanced-line microphone inputs such as those
normally used with other Shure A15 Series Products.
The A15TG is equipped with an On-Off switch recessed in the
side of the housing and a three-pin professional audio connector*
at the output end. The end cap of the Tone Generator is threaded,
providing easy installation and replacement of the battery.
*Designed to mate with Cannon XL series, Switchcraft A3 (Q.G.) series,
or equivalent.
1998, Shure Brothers Incorporated
27A8430 (RA)
Shure Brothers Incorporated
222 Hartrey Avenue
Evanston IL 60202-3696 U.S.A.
A15TG
Printed in U.S.A.
