MODEL A15TG MICROPHONE LEVEL TONE GENERATOR
The Shure A15TG Tone Generator is a battery-powered 700 Hz signal
source that can be used to troubleshoot low-impedance, balanced-line
microphone inputs.
The A15TG includes a recessed On-Off switch and a three-pin XLR au-
dio connector. A removable end cap allows easy battery installation and
removal. The A15TG can also tolerate the presence of phantom power,
or a short circuit in the line it is driving. Built-in short circuit protection al-
lows normal operation to resume after a short is removed.
BATTERY LIFE
The A15TG can operate continuously for approximately 1000 hours on
one 1.5V alkaline battery (see battery specification for suggested
types).To conserve battery power, make sure the On-Off switch is in the
Off position when the A15TG is not in use.
BATTERY INSTALLATION
1. Unscrew the end cap.
2. Insert the battery with the "+" terminal facing the "+" mark inside the
end cap.
3. Reinstall the end cap.
