Connection

8.1

Motor-Pump-Unit Hydraulically Connected

8.2

Connection Technique

8.2.1

General Notes

General
Power connection
LSA Control S.L. www.lsa-control.com comercial@lsa-control.com (+34) 960 62 43 01
● Remove the flange covers on suction and pressure connection.
● Immediately wipe away outgoing hydraulic fluid.
● Check the line for cleanliness.
● Ensure that the line connection contains the specified sealings.
● Lock O-rings with assembly grease against slipping , if necessary.
● Now, hydraulically connect the pump according to the specifications of
the machine manufacturers.
Rexroth Sytronix Assembly and Maintenance Internal Gear Pump
PGH/PGM/PGF
Material number: R911340908 (Edition 02)
Rexroth Sytronix Mounting and Commissioning Axial Piston Variable Pump
A10VZO/A10VSO/A4VSO
Material number: R911341629 (Edition 02)
The following work must be done by qualified personnel according to the lo‐
cal regulations.
WARNING
All work on the electric system may only be done by skilled electricians. Tools
for electricians (VDE tools) are absolutely necessary.
Before working:
1. Isolate (even auxiliary circuits).
2. Ensure that the main switch cannot be accidentally
switched on again.
3. Ensure de-energization.
4. Ground and short-circuit.
5. Cover or fencing off neighbored, live parts.
Before start working, check with possible live parts a suitable measuring de‐
vice (e.g. with capacitors). Wait for their discharging time.
Before connecting the motor, check whether the power supply and power fre‐
quency consist with the nominal data. Motors can be operated with a power
supply deviation of ± 5 % and a power frequency deviation of ± 2 % (acc. to
IEC60034-1). A connection overview for power and accessory connections
(PTC) can be found within the terminal box. The connections must be estab‐
Bosch Rexroth AG
Danger to life due to electrical voltage! Han‐
dling within the area of live parts is extremely
dangerous.
65/143
Connection
