CHARGING STATUS

There is one central LED light (1) on the charger interface. Use this table to understand
the LED behaviour.
LED behaviour
a
Idle or no battery
b
Charging
c
Charged (over 90%)
d
Fault
INSERTING THE BATTERY INTO THE PAPR
1. Inspect both the battery and the PAPR. Note the location of the electrical
connectors.
2. Align the lip of the battery with the large slot on side of the PAPR.
3. Align the electrical connectors, and press and hold the red button on the battery
(1).
4. Press the battery into the PAPR (2), and release the red button. The battery
locks into the PAPR (3).
To remove the battery, press the red button to release, and lift.
Meaning
Green blinking light
Light blinks both red and green
Solid green
Solid red
