NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
a. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey
should be considered. If the measured field strength in the location in which the ADView 2 is used exceeds the
applicable RF compliance level above, the ADView 2 should be observed to verify normal operation. If abnormal
performance is observed, additional measures may be necessary, such as re-orienting or relocating the ADView 2.
b. Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Recommended separation distances between portable and mobile RF communications equipment and the ADView
2
The ADView 2 is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. The customer or the user of the ADView 2 can help prevent electromagnetic interference by maintaining
a minimum distance between portable and mobile RF communications equipment (transmitters) and the ADView 2
as recommended below, according to the maximum output power of the communications equipment.
Rated maximum output
power
of transmitter
W
0.01
0.1
1
10
100
93-9005-00
September 1, 2016
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
0.12
0.38
1.2
3.8
12
compliance level in each frequency range.
Interference may occur in the vicinity of equipment
marked with the following symbol:
80 MHz to 800 MHz
0.12
0.38
1.2
3.8
12
800 MHz to 2.5 GHz
0.23
0.73
2.3
7.3
23
