Wi-Fi radio connected (segments will be illuminated continuously)
AC power connected
Printer connected and powered on
Barcode scanner connected and powered on
Error Alert Symbol
WARNING: User must take immediate action (see additional information in Section 12)
Battery Level Indicator
Battery symbol (all bars illuminated indicate a full charge)
Blood Pressure Measurement Mode Selection Icons
Manual Mode (for auscultatory readings)
Averaging Mode
Number of measurements taken in averaging mode
Maximum pressure setting for Manual Mode
Time before first measurement in minutes (Illuminates when Averaging Mode is selected)
Time between measurements in seconds (Illuminates when Averaging Mode is selected)
Blood Pressure Results (DIA and SYS)
DIA and mmHg: Diastolic blood pressure
SYS and mmHg: Systolic blood pressure
EMR Transmission Icons
EMR icon prompts the user to confirm whether or not to send measurement data as message to EMR
system. (Only shown if EMR connectivity has been set up via Configuration Application.)
Message icon (Indicates if EMR messaging is successful)
If successful, the icon will flash on and off with check mark.
If not successful, it will flash on and off with X.
Adult or Child Patient Selection
Press and hold toggle button for 4 seconds, until selection knob starts flashing. Release toggle button, and use the
selection knob to select the icon needed. Selected icon will blink after 1 second. Press the selection knob to confirm
the selection.
Adult BP Mode icon. This icon is illuminated when the Adult BP mode is selected. The ADView 2 will remain in the
selected patient mode until a new mode is set.
