Pediatric BP Mode icon. This icon is illuminated when the Pediatric BP mode is selected. The ADView 2 will
remain in the selected patient mode until a new mode is set.
Heart Rate and MAP Measurements
Measured in BPM (beats per minute) is illuminated when a heart rate is shown in the heart rate display.
MAP Measured in mmHg. Illuminated when MAP functionality is enabled and a MAP value is shown. NOTE: This is a
factory setting. MAP is not available in the U.S.
Pulse Oximetry Measurement Display
Expressed in % of arterial oxyhemoglobin
Temperature Measurement Settings and Results Display
Body temperature in either Fahrenheit or Celsius (user selectable)
Cold Mode
Predictive Mode
Direct Mode
Human Thermometry Mode. Oral (arrow on right side of head), Axillary (arrow under arm), or Rectal (arrow
pointing to rectum).
Apply temp probe cover
