Table of Contents

Frequently Asked Questions (FAQ:) .............. Inside Front Cover
Safety Rules ............................................................................ 1
General Information ................................................................. 2
1.1 Introduction ................................................................................ 2
1.2 Unpacking .................................................................................. 2
1.3 Equipment Description ................................................................ 2
1.4 Transfer Switch Data Decal ......................................................... 3
1.5 Transfer Switch Enclosure ........................................................... 3
1.6 Safe Use Of Transfer Switch........................................................ 3
Installation ............................................................................... 3
2.1 Introduction to Installation ........................................................... 3
2.2 Mounting .................................................................................... 3
2.3 Connecting Power Source and Load Lines .................................. 3
2.4 Connecting Start Circuit Wires .................................................... 4
2.5 Overload Prevention Control Board (OPCB) ................................. 4
2.6 Connection of Power Supply for Contactors ................................ 6
2.7 Auxiliary Contacts ....................................................................... 6
Operation ................................................................................. 7
3.1 Functional Tests & Adjustments .................................................. 7
3.2 Manual Operation ........................................................................ 7
3.3 Voltage Checks ........................................................................... 7
3.4 Generator Tests Under Load ........................................................ 9
3.5 Checking Automatic Operation .................................................... 9
3.6 Testing Overload Prevention Control Board (OPCB) ...................... 9
3.7 Installation Summary .................................................................. 9
Installation Diagram .............................................................. 10
Electrical Data ....................................................................... 11
Notes ..................................................................................... 12
MANUAL DEL PROPIETARIO ........................ 15
MANUEL DU PROPIÉTAIRE .......................... 27
Engine exhaust and some of its constituents are known to the state of California to cause cancer,
This product contains or emits chemicals known to the state of California to cause cancer,
WARNING!
California Proposition 65
birth defects, and other reproductive harm.
WARNING!
California Proposition 65
birth defects, and other reproductive harm.
FAQ:
Q: Do I have to supply the generator with the 100%
loaded BTU rated fuel supply and pipe size?
A: Yes, the generator needs the 100% loaded BTU fuel
rating to start, run and handle loads. The fuel pipe
must be sized for 100% load, regardless of the load.
Q: Does the fuel regulator really need to be 10ft.
(3.05m) from the generator?
A: Yes, per the manufacturer's instruction to assure
proper operation of the regulator and also to meet
code.
Q: Can I use a fuel shut off valve that is not "Full
Flow Rated"?
A: No, it must be a Full Flow Rated valve and must also
match the required fuel pipe ID dimensions.
Q: Do pipe elbows, tees, drip legs, etc. affect gas
pipe size and flow?
A: Yes, they are restrictions to gas flow. You must add
2.5ft. (.76m) per each elbow, tee, etc. to the overall
calculated distance from the source to the generator.
Q: Can I leave the unit on the shipping pallet and
install it?
A: No, it must be installed per local jurisdiction, code
and the instructions as outlined by the manufacturer.
Q: Can the generator be mounted indoors or in a
structure?
A: No, it is designed, manufactured and sold for outdoor
use only!
Q: Can I run the Main AC and Control Wires in the
same conduit?
A: Yes, this wiring can be run in the same conduit if the
appropriate rated wire and insulation is used and it
meets code.
Q: Can the Transfer Switch be mounted outdoors?
A: Only if it's a NEMA 3R rated transfer switch.
