Intel IQ80315 Board Manual page 11

Table 2. Feature Summary (Sheet 2 of 2)
Feature
I/O Ports
Expansion
Connectors
Misc. Functions
Optical
Audible Alarm
®
Intel IQ80315 I/O Processor Evaluation Platform Board Manual
®
Intel
Dual Serial Ports:
• Stacked DB9s mounted in the rear gasket area
JTAG Ports:
• Six JTAG headers (one main/CPU 0 JTAG header and a second dedicated header
for CPU 1)
®
• The Intel 80200 processor JTAG can be chained together on the main JTAG
header or use a jumper option for independent operation.
®
• The Intel 80314 I/O processor companion chip JTAG can be operated
independently or chained with the remaining peripheral devices.
• Main JTAG header is accessible from the rear panel gasket.
• CPLD is programmed through the dedicated JTAG port.
2
Dual I C Ports:
• Four-pin header for access to main I
• Four-pin header for access to the DDR serial presence detect I
Serial ATA:
• Eight serial ATA 1.0 standard copper connect ports
CompactFlash* II:
• One CompactFlash type-II socket mounted in the rear panel gasket
Gigabit Ethernet:
• Two RJ45 Ethernet ports with integrated LEDs and magnetics
• Mounted in the rear panel gasket
Fan-Control Headers:
• Eight fan-control headers (up to four front fans and four rear fans)
ATX standard front panel header
PCI-X Connectors:
• Bus A—Two 64-bit slots—100/66 MHz
• Bus B—One 64-bit slot—100/66 MHz
Peripheral Bus Header:
• PC104-like 0.1" header for logic analyzer probing or peripheral bus prototyping
Real-time clock with replaceable CR2032 battery
Dual temperature sensors
Electronic serial numbers—two unique 48-bit serial numbers
Supply voltage monitor for under-voltage detection
CPLD:
• Misc. logic collection
• Misc. registers (Revision ID, battery status, rotary switch, and so on)
• Two 7-Segment LED displays for debug
• Power-on LED (green) indicators for each power plane
• Hard-drive activity LED indicators (blue) for each hard drive
• Composite hard-drive activity LED (green)
• Header for external hard-drive activity LEDs
• Header for a two-line, 40-character LCD display.
PCB mounted buzzer and connector for chassis mounted speaker
IQ80315 I/O Processor Evaluation Platform
Details
2
C bus
2
C bus
