54 C 3: C
HAPTER ONFIGURING

Step Summary

W S
IRELESS ERVICES
Table 9 Creating a Service for Employee Access (continued)
Task Path
"Create a 1 Tool bar option: select
Service Profile
for 802.1X
2 Organizer panel: expand
Access" on
page 61
3 Expand Wireless.
4 Click Wireless Services.
5 Select 802.1X Service
"Set Up 1 Tool bar option: select
VLANs on WX
Switches" on
2 Organizer panel: expand
page 66
3 Expand System.
4 Click VLANs.
5 Select VLAN in the Task
The following list summarizes the fields selected or configuration items
entered in the example that follows to configure Employee access:
1 Create a radio profile.
From the Radio Profile wizard, enter RadioProfile1 as the name of the
radio profile.
Click Finish.
2 Configure the RADIUS back end:
Configure the RADIUS server for 802.1X. Use the recommended EAP
method, PEAP + MS-CHAPv2.
Set up each WX switch as a RADIUS client.
Define any desired 3Com vendor-specific attributes (VSAs).
Configuration.
the WX switch.
Profile in the Task List.
Configuration.
the WX switch.
List.
Primary Parameters to
Configure
From the Create Service Profile
wizard:
Service profile name: edit name
SSID name: enter name
Security mode: select WPA (and
deselect Dynamic WEP)
Encryption type: use TKIP
(already selected)
EAP Type: use External RADIUS
Server (already selected)
RADIUS server group: select one
SSID default VLAN: enter name
Radio profile: select one
From the Create VLAN wizard:
VLAN Name: enter name
VLAN ID: select number
IP Address: enter IP Address
Ports: select them and either
move them (use them only in
the new VLAN) or add them
(share them with other VLANs)
If you add them, select Tag
