Baud rate—9600
Flow control—None
Data—8
Parity—None
Stop bits—1
DCD state—Disregard
Ensure that you have the following parts and tools available:
1 USB 2.0 Standard-A to Mini-USB cable (p/n 720-037982).
To connect the CTP151 device to the console using the Mini-USB Type-B console port:
1. Connect the Standard-A connector of the Mini-USB cable to the host machine (PC or laptop).
2. Connect the Mini-USB Type-B (5-pin) connector of the Mini-USB cable to the Mini-USB Type-B console port (labeled
CON) on the CTP151 device.
3. Reboot the CTP151 device.
After the connection is established, the Mini-USB Type-B console port becomes the active console port. The host machine
connected to the Mini-USB Type-B console port displays log messages and lets you control the CTP151 device functionality
through it.
Connect Interface Modules
To install a cable in an interface module:
1. Wrap and fasten one end of the ESD grounding strap around your wrist and connect the other end to a site ESD point.
2. For the T1/E1 interface module, slide the cable as far as you can into the T1/E1 interface module until it clicks into
place.
For the serial/multiservice interface module, push the serial HD-26 cable into the module, and tighten the thumb
screws.
3. Gently pull the cable to confirm that it is inserted correctly.
9
