Access the Device Using HyperTerminal
You can use the HyperTerminal application to access the device console. Before you begin connecting a CTP151 device
to a console management device, you must ensure that the HyperTerminal properties of the serial port on the console
management device are set as follows:
Baud rate—9600
Flow control—None
Data—8
Parity—None
Stop bits—1
DCD state—Disregard
Power On and Perform Initial Configuration
CAUTION:
rack.
To power on the device:
1. Verify that the power source is operational.
2. Inspect all grounding and power connections to the device chassis.
3. Confirm that all cable connections are secure.
4. Switch any available power switches to ON.
5. Monitor the console to verify that the device is booting up properly.
The device goes through a boot process. When a prompt appears on the console, the device is ready to be configured.
If the device is new, it boots to a first boot script. If the device is already operational, it boots to a login prompt.
The CTP151 device is delivered with the CTPOS software preinstalled on the internal SSD. If the CTPOS software
preinstalled on your device is corrupted, you can use a USB storage device to load the CTPOS software on the internal
SSD.
To bring up the CTP151 device with CTPOS on the internal SSD using a USB storage device:
Evaluate the overall loading of the branch circuit before you install any equipment into a
10
