Juniper CTP151 Platform Quick Start Manual page 11

1. Download and copy the CTPOS software USB installation image to a USB storage device.
2. Insert the USB storage device to the CTP151 chassis, power on the CTP151 device, and monitor the console.
3. Press the Del key to open the BIOS menu.
4. Select the Boot tab and make the first boot device the one that includes "UEFI" and "Flash" in the name, which indicates
that it is the USB install media.
5. Save the configuration and exit the setup.
The device goes through a boot process, and then the CTPOS USB installation menu opens.
6. Select a destination disk (the internal SSD on the CTP151), and then verify the installation selections.
7. Enter y to continue with the CTPOS software installation.
8. Enter y to reboot the system.
9. After the system reboots, go back to the BIOS menu and change the first boot device to the one that includes "UEFI
OS (P5: SFSA20...".
10. Save the configuration and exit the BIOS menu.
For the first-time boot process, there is a series of login prompts that require the following settings:
You must provide a password for the root account. The ctp and ctp_cmd accounts have default passwords. The default
password for the ctp user account is "ctp", and the default password for the ctp_cmd user account is "ctp_cmd". You
can change the default passwords later.
Supported protocol or protocols—(0) IPv4 only, (1) IPv6 only, or (2) IPv4 and IPv6. Enter the appropriate number value.
Default interface—From the list of available devices, such as eth0 and eth1 (or more), enter the name of the interface
that you want to set as the default.
Hostname of the device.
IP address of the interface—Enter the IP address of the selected interface, or accept the loopback address (127.0.0.1)
as the default.
Netmask of the IP address—Enter the netmask (such as 255.255.255.128), or accept 255.255.255.0 as the default.
Gateway IP address—Enter the IP address of the gateway, or accept the local address (127.0.0.1) as the default.
