3 Select the input directory next to the
Available Software window.
/CDROM/dist
If you install the operating system
from a location other than the CD-
ROM drive, change this accordingly.
4 Click Customize Installation.
5 A list of all installed and available OS
modules appears. Scroll down to IRIX
6.2 Execution Environment and
expand the folder.
6 Scroll down to Optional Input Devices ,
highlight the entry and click Start .

Product Specifications

Feature/Specification
Contactless, wearless, high-linear measuring system
Operating speed levels (increments of resolution)
Number of freely programmable buttons
Software-controllable keyboard LEDs
Quicktip virtual button
Device weight (for stability)
Min. releasing force of the measuring system
Max. user force of the measuring system
Ratio of device weight to min. releasing force
Ratio of device weight to max. user force
Device weight deficit w.r.t. max. user force
Counter force to compensate max. user force
Min. releasing torque of the device
Max. user torque of the device
Customization of user force
Customizable keyboard template
Operating humidity (non-condensing)
Operating temperature
Storage humidity
Storage temperature
Gravity height of work center
Dialbox simulation
LPFK simulation
Dominant Mode
7 This starts the installation process
whereby the following file is installed:
/usr/lib/X11/input/dial.o
8 After rebooting, reinstall the X-Window
driver, this time using the -installlpfk
command.
./xdriver -new -global -installlpfk
9 To test the installation, start the X-
Window driver and from the System
menu select Run Confidence Test .
Click on Dials and Buttons . You should
now be able to manipulate the dials
and the buttons with the Magellan/
SPACE MOUSE device.
Magellan/ Magellan/
SPACE MOUSE SPACE MOUSE
Classic
Yes
600
9
No
Yes
0.665 kg
0.2 N
4.4 N
33.2
1.5
0 %
0 N
4 N mm
100 N mm 100 N mm
Possible
Yes
10 to 98% RH 10 to 98% RH
+5 to +60 °C +5 to +60 °C
10 to 98% RH 10 to 98% RH
-40 to +85 °C -40 to +85 °C
25 mm
Yes 100% Yes 100%
Yes 100% Yes 100 %
Yes
23
Magellan/
SPACE MOUSE
Plus Plus XT
Yes Yes
600 600
11 11
No Yes
(2 yellow, 1 red)
Yes Yes
0.680 kg 0.680 kg
0.2 N 0.2 N
4.4 N 4.4 N
33.2 33.2
1.5 1.5
0 % 0 %
0 N 0 N
4 N mm 4 N mm
100 N mm
Possible Possible
Yes Yes
10 to 98% RH
+5 to +60 °C
10 to 98% RH
-40 to +85 °C
26 mm 26 mm
Yes 100%
Yes 100 %
Yes Yes
