KA01206G/00/EN/02.17
71364766
Products
Brief Operating Instructions
Proservo NMS83
Tank Gauging
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
– Internet:
www.endress.com/deviceviewer
– Smart phone/tablet: Endress+Hauser Operations App
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Proservo NMS83

Summary of Contents for Endress+Hauser Proservo NMS83

  • Page 1 Operating Instructions pertaining to the device. Detailed information about the device can be found in the Operating Instructions and the other documentation: Available for all device versions via: – Internet: www.endress.com/deviceviewer – Smart phone/tablet: Endress+Hauser Operations App...
  • Page 2 Proservo NMS83 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...

  • Page 3: Table Of Contents

    Proservo NMS83 Table of contents Table of contents About this document ............. . 4 Symbols .

  • Page 4: About This Document

    About this document Proservo NMS83 About this document Symbols 1.1.1 Safety symbols Symbol Meaning DANGER! This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in DANGER serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in WARNING serious or fatal injury.
  • Page 5 Proservo NMS83 About this document 1.1.4 Symbols for certain types of information Symbol Meaning Symbol Meaning Permitted Preferred Procedures, processes or actions that Procedures, processes or actions that are permitted. are preferred. Forbidden Procedures, processes or actions that Indicates additional information.

  • Page 6: Basic Safety Instructions

    Basic safety instructions Proservo NMS83 Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣ Are authorized by the plant owner/operator.

  • Page 7: Operational Safety

    The measuring system meets the legal requirements of the applicable EC guidelines. These are listed in the corresponding EC Declaration of Conformity together with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. Endress+Hauser...

  • Page 8: Product Description

    Product description Proservo NMS83 Product description Product design A0028873  1 Configuration of NMS83 Front cover Display Modules Sensor unit Housing Wire drum Bracket Housing cover Displacer Endress+Hauser...

  • Page 9: Incoming Acceptance And Product Identification

    ): All information about the measuring device is displayed. • Enter the serial number from the nameplates into the Endress+Hauser Operations App or scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations App: all the information for the measuring device is displayed.
  • Page 10 Incoming acceptance and product identification Proservo NMS83 4.3.2 Transport NOTICE Risk of injury ‣ Transport the measuring device to the measuring point in its original packaging. ‣ Take into account the mass center of the device in order to avoid unintended tilting.

  • Page 11: Installation

    Proservo NMS83 Installation Installation Requirements 5.1.1 Alignment of NMS8x Flange Confirm that the size of the nozzle and the flange is matched prior to mounting NMS8x on the tank. The flange size and the rating of NMS8x vary depending on the customer’s specifications.
  • Page 12 Installation Proservo NMS83 -90° 90° -45° 45° 0° ≥500 (19.69) A0026890  3 Recommended position for mounting NMS8x and minimum measuring level; dimensions mm (in) Inlet pipe Tank nozzle • Before pouring liquid into the tank, confirm that liquid flowing through the inlet of the pipe will not contact the displacer directly.

  • Page 13: Mounting Of The Device

    Proservo NMS83 Installation 5.1.2 Electrostatic charge When liquid measured by NMS8x has a conductivity of 1 uS/m or less, it is quasi- nonconductive. In this case, using a stilling well or guide wire is recommended. This releases the electrostatic charge on the liquid surface.
  • Page 14 Installation Proservo NMS83 5.2.2 Verification of displacer and wire drum Prior to installation of NMS8x, confirm that the serial numbers of displacer and the wire drum match with those printed to the label attached on the housing. Ser.no.: 98765432109 Spare part-no.: 712xxxxx Range Cir.
  • Page 15 Proservo NMS83 Installation Use blocks or a pedestal to secure NMS8x and provide an environment where electrical power can be supplied to NMS8x. The following procedure uses NMS81 figures for an example. Figures Procedures Secure NMS8x on the blocks or pedestal.
  • Page 16 Installation Proservo NMS83 Figures Procedures Hook the displacer [3] on the ring [2].  • Be sure that the wire is wound correctly in the grooves. • If not, remove the displacer and the wire drum, and repeat step 7.
  • Page 17 Proservo NMS83 Installation Figures Procedures Perform drum calibration.  For drum calibration, →  46 5.2.4 Installation through the calibration window In the case of a 50 mm (1.97 in) diameter displacer, the displacer can be installed through the calibration window.
  • Page 18 Installation Proservo NMS83 Figures Procedures Holding the wire drum [1] with one hand, unwind the measuring wire [3] approximately 500 mm (19.69 in). Secure the wire [3] temporarily with the tape [2]. Insert the wire ring [4] into the drum housing.
  • Page 19 Proservo NMS83 Installation Figures Procedures Let go of the displacer [2]. Remove the tape from the wire drum [5]. Insert the wire drum into the drum housing. Mount the bracket [4].  Be sure that the wire is wrapped correctly in grooves.

  • Page 20: Electrical Connection

    Electrical connection Proservo NMS83 Electrical connection Terminal assignment POWER POWER G1 N AC 85...264 V G3 L A0032445  5 Terminal compartment (typical example) and ground terminals Terminal area Module Up to four I/O modules, depending on the order code •...
  • Page 21 Proservo NMS83 Electrical connection 6.1.1 Power supply POWER POWER G1 N AC 85...264 V A0033413 not connected Green LED: indicates power supply Supply voltage 85 to 264 V , 50/60 Hz, 28.8 VA The supply voltage is also indicated on the nameplate.
  • Page 22 Electrical connection Proservo NMS83 6.1.2 HART Ex i/IS interface POWER A0033414 Orange LED: indicates data communication This interface always operates as the main HART master for connected HART slave transmitters. The Analog I/O modules, on the other hand, can be configured as a HART master or slave →...
  • Page 23 Proservo NMS83 Electrical connection 6.1.3 Slots for I/O modules The terminal compartment contains four slots (A, B, C and D) for I/O modules. Depending on the device version (ordering features 040, 050 and 060) these slots contain different I/O modules. The slot assignment for the device at hand is indicated on a label attached to the back cover of the display module.
  • Page 24 Electrical connection Proservo NMS83 6.1.4 Terminals of the "Modbus" or "V1" module 1 2 3 4 D1-4 1 2 3 4 POWER A1-4 A0031200  6 Designation of the "Modbus" or "V1" modules (examples); depending on the device version these modules may also be in slot B or C.
  • Page 25 Proservo NMS83 Electrical connection Terminals of the "V1" module Terminal Name Description Cable shielding connected via capacitor to EARTH not connected Protocol loop signal - Protocol loop signal + Designation of the module in the operating menu: V1 X1-4; (X = A, B, C or D) In this column, "X"...
  • Page 26 Electrical connection Proservo NMS83 6.1.5 Connection of the "Analog I/O" module for passive usage • In the passive usage the supply voltage for the communication line must be supplied by an external source. • The wiring must be in accordance with the intended operating mode of the Analog I/O module;...
  • Page 27 Proservo NMS83 Electrical connection "Operating mode" = "4..20mA input" or "HART master+4..20mA input" POWER POWER – A0027933  8 Passive usage of the Analog I/O module in the input mode Power supply External device with 4...20mA and/or HART signal output...
  • Page 28 Electrical connection Proservo NMS83 "Operating mode" = "HART master" POWER POWER – A0027934  9 Passive usage of the Analog I/O module in the HART master mode Power supply Up to 6 external devices with HART signal output Endress+Hauser...
  • Page 29 Proservo NMS83 Electrical connection 6.1.6 Connection of the "Analog I/O" module for active usage • In the active usage the supply voltage for the communication line is supplied by the device itself. There is no need of an external power supply.
  • Page 30 Electrical connection Proservo NMS83 "Operating mode" = "4..20mA input" or "HART master+4..20mA input" POWER POWER A0027935  11 Active usage of the Analog I/O module in the input mode External device with 4...20mA and/or HART signal output Endress+Hauser...
  • Page 31 Proservo NMS83 Electrical connection "Operating mode" = "HART master" POWER POWER A0027936  12 Active usage of the Analog I/O module in the HART master mode Up to 6 external devices with HART signal output The maximum current consumption for the connected HART devices is 24 mA (i.e. 4 mA per device if 6 devices are connected).
  • Page 32 Electrical connection Proservo NMS83 6.1.8 Terminals of the "Digital I/O" module 1 2 3 4 5 6 7 C1-2 C3-4 1 2 3 4 POWER A1-2 A3-4 A0026424  13 Designation of the digital inputs or outputs (examples) • Each Digital IO Module provides two digital inputs or outputs.

  • Page 33: Connecting Requirements

    Proservo NMS83 Electrical connection Connecting requirements 6.2.1 Cable specification Terminals Terminal Wire cross section Signal and power supply 0.2 to 2.5 mm (24 to 13 AWG) • Spring terminals (NMx8x-xx1...) • Screw terminals (NMx8x-xx2...) Ground terminal in the terminal compartment max.

  • Page 34: Ensuring The Degree Of Protection

    Electrical connection Proservo NMS83 Ensuring the degree of protection To guarantee the specified degree of protection, carry out the following steps after the electrical connection: Check that the housing seals are clean and fitted correctly. Dry, clean or replace the seals if necessary.

  • Page 35: Commissioning

    Proservo NMS83 Commissioning Commissioning Operating methods 7.1.1 Operation via the local display A0028345  14 Display and operating elements Liquid crystal display (LCD) Optical keys; can be operated through the cover glass. Endress+Hauser...
  • Page 36 Commissioning Proservo NMS83 Standard view (measured value display) X X X X X X X 4841.00 Level bal. A0028702  15 Typical appearance of the standard view (measured value display) Display module Device tag Status area Display area for measured values...
  • Page 37 Proservo NMS83 Commissioning 7.1.2 Operation via service interface and FieldCare/DeviceCare A0028871  17 Operation via service interface Service interface (CDI = Endress+Hauser Common Data Interface) Commubox FXA291 Computer with "FieldCare" operating tool and "CDI Communication FXA291" COM DTM Endress+Hauser...

  • Page 38: Terms Related To Tank Measurement

    Commissioning Proservo NMS83 Terms related to tank measurement A0033283  18 Terms concerning NMS8x installation (e.g. NMS81) Liquid level Upper interface Lower interface Gas phase Upper phase Middle phase Endress+Hauser...

  • Page 39: Setting The Display Language

    Proservo NMS83 Commissioning Lower phase Tank bottom Gauge reference height Empty Datum plate Tank ullage Tank level Tank reference height High stop level Displacer position Standby level Upper interface level Lower interface level Low stop level Dipping reference Mechanical stop...

  • Page 40: Calibration

    Commissioning Proservo NMS83 Calibration After installing or replacing NMS8x or its parts (sensor module, detector unit, wire drum, or measuring wire), several calibration steps are required. All calibration steps may not be required, depending on whether the device is being installed, adjusted, or replaced (see table below).
  • Page 41 Proservo NMS83 Commissioning Data verification Data verification procedure Check the displacer diameter, weight, volume, and balance volume for the Displacer diameter parameter, the Displacer weight parameter, the Displacer volume parameter, and the Displacer balance volume parameter. Check the drum circumference and wire weight for the Drum circumference parameter and Wire weight parameter.
  • Page 42 Commissioning Proservo NMS83 A0027996  19 Move displacer Endress+Hauser...
  • Page 43 Proservo NMS83 Commissioning 7.4.3 Sensor calibration Sensor calibration adjusts the weight measurement of the detector unit. The calibration consists of three steps as follows. • ADC zero calibration • ADC offset calibration • ADC span calibration For the ADC offset weight calibration, either 0 g or an offset weight (0 to 100 g) can be used.
  • Page 44 Commissioning Proservo NMS83 Calibration procedure Step Using displacer Using offset weight Description • Navigate to: Setup → Calibration → Sensor calibration → Sensor calibration • Input the offset weight for the Offset weight parameter used in step 3 (0.0 g in case of using the displacer only).
  • Page 45 Proservo NMS83 Commissioning 7.4.4 Reference calibration The reference calibration defines the zero distance position of the displacer from the mechanical stop. Navigate to: Setup → Calibration → Reference calibration → Reference calibration Select the Start option Check the reference position (e.g. 70 mm (2.76 in)).
  • Page 46 Commissioning Proservo NMS83 7.4.5 Drum calibration Navigate to: Setup → Calibration → Drum calibration → Drum calibration Ensure a distance of 500 mm (19.69 in) or more from the bottom of the displacer to the liquid level. Confirm that the displacer weight is correct for the Set high weight parameter.
  • Page 47 Proservo NMS83 Commissioning 7.4.6 Commissioning check This procedure is to confirm that all calibration steps have been completed appropriately. Navigate to: Diagnostics → Device check → Commissioning check → Commissioning check Select the Start option.  Executing option is shown on the verify drum table.

  • Page 48: Configuration Of The Inputs

    Commissioning Proservo NMS83 Configuration of the inputs 7.5.1 Configuration of the HART inputs 1 2 3 4 5 6 7 8 C1-3 C4-8 1 2 3 4 5 6 7 8 POWER B1-3 B4-8 A0032955  23 Possible terminals for HART loops...
  • Page 49 Proservo NMS83 Commissioning 1) 2) Submenu: Setup → Advanced setup → Input/output → HART devices → HART Device(s) Parameter Meaning / Action Output pressure • If the device measures a pressure: Select which of the HART variables (PV, SV, TV or QV) contains the pressure.
  • Page 50 Commissioning Proservo NMS83 7.5.2 Configuration of the 4-20mA inputs 1 2 3 4 5 6 7 8 C1-3 C4-8 1 2 3 4 5 6 7 8 POWER B1-3 B4-8 A0032464  24 Possible locations of the Analog I/O modules, which can be used as a 4-20mA input. The order code of the device determines which of these modules is actually present.
  • Page 51 Proservo NMS83 Commissioning I [mA] 20mA 100% A0029264  25 Scaling of the 4-20mA input to the process variable Input value in mA Process value Endress+Hauser...
  • Page 52 Commissioning Proservo NMS83 7.5.3 Configuration of a connected RTD 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 C1-3 C4-8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...
  • Page 53 Proservo NMS83 Commissioning A0029269 Datum plate Probe position Endress+Hauser...
  • Page 54 Commissioning Proservo NMS83 7.5.4 Configuration of the digital inputs 1 2 3 4 5 6 7 C1-2 C3-4 1 2 3 4 POWER A1-2 A3-4 A0026424  27 Possible locations of the Digital I/O modules (examples); the order code defines the number and location of digial input modules.
  • Page 55 Proservo NMS83 Commissioning A0029262 "Operating mode" = "Input passive" "Operating mode" = "Input active" State of the external switch Internal state of the DIO module Contact type = Normally open Contact type = Normally closed Open Inactive Active Closed Active...

  • Page 56: Linking Measured Values To Tank Variables

    Commissioning Proservo NMS83 Linking measured values to tank variables Measured values must be linked to tank variables before they can be used in the Tank Gauging application. Depending on the application not all these parameters will be relevant in a given situation.

  • Page 57: Configuration Of The Limit Evaluation

    Proservo NMS83 Commissioning Configuration of the limit evaluation A limit evaluation can be configured for up to 4 tank variables. The limit evaluation generates an alarm if the value exceeds an upper limit or falls below a lower limit, respectively. The limit values can be defined by the user.
  • Page 58 Commissioning Proservo NMS83 To configure an alarm, assign appropriate values to the following parameters: Submenu: Setup → Advanced setup → Application → Alarm → Alarm 1 to 4 Parameter Meaning / Action Alarm mode • Off No alarms are generated.

  • Page 59: Configuration Of The Signal Output

    Proservo NMS83 Commissioning Configuration of the signal output 7.8.1 Analog output (4...20mA) 1 2 3 4 5 6 7 8 C1-3 C4-8 1 2 3 4 5 6 7 8 POWER B1-3 B4-8 A0032464  29 Possible locations of the Analog I/O modules, which can be used as an analog output. The order code of the device determines which of these modules is actually present.
  • Page 60 Commissioning Proservo NMS83 7.8.2 HART output This section is only valid for Operating mode = HART slave +4..20mA output. Setup → Advanced setup → Communication → HART output → Configuration Parameter Meaning / Action System polling address Set the HART communication address of the device.
  • Page 61 Proservo NMS83 Commissioning 7.8.3 Modbus or V1 output 1 2 3 4 D1-4 1 2 3 4 POWER A1-4 A0031200  30 Possible locations of the Modbus or V1 modules (examples); depending on the device version these modules may also be in slot B or C .
