Summary of Contents for Multitech Conduit MTCDT-L4E1
- Page 1 ® Conduit Cat 4 for EU/UK MTCDT-L4E1 Hardware Guide...
- Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
-
Page 3: Table Of Contents
CONTENTS Contents Chapter 1 – Product Overview ..........................5 Introduction .................................. 5 Documentation ................................5 Product Kit Contents ..............................6 Product Build Options ..............................6 Chapter 2 – Specifications............................8 MTCDT-L4E1 Specifications............................8 Mechanical Drawing..............................10 Backpanel Connectors ..............................11 LED Descriptions ................................. - Page 4 CONTENTS Device Maintenance ..............................22 Vehicle Safety................................22 Notice regarding Compliance with FCC, EU, and Industry Canada Requirements for RF Exposure......22 Radio Frequency (RF) Safety ............................23 Sécurité relative aux appareils à radiofréquence (RF)....................23 Interference with Pacemakers and Other Medical Devices ..................24 Potential interference ...............................
-
Page 5: Chapter 1 - Product Overview
(M2M) connectivity using various wireless interfaces. It also provides an online application store for industrial things as a platform for developers to provision and manage their gateway and associated sensors and devices. Documentation The following documentation is available at https://www.multitech.com/brands/multiconnect-conduit. Document Description Part Number... -
Page 6: Product Kit Contents
PRODUCT OVERVIEW Product Kit Contents Your Product Kit includes the following (varies with model): Device 1 - MTCDT-Conduit Power Supply 1 - 100-240V 9V-1.7A power supply with removable blades 1 - NAM blade/plug 1 - EURO blade/plug 1 - UK blade/plug Cables 1 - Micro USB Cable 1 - Ethernet Cable RJ45 6-ft. - Page 7 PRODUCT OVERVIEW Product Description Region MTCDT-L4E1-247L-EU-GB LTE Category 4 mLinux Programmable Gateway w/ GNSS, WiFi/BT, EU/UK and EU/UK Accessory Kit MTCDT-L4E1-246L-EU-GB LTE Category 4 mLinux Programmable Gateway, w/ GNSS and EU/UK US/EU/UK Accessory Kit MTCDT-L4E1-240L-EU-GB LTE Category 4 mLinux Programmable Gateway w/ US/EU/UK EU/UK Accessory Kit Note:...
-
Page 8: Chapter 2 - Specifications
SPECIFICATIONS Chapter 2 – Specifications MTCDT-L4E1 Specifications Category Description General Performance LTE FDD Cat. 4, 3GPP release 10 HSPA+ with GPRS fallback Frequency Bands (MHz) 4G LTE: B3(1800), B7(2600), B20(800), B1(2100), B8(900), B28A (700) 3G: B1(2100), B3(1800), B8(900) 2G: B3(1800), B8(900) Cellular radio module Telit LE910C4-EU Cellular packet data... - Page 9 SPECIFICATIONS Category Description Certifications Radio & EMC Compliance CE Mark, RED (EU) Safety Compliance IEC60950-1(EU) Telecom Approvals EU carriers UL Listed @ 40° C, limited by AC power supply. UL Recognized @ 65° C for Conduit LTE devices within IP67 enclosure or when used with the fused DC power cable, part number FPC-532-DC.
-
Page 10: Mechanical Drawing
SPECIFICATIONS Mechanical Drawing ® Conduit Cat 4 for EU/UK MTCDT-L4E1 Hardware Guide... -
Page 11: Backpanel Connectors
AUX - Diversity. AP1, AP2 Slots for MultiTech accessory cards. You can install an accessory card in either slot. Both slots can be occupied at one time. An exception is an SDIO (Secure Digital Input/Output) card, which can be used only in the AP1 slot. -
Page 12: Led Descriptions
SPECIFICATIONS LED Descriptions Conduit mLinux Model Front Panel Conduit Application Model Front Panel Label Name Description Power Solid (constant) green if unit is on indicating that DC power is present. STATUS Power Status Default condition: LED blinks when mLinux is fully loaded. Link Status Varies with radio model. -
Page 13: Chapter 3 - Power Draw
POWER DRAW Chapter 3 – Power Draw Power Draw MTCDT-L4E1-247A with Modem and No Accessory Cards Radio Protocol Cellular Connection Measured Current at TX Pulse (AVG) Total Inrush Charge no data (mA) Max Power (mA) Amplitude Current (mC) for GSM850 or Peak Current (mA) 9.0 Volts eGSM 900 MHz... -
Page 14: Chapter 4 - Antenna Information
ANTENNA INFORMATION Chapter 4 – Antenna Information Wieson Antenna Devices were approved with the following antenna: Manufacturer: Wieson Description: LTE GY115HT467-017 Model Number: 11320Y11194A1 MultiTech ordering information: Model Quantity ANLTE2-2HRA ANLTE2-10HRA ANLTE2-50HRA Antenna Specifications Category Description Frequency Range .069~0.96GHz, 1.71~2.17GHz, 2.3GHz~2.69GHz... -
Page 15: Chapter 5 - Frequency Information
FREQUENCY INFORMATION Chapter 5 – Frequency Information Frequency Bands for Conduit Cellular Radio Frequencies LE910C4-EU 2G: B3(1800), B8(900), 3G: B1(2100), B3(1800), B8(900), 4G: B3(1800), B7(2600), B20(800), L4E1 B1(2100), B8(900), B28A(700) Frequency and Power Information for WiFi/Bluetooth Operating Frequency RF Output Power 802.11b: 2400 MHz –... -
Page 16: Chapter 6 - Setting Up And Configuring The Device
Gently push the new SIM card into SIM card holder face up with the cut corner to the right and the SIM contacts facing toward the Conduit’s interior. If not installing a battery or micro SD card, reattach the MultiTech nameplate to the Conduit using the screw removed in Step 2. -
Page 17: Accessory Port (Mcard) Interfaces
Disconnect power to the Conduit, if it is connected. At the front of the Conduit, remove the screw that secures the MultiTech nameplate. Locate the SD card at the left side of the opening on the underside of the PC board. -
Page 18: Installing A Battery
To install or replace the battery: If connected, disconnect power to the Conduit. At the front of the Conduit housing, remove the screw that secures the MultiTech nameplate to the housing. The battery holder is located at the right side of the opening on the underside of the PC board. To remove an existing battery, use non-metal tweezers as necessary. -
Page 19: Connecting To The Debug Interface
To connect the debug cable: Disconnect power to the Conduit, if it is connected. At the front of the Conduit housing, remove the screw that secures the MultiTech nameplate to the housing. Locate the USB debug cable connector in the center of the opening. -
Page 20: Resetting The Device
To power up the device: Install the desired MultiTech accessory card or cards into the slots at the back of the device. Refer to the appropriate installation documentation for the accessory card. Connect the power cord to an outlet or power strip and to the power adapter. -
Page 21: Chapter 7 - Regulatory & Safety Information
This battery has an estimated life expectancy of ten years. When this battery starts to weaken, the date and time may be incorrect. Battery is not user replaceable. If the battery fails, the device must be sent back to MultiTech Systems for battery replacement. -
Page 22: Device Maintenance
Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty. -
Page 23: Radio Frequency (Rf) Safety
REGULATORY & SAFETY INFORMATION structures (the antenna) and the body of users. Qualification for distances closer than 20 cm (portable operation) would require re-certification. Wireless devices could generate radiation. Other nearby electronic devices, like microwave ovens, may also generate additional radiation to the user causing a higher level of RF exposure. Radio Frequency (RF) Safety Due to the possibility of radio frequency (RF) interference, it is important that you follow any special regulations regarding the use of radio equipment. -
Page 24: Interference With Pacemakers And Other Medical Devices
REGULATORY & SAFETY INFORMATION Interference with Pacemakers and Other Medical Devices Potential interference Radio frequency energy (RF) from cellular devices can interact with some electronic devices. This is electromagnetic interference (EMI). The FDA helped develop a detailed test method to measure EMI of implanted cardiac pacemakers and defibrillators from cellular devices. -
Page 25: Chapter 8 - Environmental Notices
Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements. -
Page 26: Reach Statement
ENVIRONMENTAL NOTICES Polybrominated Diphenyl Ethers, [PBDE] < 1000 PPM Bis(2-Ethylhexyl) phthalate (DEHP): < 1000 ppm Benzyl butyl phthalate (BBP): < 1000 ppm Dibutyl phthalate (DBP): < 1000 ppm Diisobutyl phthalate (DIBP): < 1000 ppm Environmental considerations: Moisture Sensitivity Level (MSL) =1 Maximum Soldering temperature = 260C (in SMT reflow oven) Lead usage in some components is exempted by the following RoHS annex, therefore higher lead concentration would be found in some modules (>1000 PPM);... -
Page 27: Information On Hs/Ts Substances According To Chinese Standards (In Chinese)
ENVIRONMENTAL NOTICES Information on HS/TS Substances According to Chinese Standards (in Chinese) 依 依 照 照 中 中 国 国 标 标 准 准 的 的 有 有 毒 毒 有 有 害 害 物 物 质 质 信 信 息 息 根据中华人民共和国信息产业部... -
Page 28: Information On Hs/Ts Substances According To Chinese Standards
ENVIRONMENTAL NOTICES Information on HS/TS Substances According to Chinese Standards In accordance with China's Administrative Measures on the Control of Pollution Caused by Electronic Information Products (EIP) # 39, also known as China RoHS, the following information is provided regarding the names and concentration levels of Toxic Substances (TS) or Hazardous Substances (HS) which may be contained in Multi-Tech Systems Inc.
