Schwinn IC4 Assembly Manual / Owner's Manual page 26

Condition/Problem
Console shuts off (enters
sleep mode) while in use
Unit rocks/does not sit
level
Pedals loose/unit difficult
to pedal/ Pedals seem to
skip or slip with a sudden
increase in rpm
Clicking sound when
pedaling
Seat post movement
26
Things to Check
Check electrical (wall)
outlet
Check connection at front
of unit
Check data cable integrity
Check data cable
connections/orientation
Reset machine
Check magnet position
(requires shroud removal)
Check Speed Sensor
(requires shroud removal)
Check level adjustment
Check surface under unit
Check pedal to crank
connection
Check crank arm to axle
connection
Check drive belt tension
Check pedal to crank
connection
Check locking pin
Check locking knob
Make sure unit is plugged into a functioning wall outlet.
Connection should be secure and undamaged. Replace
adapter or connection at unit if either are damaged.
All wires in the cable should be intact. If any are cut or crimped,
replace cable.
Be sure cable is connected securely and oriented properly.
Small latch on connector should line up and snap into place.
Unplug unit from electrical outlet for 3 minutes. Reconnect to
outlet.
Magnet should be in place on pulley.
Speed sensor should be aligned with magnet and connected to
data cable. Realign sensor if necessary. Replace if there is any
damage to the sensor or the connecting wire.
Contact Customer Service (if inside US/Canada) or your local
distributor (if outside US/Canada).
Levelers may be turned to level machine.
Adjustment may not be able to compensate for extremely un-
even surfaces. Move machine to level area.
Pedal should be tightened securely to crank arm. Be sure con-
nection is not cross-threaded.
Crank arm should be tightened securely to axle.
Refer to the "Adjust the Belt Tension" procedure in the Service
Manual. Contact Customer Service (if inside US/Canada) or
your local distributor (if outside US/Canada).
Remove pedals. Make sure there is no debris on threads, and
reinstall the pedals.
Be sure adjustment pin is locked into one of the seat post
adjustment holes.
Be sure knob is securely tightened.
Solution
