5.3 Overview Components

5.3.1 Overview seating system

Modulite seat (example)
A Backrest, see chapter 5.3.2 Backrest styles, page 15
B
Armrest, see chapter 5.3.4 Armrest styles, page 16
C
Cushion
D
Seat surface, see chapter 5.3.7 Seat frame and surface, page 19
E
Seat frame, see chapter 5.3.7 Seat frame and surface, page 19
F Chassis and interface, see chapter 5.3.8 Overview seat interfaces, page 19
G/ H Remote holder / remote holder for attendant, headrest adapters, see chapter 5.3.5 Remote Brackets and
Headrest Adapters, page 16

5.3.2 Backrest styles

Modulite seat is available with different backrest styles.
Tension adjustable

5.3.3 Backrest frames

Modulite is available with different backrest frames. For remote brackets that can be mounted to the backrest, see
5.3.5 Remote Brackets and Headrest Adapters, page 16.
1604311-G
Flex 3 backrest plates Flex 3 Tension Adjustable
