Remotes for users

Standard with support tube

Remotes for the wheelchair user are mounted at a slot at the armrest or on nucleus midline holder.

Modulite with nucleus midline holder can carry additional brackets, remotes and switches. An adapter is needed to mount

nucleus midline holder to slot at the armrest. See 5.8.1 Replacing Nucleus Midline Holder, page 25.

Nucleus midline holder

With Modulite seat system the following components can be mounted to nucleus midline holder:

1604311-G

Standard with swing away armrest

REM500 swing-away display holder
