Rinnai Linear Series Operation Manual
Hide thumbs
Also See for Linear Series:
- Installation manual (48 pages) ,
- Flue installation manual (20 pages)
Related Manuals for Rinnai Linear Series
Summary of Contents for Rinnai Linear Series
- Page 1 Operation guide Linear collection Gas fires, like cars, require regular maintenance and servicing. For reliable operation Rinnai gas fires should be serviced every two years, including inspection of the flue system.
- Page 2 Important Appliance must be installed with a Rinnai approved flue system. This appliance must be installed in accordance with: - Manufacturer’s installation instructions - AS/NZS 5601 Gas Installations - AS/NZS 5263 Gas appliances standards For use with Natural Gas or Universal LPG as indicated on the appliance.
-
Page 3: Table Of Contents
Contents Safety ..............4 General information ..........5 About your Rinnai Linear gas fire ......6 Operation using your remote ........8 Operation using the Wi-Fi app ......10 Clearances from combustibles ......11 Mantels and surrounds .........12 Abnormal flame pattern ........13 Error codes ............14 Troubleshooting ............16 Installation checklist and installer details ....18... -
Page 4: Safety
Most must be replaced by a licensed contain butane gas which can tradesperson. This must be be a fire hazard if used near the a genuine replacement part appliance. available from Rinnai. 4 | Linear operation guide: 13562-B 02-19... -
Page 5: General Information
General information Before operation please read these instructions to get an overview of how to operate, maintain and service your Rinnai gas fire. Electrical connection Environmental The Linear is fitted with a 1.5 m power cord The Rinnai Linear is and 3-pin plug. -
Page 6: About Your Rinnai Linear Gas Fire
About your Rinnai Linear gas fire Congratulations on the purchase of your Rinnai Linear gas fire. We hope you love this product as much as we do, and on the off chance that something does go wrong, or if you need help, we’re only a phone call away. - Page 7 Reset heater, press the On/Off button at the fireplace twice. Position of your Rinnai Linear on a wall If installing the Linear up the wall in an elevated position, air from the convection fan, depending on the room configuration, could create draughts. This needs to be factored when determining the location of the fire.
-
Page 8: Operation Using Your Remote
Operation using the remote For the remote control functions to be available, the appliance On/Off button must be in the On position. Signal transmission to the unit Changing the batteries The unit will beep and flash to confirm the • Remove the back settings have been received from the remote. - Page 9 Turning on and off This button switches the fire on and off. For it to work the power button on the fire must be ON. Flame and heat setting Once the fire is turned on the flame setting defaults to level five (on high).
-
Page 10: Operation Using The Wi-Fi App
For more information about how to use the Rinnai Wi-Fi app, refer to the ‘Wi-Fi control user guide’ available on the Rinnai website, www.rinnai.co.nz, enter Wi-Fi user guide in the search field. -
Page 11: Clearances From Combustibles
Some television manufacturers have warranty conditions that state a television is not to be installed above a fireplace. For further information, please contact Rinnai or refer to the installation guide, which includes a TV installation diagram. -
Page 12: Mantels And Surrounds
Mantels and surrounds Combustible mantels and surrounds require clearance from the unit to minimise the risk of fire. Mantels and surrounds, made of combustible materials such as wood, are allowed providing they are outside the minimum clearances shown. B - mantel depth Mantel needs to be a minimum of 400 mm away from the edge of the glass Maximum mantel depth at 400 mm (A) is 250 mm maximum Surround needs to be a minimum of 400 mm away from the edge of the glass... -
Page 13: Abnormal Flame Pattern
Abnormal flame pattern Each Rinnai flame fire has a distinct flame pattern, refer images below. This should look the same every time you start your fire, after an initial warm up period of approximately 20 minutes. Abnormal flame performance and/or pattern can indicate a problem with your fire, such as blocked gas injectors, or shifting of burn media. -
Page 14: Error Codes
Reset the Wi-Fi module in the fire. between the main PCB and Wi-Fi module Communication error detected Check your Wi-Fi and Rinnai Wi-Fi module are between Smart device and Wi-Fi within range. Check network settings. module 14 | Linear operation guide: 13562-B 02-19... - Page 15 If you think your problem is Wi-Fi related, please lookup/download the Wi-Fi user guide available on the Rinnai website, enter Wi-Fi user guide in the search field. There may be a requirement for you to reset the Wi-Fi module in the fire. To do this for the Linear make sure the fire is on: 1.
-
Page 16: Troubleshooting
If you are still unsure or concerned after reading this section, please contact Rinnai on 0800 746 624. During installation there will be an initial burning in period where some smoke and smell may be experienced, this could last for a couple of hours—... - Page 17 Possible error codes* on remote when batteries are activated or changed: F1 displays on remote Assembly fault, remote will not respond to movement—accelerometer not communicating with the main processor correctly. Contact Rinnai. F2 displays on remote Room temperature outside 5-45 °C, or temperature sensing circuit has failed, which may indicate an assembly fault.
-
Page 18: Installation Checklist And Installer Details
Checklist F Appliance positioned in a suitable location (clearances, mantels, surrounds, cavity ventilation). F Rinnai flue system installed and tested to ensure effective draw. F Gas pressure checked and set according to the data plate. F Burn media installed as per instructions. -
Page 19: Limited Warranty
Rinnai brings you peace of mind with a: 5-year firebox warranty This warranty is applicable to all Rinnai Linear collection models. All terms of the warranty, subject to the conditions below, are effective from the date of first installation. The attending service person reserves the right to verify this by requesting a copy of the certificate of compliance prior to commencement of any warranty work. - Page 20 8. Rinnai reserves the right to have installed product returned to the factory for inspection. 9. Where the gas fire is installed outside the metropolitan area or further than 40 km from a Rinnai authorised service centre, travel costs shall be the owner’s responsibility.
-
Page 21: Purchase Details
Warranty claim To make a warranty claim, contact Rinnai on 0800 RINNAI (0800 746 624) or email info@rinnai.co.nz. Linear operation guide: 13562-B 02-19 | 21... -
Page 22: Appendix 1: Glass Cleaning
Appendix 1 Glass cleaning The inside of the glass, over a period of time, may develop some buildup and condensation marks. These can be removed using a soft microfibre cloth, never use solvents or abrasive chemicals. Do not attempt to clean the glass while the Linear is operating or is still hot. Before starting make sure the power to the fire is off and the glass is cool to touch. - Page 23 To remove the glass: 1. Using a screwdriver, loosen the three screws holding the louvre in place, remove the louvre, and then remove the screws (so the glass can come out)—put the louvre to one side. 2. Push the top glass retainer latches up and slightly to one side to release the top section of the glass.
- Page 24 Rinnai.co.nz 0800 746 624 http://www.youtube.com/rinnainz http://www.facebook.com/rinnainz Linear operation guide: 13562-B...
