FREESTANDING ROYALE ETR - FS35ETR
Customer Operation & Installation Manual
This appliance shall be installed in accordance with:
•
Manufacturers Installation Instructions
•
Local Gas Fitting Regulations
•
Municipal Building Codes
•
Installation code AS/NZS 5601 'Gas Installations'
•
Any other local relevant Statutory Regulation
Installation & Service must be performed by an authorised person.
This heater is NOT designed to be inbuilt.
This heater is not designed for use with Flexible Flueing.
All Rinnai gas products are
A.G.A. certified
INSTALLER: PLEASE LEAVE THIS MANUAL WITH THE END USER AFTER INSTALLATION
END USER: RETAIN THIS MANUAL FOR FUTURE REFERENCE
FLAME FIRE
ISO 9001 Lic 4983
SAI Global
Advertisement
Table of Contents
Related Manuals for Rinnai Royale FS35 ETR
Summary of Contents for Rinnai Royale FS35 ETR
- Page 1 This heater is NOT designed to be inbuilt. This heater is not designed for use with Flexible Flueing. ISO 9001 Lic 4983 All Rinnai gas products are SAI Global A.G.A. certified INSTALLER: PLEASE LEAVE THIS MANUAL WITH THE END USER AFTER INSTALLATION...
-
Page 2: Table Of Contents
INSTALLERS INFORMATION - LOG INSTALLATION..........17 INSTALLERS INFORMATION - TESTING & COMMISSIONING ......18 INSTALLERS INFORMATION - WIRING DIAGRAM..........19 INSTALLATION / COMMISSIONING CHECKLIST ...........20 INSTALLERS / GAS FITTER DETAILS ..............20 CUSTOMER INFORMATION - CONTACTS.............21 Royale - Freestanding ETR - ii - Issue 3 - ©Rinnai... -
Page 3: Customer Information - Control Panel
Temporarily changes operation from turns heat down to OFF. ON to OFF or OFF to ON, until next (Pilot only) programmed setting is reached. When OFF, Thermostat turns heat down to LOW. Royale - Freestanding ETR - 1 - Issue 3 - ©Rinnai... -
Page 4: Customer Information - Operation
If the appliance fails to ignite after 4 attempts, will turn the burners down to the OFF heat setting contact Rinnai as a service call may be required. when the selected temperature is reached. •... -
Page 5: Remote Control
If the Timer(s) have been selected, and the heater is in standby mode, and the OFF button on the Remote Control is pressed, the Timer(s) will be deactivated. Royale - Freestanding - ETR - 3 - Issue 3 - ©Rinnai... -
Page 6: Customer Information - Setting The Clock
Turn to the next page to operate the dual timer. The programmed time must be selected and locked-in within one minute of the On Timer indicators flashing otherwise the programmed times will not be retained in the system memory. Royale - Freestanding ETR - 4 - Issue 3 - ©Rinnai... -
Page 7: Operating The Timers
The temperature differential at the time of sensing the room governs how long before the program ON time the microcomputer will operate the heater and ignite the burner. Royale - Freestanding ETR - 5 - Issue 3 - ©Rinnai... -
Page 8: Customer Information - Safety Points
Do not spray aerosols whilst the heater is operating. Most aerosols contain butane gas, which can be a fire hazard if used near the heater when it is in use. Royale - Freestanding ETR - 6 - Issue 3 - ©Rinnai... - Page 9 Do not allow anyone to post articles through the louvres. Do not allow young children or the infirm to sleep directly in front of the heater. Royale - Freestanding ETR - 7 - Issue 3 - ©Rinnai...
- Page 10 Do not turn the heater off by unplugging it from the wall. Do not place containers of liquid on top of the heater. Liquid spillage can cause extensive damage to the appliance. Royale - Freestanding ETR - 8 - Issue 3 - ©Rinnai...
- Page 11 DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE. DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION. Royale - Freestanding ETR - 9 - Issue 3 - ©Rinnai...
-
Page 12: Customer Information - Trouble Shooting
See Error Messages on Page Control Panel • NOTE: If you have any other faults or problems, please refer to your installer or a Rinnai Customer Care Centre Consultant on 1300 555 545. • IMPORTANT: Do not remove any panels or attempt to carry out any service work other than that mentioned in the trouble shooting chart. -
Page 13: Customer Information - Error Codes
In all cases, you may be able to clear the Error Message simply by turning the heater OFF, then ON again. If the Error Message still remains or returns on the next operation, please contact your nearest service contact and arrange for a service call. Royale - Freestanding ETR - 11 - Issue 3 - ©Rinnai... -
Page 14: Installer Information - Important Points
9. The local gas and electrical authorities will be able to advise on local regulations. 10.Rinnai appliance warranty conditions will be voided if non Rinnai flue components are fitted. Rinnai appliances are NOT CERTIFIED for use with non Rinnai flueing components. -
Page 15: Installers Information - Location
Installation and Service must be carried out by an authorised person only. When positioning the heater, the main points to consider are: 1. Flue connection and terminal to comply with AS/NZS 5601. Only Rinnai flueing compo- nents to be used. - Page 16 Royale - Freestanding ETR - 14 - Issue 3 - ©Rinnai...
-
Page 17: Installers Information - Specifications
Flue terminal: 100 mm dia. top discharge Flue: An approved Rinnai Flue kit is mandatory for this appliance, and it is to be installed in acccordance with AS/NZS 5601. Use FLFKIT05 / FLFTWKIT minimum of 3 metres of flue to be installed. -
Page 18: Installers Information - Dimensions
INSTALLERS INFORMATION - DIMENSIONS Royale - Freestanding ETR - 15 - Issue 3 - ©Rinnai... -
Page 19: Installers Information - Flueing
HEATER HEATER 1. Position heater taking into consideration the Information under “Location”. 2. Assemble and connect flue in accordance with the Rinnai Flueing Installation manual for Rinnai Flame Fire heaters. 3. For pipe sizing, refer to your local gas installation codes. -
Page 20: Installers Information - Log Installation
Note: When first lighting the heater, the logs need to be burnt in, which may take approximately 2 hours. The flame colour may change after the initial burning in period. Royale - Freestanding - 17 - Issue 3 - ©Rinnai... -
Page 21: Installers Information - Testing & Commissioning
• All burner aerations are factory preset and period, the heater should be run on the cannot be adjusted. High position in a well ventilated room. Royale - Freestanding ETR - 18 - Issue 3 - ©Rinnai... -
Page 22: Installers Information - Wiring Diagram
If the supply cord is damaged or requires replacing, it must be replaced by the manufacturer or the manufacturers agent or similarly qualified person in order to avoid a hazard. The supply cord must only be replaced with a genuine Rinnai spare part. Part No. 90182065. -
Page 23: Installation / Commissioning Checklist
Issue 3 (To be completed by certified Gas Installer) Model: _______________________________ 1. Was a Rinnai Flue system installed in accordance with the instructions? 2. Have specified gas pressures been checked and set? 3. Are decorative logs located correctly? 4. Have ember granules been placed and free of dust and powder? 5. -
Page 24: Customer Information - Contacts
CUSTOMER INFORMATION - CONTACTS The Rinnai Flame Fire Heater Family Inbuilt Royale Freestanding Royale Inbuilt Slimfire IB35 / IB35ETR FS35 / FS35ETR IB25 Australia Pty. Ltd. ABN 74 005 138 769 Head Office Internet: www.rinnai.com.au E-mail: enquiry@rinnai.com.au 10-11 Walker Street,...
