- Page 1 OPERATOR’S MANUAL Model 336, 338, 339 Soft Serve Freezer Original Operating Instructions 4/16/2009 (Original Publication) 036029-M (Updated 6/26/2018)
- Page 2 Only instructions originating from the factory or its authorized translation representative(s) are considered to be the original set of instructions. © 2009 Taylor Company 036029-M Any unauthorized reproduction, disclosure, or distribution of copies by any person of any portion of this work may be...
-
Page 3: Table Of Contents
Refrigerant ......................1-3 Section 2: To the Operator Compressor Warranty Disclaimer ..............2-2 Section 3: Safety Section 4: Operator Parts Identification Model 336 ......................4-1 Model 338 ......................4-2 Model 339 ......................4-3 Three Spout Door....................4-4 Accessories......................4-5 Section 5: User Interface Symbol Definitions ..................... - Page 4 Section 6: Operating Procedures Assembly......................6-1 Sanitizing......................6-6 Priming .......................6-7 Closing Procedure....................6-8 Draining Product from the Freezing Cylinder .............6-9 Rinsing .......................6-9 Cleaning ......................6-9 Disassembly .......................6-9 Manual Brush Cleaning ..................6-10 Section 7: Operator’s Checklist During Cleaning and Sanitizing ................7-1 Troubleshooting Bacterial Count ................7-1 Regular Maintenance Checks ................7-1 Winter Storage ....................7-2 Section 8: Troubleshooting Guide...
-
Page 5: Section 1: To The Installer
Failure to comply may result in personal injury or equipment damage. Note: All repairs must be performed by a Taylor service Uncrate the unit and inspect it for damage. Report any technician. damage to your Taylor distributor. -
Page 6: Water Connections
Supply cords used with this unit shall be oil- on the unit. Check the data label(s) on the freezer for resistant, sheathed flexible cable not lighter than ordinary branch circuit overcurrent protection or fuse, circuit polychloroprene or other equivalent synthetic elastomer- To the Installer Model 336, 338, 339... -
Page 7: Beater Rotation
If burns are severe, apply Beater Rotation ice packs and contact a physician immediately. Taylor reminds technicians to be aware of government laws regarding refrigerant recovery, recycling, and Beater rotation must be clockwise as viewed reclaiming systems. If you have any questions regarding looking into the freezing cylinder of any model freezer. - Page 8 TO THE INSTALLER Notes: To the Installer Model 336, 338, 339...
-
Page 9: Section 2: To The Operator
The Taylor softserve models covered in this subject to change without notice. manual consist of the following: 336, 338, and 339. These units, when properly operated and cared for, will produce a consistent quality product. Like all mechanical If the crossed-out waste container symbol is products, they will require cleaning and maintenance. -
Page 10: Compressor Warranty Disclaimer
It should also be noted that Taylor does not warrant the refrigerant used in its equipment. For example, if the refrigerant is lost during the course of ordinary service to... -
Page 11: Section 3: Safety
We at the Taylor Company are concerned about the safety of the operator when he or she comes into contact with the freezer and its parts. Taylor has gone to extreme DO NOT use a water jet to clean or rinse the efforts to design and manufacture built-in safety features freezer. - Page 12 SAFETY For Cord Connected Units: Only Taylor • authorized service technicians or licensed electricians may install a plug or replacement This freezer must be placed on a level surface. cord on the unit. Failure to comply may result in personal injury or •...
-
Page 13: Model 336
Tube-Feed 5/32 Dia. Hole 043461-2 Shield-Splash 022765 O-ring-.563 OD X .070W 043758 Stud-Nose 022822 Panel-Rear 029816 Panel A.-Front X68530 Louver-Side-Top 051191 Decal-Dec-Taylor 045812 Panel-Upper Side R. 028741 Plate-Dec 041854 Panel A.-Lower Side X24424-SER Gasket-Hopper Cover 037042 Operator Parts Identification Model 336, 338, 339... -
Page 14: Model 338
O-ring.643 OD X .077 W 018572 Shield-Splash 23 Long 022766 Panel-Rear 051600 Tray-Drip 22-7/8 L X 5-1/8 W 014533 Louver-Side Top 051191 Leg-4” SS W/O-ring 013458 Panel A.-Side Upper Right X48596 Skirt-Air Flow 048489 Operator Parts Identification Model 336, 338, 339... -
Page 15: Model 339
Caster-SWV 5/8 Stem 4” 018794 Panel-Rear 053782 Caster-4” SWV W/Brake 034081 Louver-Side Top 051191 Panel-Service 024439 Panel-Upper Side Right 028741 Shield-Splash 23 L 022766 Panel A.-Lower Side (R/l) X24424-SER Tray-Drip 22-7/8l X 5-1/8 W 014533 Operator Parts Identification Model 336, 338, 339... -
Page 16: Three Spout Door
Cap-Design 1.010"ID-6 Point 014218 O-ring-3/8 OD X .070W 016137 O-ring-5/16 OD X .070W 016272 Plug-Prime 028805 Rod A.-Pivot X20683 Handle A.-Draw *White X81010-SP Door A.-3 Spout X51532-15 Handle-Draw-White 056248-1 Baffle A.-Short 4” X50883 Screw-Adjustment 056332 Operator Parts Identification Model 336, 338, 339... -
Page 17: Accessories
Accessories Figure 4-5 Item Description Part No. Item Description Part No. Tool-O-ring Removal 048260-WHT Pail-10 qt. (336 and 339) 013163 Brush-Rear Bearing 1” D X 2” L 013071 Pail-6 qt. (338) 023348 Brush-Double Ended 013072 Deflector-Blower (339) 047912 Brush-Draw Valve 1” X 2” X 17”... - Page 18 OPERATOR PARTS IDENTIFICATION Notes: Operator Parts Identification Model 336, 338, 339...
-
Page 19: Section 5: User Interface
Power Switch AUTO Button MIX Button Indicator Light - MIX LOW STANDBY Button RESET Button WASH Button Symbol Definitions The following chart identifies the symbol definitions used on the operator switches. WASH MIX LOW STANDBY User Interface Model 336, 338, 339... -
Page 20: Power Switch
Always maintain at least 3 in. (76 mm) of mix in the hopper. If you neglect to add mix, a Note: The Model 336 cannot be operated in freeze-up may occur. This will cause eventual damage to the WASH mode if the opposite side of the freezer is in the beater, blades, drive shaft, and freezer door. -
Page 21: Air Tube
If the flow rate can be increased by removing the pivot pin and freezer shuts down again, contact a Taylor service placing the restrictive bar on the top. When drawing technician. - Page 22 USER INTERFACE Notes: User Interface Model 336, 338, 339...
-
Page 23: Section 6: Operating Procedures
Note: When lubricating parts, use an approved food grade lubricant (example: Taylor Lube). MAKE SURE THE POWER SWITCH IS IN THE “OFF” POSITION. 1. Install the drive shaft. Lubricate the groove and shaft portion that comes in contact with the bearing on the beater drive shaft. - Page 24 Figure 6-5 8. Slide the two O-rings into the grooves on the prime plugs. Apply an even coat of Taylor Lube to the O- rings and shafts. Figure 6-4 5.
- Page 25 Tighten view. equally in a crisscross pattern to make sure the door is snug. Note: The short handscrews go on the bottom and the long handscrews go on top. Figure 6-10 Figure 6-8 Operating Procedures Model 336, 338, 339...
- Page 26 Secure with the pivot pin. the door spouts. Note: Models 336, 338 and 339 have three draw handles. Slide the fork of the draw handle in the slot of the draw valve, starting from the right. Slide the pivot pin through each draw handle as you insert them into the draw valves.
- Page 27 20. Lay the air tube (with the air orifice installed) and the hopper gasket in the bottom of the mix hopper for sanitizing. 21. Repeat step 18 through step 20 for the other side of the freezer. Operating Procedures Model 336, 338, 339...
-
Page 28: Sanitizing
Figure 6-22 5. Press the WASH button. This will cause the sanitizing solution in the freezing cylinder to agitate. Allow it to agitate for five minutes. Figure 6-20 Figure 6-23 Operating Procedures Model 336, 338, 339... -
Page 29: Priming
8. Once the sanitizer stops flowing from the door spout, raise the draw handle and press the WASH button, canceling the beater motor operation. Note: You have just sanitized the freezer. Be sure your hands are sanitized before continuing these Figure 6-27 instructions. Operating Procedures Model 336, 338, 339... -
Page 30: Closing Procedure
To disassemble your unit, the following items will be needed: • Two cleaning pails Figure 6-29 • Sanitized stainless steel rerun can with lid • Necessary brushes (provided with freezer) • Cleaner • Single-service towels Operating Procedures Model 336, 338, 339... -
Page 31: Draining Product From The Freezing Cylinder
Wash mode. freezer. 8. Repeat step 1 through step 7 for the other side of the Note: For Model 336, both sides must be in Wash freezer. mode. If one side is in Auto mode and the other is in... -
Page 32: Manual Brush Cleaning
O-ring first. This will allow the O-ring to slide over the forward rings without falling into the open grooves. 5. Remove the O-rings from the air tubes and air orifices. 6-10 Operating Procedures Model 336, 338, 339... -
Page 33: Section 7: Operator's Checklist
When using rerun, skim the foam and discard. Mix the rerun with fresh mix in a ratio of 50:50 during the day’s operation. Caution: Always disconnect electrical power prior to cleaning the condenser. Operator’s Checklist Model 336, 338, 339... -
Page 34: Winter Storage
Deteriorated or cracked in a protected dry place. Rubber trim parts and water lines should be replaced only by a Taylor gaskets can be protected by wrapping them with service technician. -
Page 35: Section 8: Troubleshooting Guide
The mix hopper cover is not in position. c. Place the cover in position. d. The MIX light is not lit. d. Press the MIX button. e. The condenser is dirty. e. Clean the condenser. Troubleshooting Guide Model 336, 338, 339... - Page 36 Install the air tube in the mix inlet hole, using the end with the small hole in the side. d. The air orifice is not installed. d. Install the air orifice in the air tube. Troubleshooting Guide Model 336, 338, 339...
-
Page 37: Section 9: Parts Replacement Schedule
White Bristle Brush, 1” x 2” Inspect and replace if Minimum necessary. Black Bristle Brush, 1” x 2” Inspect and replace if Minimum necessary. Double-Ended Brush Inspect and replace if Minimum necessary. Parts Replacement Schedule Model 336, 338, 339... - Page 38 PARTS REPLACEMENT SCHEDULE Notes: Parts Replacement Schedule Model 336, 338, 339...
-
Page 39: Section 10: Limited Warranty On Equipment
LIMITED WARRANTY Taylor warrants the Product against failure due to defects in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original Product installation. If a part fails due to defects during the applicable warranty period, Taylor, through a Taylor-authorized distributor or service agency, will provide a new or re- manufactured Part, at Taylor's option, to replace the failed defective Part at no charge for the Part. - Page 40 7. Failure, damage, or repairs due to faulty installation, misapplication, abuse, no or improper servicing, unauthorized alteration, or improper operation or use as indicated in the Taylor Operator's Manual, including but not limited to the failure to use proper assembly and cleaning techniques, tools, or approved cleaning supplies.
- Page 41 LEGAL REMEDIES The owner must notify Taylor in writing by certified or registered letter to the following address of any defect or complaint with the Product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
- Page 42 LIMITED WARRANTY ON EQUIPMENT Notes: 10-4 Limited Warranty on Equipment Model 336, 338, 339...
-
Page 43: Section 11: Limited Warranty On Parts
Taylor warrants the Parts against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original installation of the Part in the Taylor unit. If a Part fails due to defects during the applicable warranty period, Taylor, through a Taylor-authorized distributor or service agency, will provide a new or re-manufactured Part, at Taylor's option, to replace the failed defective Part at no charge for the Part. - Page 44 Taylor. 5. Replacement of wear items designated as Class 000 Parts in the Taylor Operator's Manual, as well as any release sheets and clips for the Product's upper platen assembly.
- Page 45 LEGAL REMEDIES The owner must notify Taylor in writing by certified or registered letter to the following address of any defect or complaint with the Part, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Part under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
- Page 46 LIMITED WARRANTY ON PARTS Notes: 11-4 Limited Warranty on Parts Model 336, 338, 339...
