Section 3: Troubleshooting General Troubleshooting Guide Troubleshooting Pump Style Freezers Electrical Trou leshooting Section 4: Parts Warranty Explanation Model 336 Exploded View Model 336 Panel Identification Model 338 Exploded View Model 338 Panel Identification Model 339 Exploded View Model 339 Panel Identification...
Page 3
Pump A-Syrup 036623 (774) Accessories Parts List Wiring Diagrams CAUTION: Information in this manual is intended to be used by Taylor Authorized Service Technicians only. Note: Continuing research results in steady improvements; therefore, information in this manual is subject to change without notice.
Safety We at Taylor Company, are committed to manufacturing safe operating and serviceable equipment. The many built-in safety features that are part of all Taylor equipment are aimed at protecting operators and trained service technicians alike. NOISE LEVEL: Airborne noise emission does not exceed 78 dB(A) when measured at a distance of 1.0 meter from the...
Model 336 Specifications This unit is manufactured in other electrical characteristics. Refer to the Distributor Data Book for availability. (For exact electrical information, always refer to the data label of the unit.) Freezing Cylinder Air Cooled Two, 2.8 quart (2.7 liter) volume.
Model 338 Specifications availability. (For exact electrical information, always refer to the data label of the unit.) Air Cooled Freezing Cylinder Clearance: 6" (15.2 cm.) on both sides. It is recommended to install a skirt to one side of the unit, and to place the back of Two, 2.8 quart (2.7 liter) volume.
Model 339 Specifications availability. (For exact electrical information, always refer to the data label of the unit.) Air Cooled Freezing Cylinder Clearance: 3" (7.6 cm.) around all sides. A deflector has been added to underside preventing recirculation of Two, 2.8 quart (2.7 liter) volume. warm air.
availability. (For exact electrical information, always refer Model 750 Specifications to the data label of the unit.) Air Cooled Freezing Cylinder Clearance: 6" (15.2 cm.) on both sides. It is One, 3.4 quart (3.2 liter) volume. recommended to place the back of the unit against a wall.
Models 751/8751 Specifications Freezing Cylinder These units are manufactured in other electrical characteristics. Refer to the Distributor Data Book for One, 3.4 quart (3.2 liter) volume. availability. (For exact electrical information, always refer to the data label of the unit.) Mix Hopper Air Cooled One, 20 quart (18.9 liter) capacity.
Page 10
Models 754/8754 Specifications Freezing Cylinder These units are manufactured in other electrical characteristics. Refer to the Distributor Data Book for Two, 3.4 quart (3.2 liter) volume. availability. (For exact electrical information, always refer to the data label of the unit.) Mix Hopper Air Cooled Two, 20 quart (18.9 liter) capacity.
Model 774 Specifications Freezing Cylinder availability. (For exact electrical information, always refer to the data label of the unit.) Two, 3.4 quart (3.2 liter) volume. Air Cooled Mix Hopper Clearance: 3" (7.6 cm.) around all sides. A deflector has Two, 20 quart (18.9 liter) capacity. been added to underside preventing recirculation of warm air.
Model 794 Specifications Freezing Cylinder availability. (For exact electrical information, always refer to the data label of the unit.) Two, 3.4 quart (3.2 liter) volume. Air Cooled Mix Hopper Clearance: 3" (7.6 cm.) around all sides. A deflector has been added to underside preventing recirculation of warm air. Two, 14 quart (13.3 liter) capacity.
Installation Instructions CAUTION: THIS EQUIPMENT MUST BE Air Cooled Units PROPERLY GROUNDED! FAILURE TO DO SO CAN Air cooled units require a minimum of 3" (7.6 cm.) of RESULT IN SEVERE PERSONAL INJURY FROM clearance around all sides of the freezer (6" [15.2 cm] for ELECTRICAL SHOCK! Models 338 and 750).
Water Valve allow adequate time for the pressure to stabilize. Important: On the Models 336 and 338, expansion On a water cooled unit, the water valve should be set to valves on each side of the unit must be set separately.
Generation II Control Logic Board The Generation II logic board's primary function is to interpret As of July, 1996 we have modified the differential on modes of operation. The board monitors mix levels and Generation II controls from 13'F/7.2'Cto4.5'F/2.5-C in order temperatures by sending commands to the control's power to meet the new NSF mix temperature requirements.
Page 16
Press "AUTO". When amperage achieves the previously Viscosity Function: noted beater motor amperage, turn the viscosity In soft serve freezers the logic board monitors amp draw on adjustment screw counterclockwise slowly until the unit the beater motor, which is directly related to the viscosity of cycles off.
Page 17
Note: On pump units, "STANDBY" must be cancelled and Note: On the Models 336, 338, 339, 754 and 794, the "PUMP" must be pressed to replace the portion which was temperature adjustment must be made on the left logic used for the sample draw.
Page 18
correct one. Determine whether the difference is acceptable. Thermistor Curve If a probe is actually faulty, the difference will be great. When checking a thermistor probe, first determine the present temperature at the probe and find it on this chart along with the approximate correct ohmmeter reading.
Service Tips for Generation II Boards Initial Service Tips 1. Check all connections. 2. Check the cable to verify that it is secure. 3. Verify that all pins are securely fastened in their sockets. 4. Verify that all cables correctly face away from the boards.
Page 21
These lights create a bar graph which is directly related to Ten seconds later, the pump relay closes. the product temperature. "MIX" is warm and "PUMP" is Three seconds later, the pump relay opens and the cold. mix light turns off. Ten seconds later, the beater motor relay 1.
Page 22
11. The capability of this terminal to read the Press the MIX keypad once. thermistor probe can be checked by the following method: The MIX OUT light is lit, indicating that the control Remove the thermistor probe wire from the is now reading the BARREL (freezing cylinder) "MIX 1"...
Pump Operation The pump operates under the following conditions: Soft Serve Mix Pumps The soft serve mix pump will be active for 30 seconds whenever the AUTO mode is entered. If a MIX OUT condition forces a side of the machine into the STANDBY mode of operation, the mix pump will not be active.
General Troubleshooting Guide PROBLEM PROBABLE CAUSE REMEDY 1. No product is being dispensed. Low on mix. The MIX OUT light is on. Add mix to the mix hopper The power switch is in the OFF Place the power switch to the ON position.
Page 26
PROBLEM PROBABLE CAUSE REMEDY 3. The product is too soft. The draw rate is set too fast. Adjust the draw rate to 5 - 7-1/2 oz. (142 g. - 213 g.) of product by weight every 10 seconds. Outdrawing the capacity of the The continuous draw rate is freezing cylinder.
Page 27
PROBLEM PROBABLE CAUSE REMEDY 11. Freezing cylinder walls are Missing or worn front bearing. Install or replace the front bearing. scored. Broken beater pins (pump style Replace the beater assembly. When freezers, only). installing scraper blades, be sure they are properly attached over the pins. The beater assembly is bent.
Troubleshooting Pump Style Freezers PROBLEM PROBABLE CAUSE REMEDY The air/mix pump will not operate The circuit breaker is off. Check the breaker. when the PUMP keypad is pressed. The power cord is unplugged. Plug in the power cord. The freezer is out on reset. Reset the freezer.
Electrical Troubleshooting Wash Mode of Operation: The following information provides a sequential list of electrical components that L-1 power travels through to L-1 power travels through the power switch, beater overload initiate various operations. switch, the compressor high pressure cut-out switch, the overload terminal (OL) on the power board, the BTR terminal Auto Mode of Operation: of the power board, and energizes the coil of the beater...
The warranty for new equipment parts is five years from the original date of unit installation, with a replacement parts warranty of twelve months.. Class 000 Parts: Wear Items - no warranty. CAUTION: Warranty is valid only if required service work is provided by an Authorized Taylor Service Technician.
Control A. - X38324-27A (Model 336) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. STARTER- PH-4.5 TO 7 A 041950-27K BOX A.-CONTROL X36468 RELAY-3 POLE 012725-33 BLOCK-TERMINAL 5 POLE 024329 LABEL-COPPER COND 025948 RELAY-SPST 032607-27 SCREW-8 X 1-1/4 RD HD - B...
Control A. - X47194-27A (Models 751/8751) 208-230/60/1 ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. RELAY-3 POLE-20A-208/240 012725-33 BLOCK-TERMINAL-7 POLE 024156 STARTER-1 PH-4.5 TO 7 A 041950-27K LABEL-GROUNDING SYMBOL 017669 SCREW-8X1/4 SL HEX HD 009894 LABEL-COPPER COND ONLY 025948 SCREW-6-32X5/8 TAPTITE 041363 LUG-GROUNDING 260 020928...
Control A. - X48237-27 (Model 794) 208-230/60/1 Item Description Part No. Item Description Part No. BUSHING-SPLIT 43/64 ID 027691 LABEL-GROUNDING SYMBOL 017669 STARTER-1 PHASE-4.5 TO 7 A 041950-27K SCREW-8 X1-1/4 RDHD 039420 SCREW-8X1/4 SL HEX HD B 009894 BLOCK-TERMINAL 2P-L1,L2 039422 LABEL-COPPER COND ONLY 025948...
Box A.-Cap & Relay - X50297-27 (Model 754) 208-230/60/1 ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. SCREW-8-32 X 1/4 RHM-BR. 000953 SCREW- 10X3/8 TYPE B-HEX 015582 WASHER-#8-EXTERNAL 000964 STRAP-CAPACITOR 5-5/8 IN. 030258 SLEEVE-WIRE 7/16 ID 020919- BOX-CAPACITOR RELAY 030183 CONNECTOR-BX 3/8 STR 014569 R E LAY- START- CO M P.
Models 336/338/339 Three-Spout Door A. ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. SEAL-DRIVE SHAFT 032560 O-RING 1/4 ODx.070 W 015872 SHAFT-BEATER 033235 NUT-5/16-2418-8 SS JAM 029639-BLK BEATER A.-2.8 QT. X35466 NUT-STUD LONG 034382 BLADE-SCRAPER-PLASTIC 035480 NUT-STUD SHORT 034383 BEARING-FRONT 050216 VALVE A.-DRAW...
Page 92
DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. CLASS UPDATE GASKET-DOOR HT 4'-DOUBLE 048926 GEAR A *REDUCER 021286 GUARD-FAN 028534-1 GUIDE A.-DRIP PAN X27554 GUIDE A.-DRIP PAN X51567 GUIDE A.-DRIP PAN X28699 HOOD 041026 HOOD 042866 HOOD 035434 KIT A.-TUNE UP-3 SPOUT-NON HT X49463-6 BEARING-FRONT 050216...
Page 93
UPDATE LABEL-SWITCH-POWER "OFF/ON* 052632 J8080000/UP (ON POSITION ON R/S) LEG-4" SS-W/ORING 013458 LOUVER-SIDE 017471 MODEL 338 - LEFT SIDE LUBRICANT-TAYLOR 4 OZ. 047518 MAN-OPER 300 SERIES SOFTECH 036029-M MOTOR-1.0 HP 013102- MOTOR-FAN 80 W 208/230V 60HZ 051744- MAIN SYSTEM +CAPAC1TOR-RUN- 4UF-440V 051785 +FAN-5 BLADE 12"PUSH 32DEG CC...
Page 94
PRIOR TO J6090000 +STUD-NOSE CONE 022822 SHIELD-SPLASH *5454-8-752-336* 022765 SHIELD-SPLASH 23 L 022766 SKIRT-AIR FLOW 048489 +COLLAR-HOLDING 019481 +SCREW-HOLDING COLLAR (10-32 X 3/4) 001086 STARTER 041950- BEATER LINE STARTER OVERLOAD-THERMAL 047150- SWITCH A.-DRAW *336*SELF CLOSE X43417-SER ARM-SWITCH-DRAW-LEFT 038649 ARM-SWITCH-DRAW-RIGHT 038650...
Page 96
DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. CLASS UPDATE TRIM-REAR CORNER RIGHT 044281 TUBE-FEED 5/32 DIA. HOLE 043461-2 +0-RING-.563 OD X .070W-#013 043758 TUBE A.-FEED-SS-5/32 HOLE DIA X29429-2 +0-RING-.643 OD X .077W 018572 VALVE-ACCESS 1/4 X 3/8 SOLDER 029406 VALVE-ACCESS 1/4FL X 1/4SOLDER 044404...
Page 97
DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. CLASS UPDATE 50Hz BELT-AX33 024396 BELT-AX39 023874 BLOCK-TERMINAL 2 POLE 039421 220-240/50/1 BLOCK-TERMINAL-2 POLE 039422 BLOCK-TERMINAL-7 POLE GREEN 024156 COMPRESSOR COMPONENTS: CAPACITOR-RUN 25UF/370VOLT 023739 220-240V 50HZ 1 PH BRISTOL CAPACITOR-START 031790 220-240V 50HZ 1 PH BRISTOL RELAY-START-COMPRESSOR 038146...
Page 98
HP62 Refrigerant: 750 - J6110454, 751 - J6080596, 754 - J6080465, 774 - J6092382, and 794 - J4094101/up DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. QTY. QTY. CLASS UPDATE ADAPTOR A.-CASTER X18915 BEARING-FRONT 050216 BEARING-REAR SHELL 031324 +GUIDE-DRIP SEAL 028992 +NUT-BRASS BEARING 028991...
Page 99
DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. QTY. QTY. CLASS UPDATE CAPACITOR-RUN 019624 MOTOR-041401-27 CASTER-SWIVEL 018794 COMPRESSOR -COPELAND 051958-27 J8108583/UP-230-60-1 COMPRESSOR -COPELAND 051958-58 J8108583/UP- 220-240/380^115/50/3 LINE A.-ACCESS COMPRESSOR X42513 COPELAND CAPACITOR-RUN 012906 230-60-1 -J8108583/UP CAPACITOR-START 033044-1 230-60-1 -J8108583/UP RELAY-START COMPRESSOR 051957-27 230-60-1 -J8108583/UP...
Page 100
DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. QTY. QTY. CLASS UPDATE +GASKET-MIX HOPPER 038474 KNOB-MIX HOPPER 025429 COVER-MIX HOPPER 041682-GRY DECAL-DECORATIVE SOFTECH 033230 DECAL-DECORATIVE SOFTECH 032919 DECAL-DECORATIVE SOFTECH 045812 DECAL-HEATER SWITCH 036551 "ON-OFF" DECAL-CLEAN & SANITIZE 019029 DECAL-POWER SWITCH - ON/OFF PRIOR TO J8080000 (NEW 32484 SEE LABEL)
Page 101
DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. QTY. QTY. CLASS UPDATE GUIDE A.-DRIP PAN X28863 GUIDE A.-DRIP PAN X28699 GUIDE A.-DRIP PAN X45691 HANDLE A.-ADJUSTABLE DRAW X26996 HANDLE-DRAW 028804 SCREW-ADJUSTABLE 026592 PLASTIC 0-RING 015872 HANDLE A.-ADJUSTABLE DRAW X33687 J7090000/UP (REPLACES X26996) HANDLE-DRAW...
Page 102
052632 J8080000/UP (ON POSITION ON R/S LABEL-WARN-COVER 051433 LEG (4" w/O-RING) 013458 LID-W/LADLE 036575 LOUVER-SIDE (LEFT) 013631 LEFT LOUVER-SIDE 017471 LUBRICANT-TAYLOR 4 OZ. 047518 MAN-OPER 028754-M MOTOR-BEATER 021522- CAPACITOR-RUN (230-60-1) 027087 MAGNETEK/CENTURY 230-30-1 CAPACITOR-RUN (230-60-1) 036084 LEESON 230-30-1 CAPACITOR-START (230-60-1)
Page 103
DESCRIPTION PART WARR. REMARKS PARTS NUMBER QTY. QTY. QTY. QTY. QTY. CLASS UPDATE PAN-DRIP 050766 PAN-DRIP- 11-5/8" LONG 027503 PAN-DRIP 17-1/4" LONG 027504 PAN-DRIP 035034 PAN A.-HINGED DRIP X41844 PANEL-REAR 020891 PANEL-REAR 013637 PANEL-REAR 017563 PANEL-REAR 041855 PANEL-REAR-LOWER 042577 PANEL A.-REAR-UPPER X42574 PANEL-SERVICE 047170...
