Furuno Inmarsat Mini-C MES FELCOM19 Installation Manual page 27

2. Select [Connection] then press the Enter key to show the [Connect List]. This list
shows the names of the terminals that can be connected to the LAN interface.
No. Name
*01 F19_123456 123432588 172.31.16.100/24
02 F19_133234 456789210 192.168.16.11/24
03
04
05
06
07
08
09
10
Note: The No., Name, IMN, IP address/subnet mask and software version of each
terminal are shown. The asterisk marks the terminal currently selected for
communication.
3. Select the terminal to use then press the Enter key.
4. Select [Date Disp. Form] then press the Enter key to open its options window.
5. Select [YY-MM-DD], [MMM-DD-YY] or [DD-MMM-YY] as appropriate then press
the Enter key.
6. Select [Screen Saver] then press the Enter key.
7. Turn the screensaver ON or OFF as appropriate then press the Enter key. When
enabled, the screensaver automatically starts 10 minutes after there is no key op-
eration. To release the screensaver, press any key.
8. Select [Window Color] then press the Enter key.
Select Preset
Load Default
- - - - - - - - - - - - - - - - - - - - - - -
Edit Color
Window
Fore Color
Back Color
- - - - - - - - - - - - - - - - - - - - - - -
To Change: ENTER
9. Set the window colors as follows:
1) [Select Preset] provides three pre-configured window color sets. Use one of
these sets, or continue this procedure to customize window colors.
2) Select [Window]. Use
or.
Base Window: Standby display
RCV Message Display: Receive message display
EGC Message Display: EGC message display
EDIT1 - EDIT2: Editor screens 1 and 2
Function: Menu
Sub Menu 1 - Sub Menu 4: Sub menus 1-4
Message: Status message
Connect List
IMN IP Address
Window Color Setup
1 2 3
[ Base Window
[ L-WHITE
[ BLUE
To Change Value:L<=>R
or key to select the window for which to select col-
3. INITIAL SETTINGS
Software Version
1650248-01
1650248-01
]
]
]
3-9
