2.5

Determine the Modem IP Address

Step Task
Connect the serial port of the modem to the serial port of a computer. The minimum pins needed
1
are 1, 2, & 3.
2 Open up a terminal session using an application like Putty or Tera Term.
Modify the following parameters:
3
Change the modems IP address. Enter the following commands:
4
Verify high security setting for SNMP V3 is turned OFF. Enter the following commands:
5
Installation
a. Emulation: VT100
b. Tx: CR+LF
c. Local Echo: yes
d. Baud rate: 115200 The modem is hard coded for this rate.
e. Data: 8 bit
f. Parity: None
g. Stop: 1
h. Flow Control: None
a. What is the IP Address?:
Input: <0/IPA?
•
Displays: >0000/IPA=192.168.001.011.24
b. Change the IP address:
Input the new IP address: <0/IPA=192.168.001.021.24
•
c. Confirm IP address:
Input: <0/IPA?
•
Displays: >0000/IPA=192.168.001.021.24
a. What is the current setting for Modem Interface Security Mode?
Input: <0/MIS?
•
Displays: >0000/MIS=0 - or -
Displays: >0000/MIS=1
b. If set to '1' (security mode ON), change the >0000/MIS= to '0' (security mode OFF).
SLM-5650C / SLM-5650C-ODU Satellite Modem
2–3
Revision 1
MN-SLM-5650C
