The
water valves from connector J7 pin 3.
If the defrost heater is on, the Fill Tube Heater relay will be on.
After the Fill Tube Heater is on during defrost, the water valve relay will not be energized. The water valve will
require input from the icemaker to energize the K3 relay.
input from the icemaker.
Upon the completion of 20 seconds of continuous input from the icemaker to the K3 relay, the K3 relay will
After receiving input from the icemaker, the
icemaker with water.
The
expired.
Icemaker Removal
Remove both freezer baskets and the drawer front to access the icemaker. The icemaker is removed by
loosening the two Phillips screws just above the mold. Disconnect the 6 pin electrical connector then lift up
and out on the assembly. See the Icemaker section in this service guide for more details.
main board K3 relay by supplying 120 VAC to the isolation and
