VIP X1600 | Installation and Operating Manual

MPEG-4 encoder

For encoding the video signal you can select two profiles for each encoder
(video input) and change the presets for the profiles.
Selecting a profile
You can adapt the MPEG-4 data transmission to the operating environment
(for example network structure, bandwidth, data load). To this end, the
VIP X1600 module simultaneously generates two data streams (Dual Stream-
ing) for each video input, which compression settings you can select individually,
for example one setting for transmissions to the Internet and one for LAN con-
nections.
Note
You must set the parameters for each camera input and for each stream
individually. The names Video 1 to Video 4 correspond to the names of
the video inputs on the unit.
Pre-programmed profiles are available, each giving priority to different perspec-
tives.
❚ Profile 1: Low bandwidth (CIF)
High quality for low bandwidth connections,
resolution 352 × 288/240 pixels
❚ Profile 2: Low delay (2/3 D1)
High quality with low delay,
resolution 464 × 576/480 pixels
❚ Profile 3: High resolution (4CIF/D1)
High resolution for high bandwidth connections,
resolution 704 × 576/480 pixels
Bosch Security Systems | 2006-03 | V2.0
EN | 41
Configuration using a Web Browser
