    The owner/user must familiarize himself with the contents of all machine instruction manuals. The owner/user should direct any questions about these instructions to a Milnor® dealer or the Milnor® Service department.

  • Page 14: Personnel

    They must be replaced immediately if lost or damaged. The Safety Guide and other machine manuals must be available at all times to the appropriate personnel. See the machine service manual for safety placard part numbers. Contact the Milnor Parts department for replacement placards or manuals.

  • Page 15: Internal Electrical And Mechanical Hazards

    No operar sin que todas place. las defensas y cubiertas estén en su lugar. Do not put hands/fingers beyond guard/cover. No poner las manos o dedos adentro de las defensas o cubiertas. PELLERIN MILNOR CORPORATION...

  • Page 16: Safety Alert Messages-Internal Electrical And Mechanical Hazards

    • Do not remove guards, covers, or panels. • Do not reach into the machine housing or frame. • Keep yourself and others off of machine. • Know the location of the main machine disconnect and use it in an emergency to remove PELLERIN MILNOR CORPORATION...
  • Page 17 Manual operation of tilting valves overrides safety interlocks. Improper operation of manual tilting valves may cause the housing to descend. • Do not remove guards, covers, or panels. • Do not reach into the machine housing or frame. — End of BIUUUS24 — PELLERIN MILNOR CORPORATION...

  • Page 18: External Mechanical Hazards

    • Do not operate the machine with malfunctioning two-hand manual controls. WARNING 5 : Crush Hazards—Tilting machines only—The machine can crush your body or limbs if you are caught between the tilting housing and a stationary object. Some machines tilt PELLERIN MILNOR CORPORATION...
  • Page 19 The shell moves within the housing during operation. • Do not reach into the machine housing or frame. • Keep yourself and others clear of movement areas and paths. — End of BIUUUS25 — PELLERIN MILNOR CORPORATION...

  • Page 20: Cylinder And Processing Hazards

    Figure 9: Cylinder and Processing Hazards—Hot Surfaces WARNING ADVERTENCIA Riesgo de Burn hazard. quemadura. Contact can cause El contacto puede serious injury. causar lesiones graves. Do not touch. No tocar. PELLERIN MILNOR CORPORATION...

  • Page 21: Safety Alert Messages-Cylinder And Processing Hazards

    WARNING 9 : Confined Space Hazards—Confinement in the cylinder can kill or injure you. Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration, biological contamination, electrocution, and crushing. • Do not attempt unauthorized servicing, repairs, or modification. PELLERIN MILNOR CORPORATION...
  • Page 22 Processing can cause solvent-containing goods to give off flammable vapors. • Do not use flammable solvents in processing. • Do not process goods containing flammable substances. Consult with your local fire department/public safety office and all insurance providers. — End of BIUUUS26 — PELLERIN MILNOR CORPORATION...

  • Page 23: Safety Alert Messages-Unsafe Conditions

    This will over-speed the motor and pulleys and can cause them to rip apart, discharging metal fragments at high speed. • Stop the machine immediately if any of these conditions occur: • abnormal whining sound during extract • skidding sound as extract ends • clutches remain engaged or re-engage during extract PELLERIN MILNOR CORPORATION...

  • Page 24: Careless Use Hazards

    WARNING 23 : Crush Hazards—Tilting machines with front and rear tilt cylinders—The housing will fall and lunge forward or rearward if the tilt wheels on the non-tilted end lift out of their cradles, even with safety supports in place. PELLERIN MILNOR CORPORATION...
  • Page 25 Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration, biological contamination, electrocution, and crushing. • Do not enter the cylinder until it has been thoroughly purged, flushed, drained, cooled, and immobilized. — End of BIUUUS14 — PELLERIN MILNOR CORPORATION...

  • Page 26: Proximity Safeguarding For Automatic Shuttle Conveyors

    ISO 10472-1 “Safety Requirements for Industrial Laundry Machinery” Hazards To Personnel in Proximity to Shuttle Conveyors 6.3. Milnor automated laundering systems use to transport goods among automatic shuttle conveyors the processing machines in the system. Depending on model, an automatic shuttle conveyor may move in any of the following ways, in addition to running its conveyor belt(s): •...

  • Page 27: How Milnor Accommodates Proximity Safeguarding

    (which occasionally change) and with the plant layout. For this reason, Milnor does not provide detailed designs or materials for proximity safeguarding. If the necessary expertise does not exist within the owner/user's organization, consult appropriate sources such as local engineers or architects specializing in industrial facility design.

  • Page 28: Manuals

    Traversing and elevating shuttle conveyor for loose goods Bank of dryers Fence enclosing paths of both shuttles and both centrifugal extractors Gates interlocked with both shuttles and both centrifugal extractors. Fence segment between tunnels. Fence segments between dryers. PELLERIN MILNOR CORPORATION...

  • Page 29: Fence Dimensions

    3. Shuttle(s), press(es), and/or centrifugal extractor(s) cannot be restarted merely by closing the gate(s), but must be restarted at the machine control panel once the gate(s) are closed. Milnor shuttles, presses and centrifugal extractors provide such functionality when properly interfaced with gate interlock switches.

  • Page 30: Wiring Safety Fence Gate Interlocks On Milnor

    Shuttles, Presses and Centrifugal Extractors This document is to be used in conjunction with Milnor document W6SYSSG “Micro 6 Systems Schematic: Customer-Provided Safety Fence Gate Interlock”. You will find this schematic document in the circuit guide for your machine. Together, these documents describe how to connect a customer-provided gate switch or series of switches to any Milnor shuttle, press, or centrifugal extractor.

  • Page 31: Testing

    Wiring Safety Fence Gate Interlocks on Milnor ® Shuttles, Presses and Centrifugal Extractors Testing 7.3. Once wiring is completed, it is vital to test the system to ensure that: 1. all gate interlocks function properly, and 2. all components that were part of the machine's three-wire circuit before the gate interlocks were added continue to function properly.
