Once the vehicle shuts off your system is in reservation mode and the vehicle is ready to safely remote
start.
IMPORTANT: By default, the system will lock/arm the vehicle upon setting reservation mode. Take care
to not lock your keys inside the vehicle.
Cancelling Reservation Mode
Reservation mode will be cancelled for the following reasons;
You did not activate the parking brake prior to turning off the ignition.
You pressed the foot brake after the key was removed from the ignition.
You released the parking brake after the key was removed from the ignition.
You entered valet mode, opened the vehicle's door, hood, trunk or set off the alarm.
Reservation Mode Settings
Reservation mode settings can be programmed with Option 1-6. It is recommended that reservation
mode settings are programmed by your local authorized Firstech dealer.
Default 1: Locks doors when Reservation Mode is set.
Option 2: Hold Key/Start button to initiate Reservation Mode
Option 3: Reservation mode sets 10 seconds after the last door is closed, as opposed to immediately.
This option will allow you to access the vehicle's rear doors, trunk or hatch prior to the system setting
reservation and passively locking/arming.
Option 4: Shuts motor off before locking doors.
Trunk Release
Hold button
for 2.5 seconds to release the trunk or hatch. If you are in range, the
remote will beep twice and the LEDs will flash indicating that the trunk release command has
been successfully transmitted. IMPORTANT: Trunk release is an optional vehicle feature that may
require additional parts and labor.
Auxiliary Outputs/Window Roll-Down/Sliding Doors
Your system is equipped with two additional outputs that can be configured to control windows, open
power sliding doors, open a power sliding moon roof, or even turn on a rear defroster. These outputs can
be configured for pulsed, timed or latched settings. Your authorized Firstech dealer can set these outputs
up accordingly. Using auxiliary outputs to control additional vehicle functions will require additional parts
and can be rather labor extensive.
Tap the Function <insert icon> button for a half second followed by the Trunk button
trigger auxiliary output 1. Tap the Function <insert icon> button for a half second followed by
the Key/Start <insert icon> button to trigger auxiliary output 2. The remote will beep once and parking
lights flash, indicating that the auxiliary output(s) have been triggered.
By default, the system is in secure auxiliary mode, which requires you to tap the Key/Start button
for a half second prior to triggering auxiliary 1 or 2. To turn off secure auxiliary, ask your authorized
Firstech dealer to turn on Option 4-5 to setting II
.
Silent Arm/Disarm
Upon lock/arm and unlock/disarm, you can eliminate vehicle's audible confirmation by muting
the siren. Normally, the siren will chirp once to indicate the system is locked/armed and twice to
indicate the system is unlocked/disarmed. To mute the siren tap buttons
10
