DIMENSIONS – OIL BOILERS
®
EUTECTIC EC-10
FRONT
Left End
BACK
1 1-1/4 threaded supply
2 Tapping 1/4"
3 Relief valve 3/4"
4 Flue outlet øD
5 1-1/4 threaded return tapping
6 1/2" drain outlet
SLANT/FIN CORPORATION, Greenvale, NY 11548 • Phone: (516) 484-2600
FAX: (516) 484-5921 • In Canada: Slant/Fin LTD/LTEE, Mississauga, Ontario
www.slantfin.com
©Slant/Fin Corp. 2007
