Demo Description

The demos that are available in the various PROM devices on the board are described
below. All of the code for these demos are loaded into PROM at the factory. The
configuration setting from the factory is for the Hello World Demo. The PROM files for
these demos can be found on the following Spartan-3E Web page link:
http://www.xilinx.com/sp3e1600e
SP3E1600E_HelloWorld Demo
This is a simple demonstration that exercises a few of the board features. The demo will
flash the LEDs and read the DIP and pushbutton switches. Messages will be displayed on
the 2x16 LCD display and, if a serial terminal window is open, diagnostic information will
appear in the terminal window. This application is loaded into the Platform Flash PROM.
Web Server Demo
This is a demonstration of a Web server running on the MicroBlaze soft processor. Refer to
the Web Server Reference System Chapter for details and instructions on how to run the
Web server demo. The Web server application is loaded into the SPI Serial Flash PROM.
µClinux Demo
This is a demonstration of µClinux running on the MiroBlaze™ soft processor. Refer to the
µClinux Reference System Chapter for details and instructions on how to run the Web
server demo. The µClinux image is loaded into the Intel StrataFlash PROM.
Address Map for SPI and BPI Flash PROMs
Table 1-1
device and
PROM device.
Table 1-1: StrataFlash PROM Address Map
8
shows the address map for each of the PROM files in the StrataFlash PROM
Table 1-2 shows the address map for the PROM file in the SPI Serial Flash
PROM File
µClinux Design (Bit file)
Unused
µClinux Kernel Image
Unused
Web Server Software Application
Unused
Web Server Memory File System
Unused
Getting Started with the MicroBlaze Development Kit - Spartan3E 1600E Edition
www.xilinx.com
Start Address End Address
0x00000000 0x000B62E3
0x000B62E4 0x002FFFFF
0x00300000 0x008E98A7
0x008E98A8 0x009FFFFF
0x00A00000 0x00A89031
0x00A89032 0x00AFFFFF
0x00B00000 0x00B4DEE3
0x00B4DEE4 0x00FFFFFF
R
Total
Space
746KB
2399KB
6199KB
1140KB
561KB
487KB
319KB
4923KB
UG258 (v1.0) June 29, 2006
