Volvo 740 1991 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Volvo 1991 740 Model
This manual deals with the operation and care of your Volvo.
Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe
driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure
your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment
descriptions, operating instructions and maintenance requirements/recommendations in this manual. We
also urge you and your passengers to wear seat belts at all times in this (or any other) automobile. And,
of course, please do not operate a vehicle if you may be affected by alcohol, medication or any
impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the
certification labels attached to the driver's door opening and on the left wheel housing in the engine
compartment. For further information please contact your dealer.
Contents
file:///K|/ownersdocs/1991/1991_740/91740_00.htm (1 of 2)12/30/2006 8:57:53 AM
740 Owner's Manual
VOLVO
740
1 9 9 1

Advertisement

loading

Related Manuals for Volvo 740 1991

Summary of Contents for Volvo 740 1991

  • Page 1 This manual deals with the operation and care of your Volvo. Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.

  • Page 2: Table Of Contents

    All information, illustrations and specifications contained in this manual are based on the latest product information available at the time of publication. Volvo reserves the right to make model changes at any time, or to change specifications or design, without notice and without incurring obligation.
  • Page 3 Volvo 1991 740 Model Instruments, switches and controls Instruments, switches and controls pg. 1:1 Instruments, switches and controls pg. 1:11 1 Air louver pg. 1:6 2 Headlights, parking lights pg. 1:6pg. 1:10 3 Turn signals, Cruise Control (accessory) pg. 1:6 4 Hazard warning flashers pg.

  • Page 4: Instruments And Controls

    Volvo 1991 740 Model pg. 1:16 13 Parking brake pg. 1:15, 2:7 14 Power door mirrors, electrically operated windows pg. 2:15 15 Hood release handle pg. 1:8 16 Rear fog lights 17 Space for additional equipment pg. 1:8 18 Instrument panel lamps rheostat and clock reset knobs pg.
  • Page 5 Volvo 1991 740 Model 2 Quartz crystal clock 3 Trip odometer reset knob 4 Speedometer NOTE: Canadian model speedometers/odometers indicate kilometers only. 5 Odometer 6 Trip odometer Used for measuring shorter distances. The last digit indicates 1/10 mile/kilometer. A black number on a white background = original speedometer.
  • Page 6 Volvo 1991 740 Model The pointer should be approximately midway on the gauge face when driving. If the pointer approaches the red range repeatedly, check coolant level and fan belt tension. Do not drive the car with the pointer in the red range. See sections "Coolant" and "Drive belts".
  • Page 7 See the section titled "Engine oil". If the light stays on after restart, have the car towed to the nearest authorized Volvo dealer. After hard driving, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.
  • Page 8 If the fluid level is above the MIN mark, or is below the MIN mark in only one of the two parts of the reservoir, drive with caution to an authorized Volvo dealer for inspection of the system. pg. 1:5 Warning lights, Indicator lights Service reminder indicator This light will come on at 5,000 mile (8,000 km) intervals.
  • Page 9 (Manual transmission cars only) The Volvo shift indicator light (S.I.L.) is a device designed to help you get even better gas mileage from your Volvo car. Studies have shown that the best fuel economy is obtained by shifting gears at low engine rpm and high relative engine load.
  • Page 10 Volvo 1991 740 Model Bulb failure warning light The light will come on if any of the following bulbs are defective: one of the low beam headlights one of the tail lights one of the brake lights when the brake pedal is depressed.
  • Page 11 Volvo 1991 740 Model pg. 1:6 Lighting, Turn signals, Hazard warning flasher Headlights and parking lights All lights off * Parking lights ON. With the headlight switch in this position, the parking lights will stay ON. Headlights and parking lights are ON, if starting (ignition) switch is in position I or II. If the headlight switch is in this position, all lights will go out when the starting (ignition), switch is turned OFF.
  • Page 12 Volvo 1991 740 Model Hazard warning flasher The four-way flasher should be used to indicate that the vehicle has become a traffic hazard. NOTE: Regulations regarding the use of the hazard warning flasher may vary from state to state. pg. 1:7 Wiper/washer, Starting switch...
  • Page 13 Volvo 1991 740 Model Wipers/washer 1 Intermittent wiper. With switch in this position, the wipers will sweep approximately every seventh second. 2 "Single sweep" position. Switch returns automatically when released 3 Wipers, low speed. 4 Wipers, high speed 5 Windshield wiper/washer The wiper will make 2-3 complete sweeps after lever is released.
  • Page 14 Volvo 1991 740 Model III Starting position: release the key when the engine starts. The key returns automatically to driving position. pg. 1:8 Rear fog light, Panel lighting, Clock, Power antenna Rear fog light The rear foglight is considerably brighter than the normal tail lights and should be used only when the atmospheric conditions, such as fog, rain, snow, smoke or dust reduce the daytime or nighttime visibility of other vehicles to less than 500 ft (150 meters).
  • Page 15 Volvo 1991 740 Model Move control upward - brighter Move control downward - dimmer Setting clock > Forward < Backward The hands of the clock will move faster if the button remains depressed. Power antenna The power antenna switch can be used to retract the antenna when the audio system is turned on. This will permit operation of the cassette drive with the antenna in the down position.
  • Page 16 Volvo 1991 740 Model Tailgate window wiper/washer (wagon) The tailgate window wiper/washer is operated by a switch at the end of the wiper lever. 1. The wiper operates continuously. 2. Intermittent position: the wiper strokes approximately every 10 seconds. 3. Tailgate washer.
  • Page 17 Volvo 1991 740 Model Operating brake pedal or clutch pedal (where applicable) This will automatically disengage the cruise control. Previously selected cruise control speed is retained in the memory and by momentarily setting the switch to RESUME position that speed will be re- engaged.
  • Page 18 If your car is equipped with air conditioning, system contains a CFC-12, a type of Freon. CFC-12 is a gas which affects the ozone layer of the earth's atmosphere. Let your Volvo dealer check your air conditioning system regularly for leakage.
  • Page 19 Volvo 1991 740 Model Air louvers (dash) A Open B Closed C Directing air flow horizontally D Directing air flow vertically A certain amount of air will always enter through the dash air louvers as long as they are open, independently of the position of the air distribution control.
  • Page 20 Volvo 1991 740 Model Air in the passenger compartment recirculates with this button depressed. Will not function in defrost setting. Light is on when function is engaged. The air conditioning system is disengaged when this button is depressed . The light is on when the air conditioning system is disengaged.
  • Page 21 Volvo 1991 740 Model Maximum cooling: Open the vents. The A/C button should not be depressed. Adjust the temperature with the temperature dial. To demist or defrost the windows Set the function dial to position . When the windows have cleared set the fan control to position 2.
  • Page 22 Volvo 1991 740 Model The air conditioning system will function best if it is used regularly. Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_03.htm (5 of 5)12/30/2006 8:57:54 AM...
  • Page 23 Volvo 1991 740 Model pg. 1:14 Heated front seats Heated front seats The front seats are equipped with electrically-heated backrests and seat cushions. The heating is thermostatically-controlled and cuts out automatically. Use the switches to disengage the seat heating manually when the seat is not occupied.
  • Page 24 Volvo 1991 740 Model Electrically-operated windows The electrically operated windows are controlled by switches from the driver's armrest as shown in the above illustration. The starting (ignition) switches must be ON (position II) for the electrically operated windows to function. The window is lowered if the rear part of the switch is pressed and raised if the front part of the switch is pressed.
  • Page 25 Volvo 1991 740 Model Cut-out switch for electrically-operated rear-door windows If the car is equipped with rear door windows, this function can be disabled by a switch located on the driver's door armrest. This switch is positioned 90° in relation to the other switches.
  • Page 26 Volvo 1991 740 Model Parking brake (hand brake) The lever is situated between the front seats. The brake is applied to the rear wheels. In order to obtain the best possible performance of the parking brake, see section titled "Brake System".
  • Page 27 Volvo 1991 740 Model Cigarette lighter To operate, depress the knob fully. When the knob automatically releases, the cigarette lighter is ready for use. The starting (ignition) switch must be switched on (position I or II) for the cigarette lighter to function.
  • Page 28 Volvo 1991 740 Model Ash trays To remove the ash trays depress the center spring and remove. Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_04.htm (6 of 6)12/30/2006 8:57:55 AM...
  • Page 29 Volvo 1991 740 Model pg. 1:17 Audio system, general description The following pages describe the use of your CR-814 cassette radio On/off (turn) Volume (turn) Balance left/right (push-turn) Fader front/rear (pull-turn) 2. Bass control 3. Treble control 4. Waveband selector 5.
  • Page 30 Volvo 1991 740 Model The radio features anti-theft circuitry. If the set is removed from the vehicle or if the battery power is disconnected, a special code must be entered to enable operation of the set. Ask your dealer for the correct code .
  • Page 31 Volvo 1991 740 Model If an incorrect code has been entered "EEE" is displayed for 1 second and then "codE". Enter the correct code. After three unsuccessful coding attempts the set locks for 2 hours. The unit must be connected and turned on during this time.
  • Page 32 Volvo 1991 740 Model Waveband selector The desired waveband is set by pressing the button. The frequency and waveband is shown on the display. NOTE! There are two FM wavebands and one AM waveband. This makes it possible to store more FM stations in the memory.
  • Page 33 Volvo 1991 740 Model Press the left side of the button to tune down and the right side to tune up. Release the button when the desired frequency is displayed. pg. 1:20 Radio (cont.) Automatic programming (autostore) This function works on the FM and AM wavebands and has 8 memories in autostore mode on each waveband.
  • Page 34 Volvo 1991 740 Model Preset buttons To select a pre-programmed radio frequency, depress the preset button. The preset button number and frequency will be displayed. Preset programming 1. Tune in to desired frequency. file:///K|/ownersdocs/1991/1991_740/91740_05.htm (6 of 19)12/30/2006 8:57:55 AM...
  • Page 35 Volvo 1991 740 Model 2. Depress and hold a preset button. The audio cuts out. Keep the button depressed until the audio comes on (approx. 2 sec.). 3. The frequency is now stored on this preset button. pg. 1:21 Radio (cont.) Display The display shows the selected waveband, preset number, frequency and ST (stereo).
  • Page 36 Volvo 1991 740 Model Balance control Push in the knob and turn it to the left or right to adjust left/right speaker balance. Fader control Pull out the knob and turn it to the left or right to adjust front/rear speaker balance.
  • Page 37 Volvo 1991 740 Model Bass control Adjust the bass by pulling out the button and turning it to the left or right. Depress the button after adjustment. Treble control Adjust the treble by pulling out the button and turning it to the left or right. Depress the button after...
  • Page 38 Volvo 1991 740 Model adjustment. pg. 1:23 Cassette deck Cassette slot The cassette is inserted with the roll of tape to the right-hand side. When the cassette is inserted, the radio is automatically disengaged. Push the cassette gently into place. The cassette will start to play automatically.
  • Page 39 Volvo 1991 740 Model Reversing the tape Depress both buttons to play the other side of the tape. The arrows in the display indicate the direction of the tape. Fast winding Press either of these buttons (see arrows for direction) for fast winding. Depress fully to lock the button.
  • Page 40 Volvo 1991 740 Model Press opposite button to stop fast winding. pg. 1:24 Cassette deck (cont.) Chrome/metal tape selector Depress the "CR"selector before playing a chrome or metal tape. "CR" will be displayed. This function should not be engaged for standard tapes.
  • Page 41 Volvo 1991 740 Model DOLBY selector This set has a DOLBY B noise reduction system. Depress the DOLBY selector when playing a DOLBY pre-recorded tape. DOLBY will be displayed. This function should not be engaged for non-DOLBY tapes. Cassette eject If the button is pressed the tape will stop and the cassette will be ejected.
  • Page 42 Volvo 1991 740 Model Sending signals The U(FM) waves do not follow the earth's surface nor do they bounce off the atmosphere. For this reason their range is limited. The M, L (AM) waves follow the earth's surface and reflect against the atmosphere.
  • Page 43 Volvo 1991 740 Model distortion can result. Distortion The reason why U(FM) but not M/L (AM) is audible is covered parking areas, under bridges, etc., is that U(FM) signals reflect against solid objects such as buildings. Because these waves are very reflective, static can result.
  • Page 44 Volvo 1991 740 Model Cross modulation If you listen to a weak station in the vicinity of a stronger one, both stations may be received simultaneously. U-(FM) - reasons for distortion U(FM) is affected by the electrical systems of nearby vehicles, especially those without suppression.
  • Page 45 Reception conditions are not always optimum and this is, of course, beyond our control. However, we have endeavored to make the Volvo Audio System of a quality that will enable you to enjoy the best possible reception no matter what the reception conditions may be.
  • Page 46 Take up slack using a pen or pencil before inserting cassette in cassette slot. Cleaning cassette We recommend the use of Volvo Cleaning Cassette available as a genuine Volvo accessory. Regular use improves sound quality, cleans vital parts and prevent tape tangle.
  • Page 47 Volvo 1991 740 Model Electronic suppression device Frequency range: CR - 718 FM (U) 87.9 - 107.9 MHz AM(M) 530 - 1700 kHz Sensitivity: U (FM) 1.5µV M (AM) 6.5 µV L 35µV Cassette deck 4-track, 2-channel stereo DOLBY and CrO2 selector Tape speed: 4.76 cm/sec.

  • Page 48: Body And Interior

    Volvo 1991 740 Model Body and interior pg. 2:1 Body and interior The seats, doors, etc. are described on the following pages. pg. 2:2 Keys pg. 2:3 Doors and locks pg. 2:4 Child safety locks, Trunk lid (sedans) pg. 2:5 Tailgate/Child safety lock (wagons) pg.
  • Page 49 The back of the tag is coated with adhesive tape. In the event of the original keys are lost, duplicates may be ordered from your Volvo dealer. The central locking system is described in detail in section Doors and locks.
  • Page 50 Volvo 1991 740 Model pg. 2:3 Doors and locks Door locks The vehicle is equipped with a central locking system. This means the lock on the driver's door controls the locks on the other doors (including the trunk or tailgate) automatically.
  • Page 51 Volvo 1991 740 Model To avoid battery drain The interior light and the warning lights in the rear of the doors come on when a door is opened. To avoid battery drain when the doors are opened for prolonged periods, these lights can be switched off by pushing in and turning the door light switches slightly clockwise.
  • Page 52 Volvo 1991 740 Model Trunk lid The trunk lock is incorporated in the central locking system. This means that you can either lock or unlock the trunk by means of driver's door lock. You can also operate the trunk lock directly with the master key even if the vehicle is centrally locked.
  • Page 53 Volvo 1991 740 Model Opening the tailgate Tailgate To unlock - turn the key clockwise and allow it to spring back. To lock - turn the key counter-clockwise and allow it to spring back. NOTE: If the vehicle has a central locking system the tailgate will be unlocked and locked at the same time as the driver's door.
  • Page 54 Volvo 1991 740 Model Opening from the inside To open the tailgate from the inside of the vehicle move the lever to the left and push outwards. WARNING! Do not drive with trunk lid or tailgate open! Poisonous exhaust gases may enter via the open trunk lid or tailgate...
  • Page 55 Volvo 1991 740 Model Location and setting of child safety lock Child Safety lock The tailgate incorporates a safety catch which is located to the side of the lock. A the tailgate functions normally B the tailgate cannot be opened from the inside.
  • Page 56 Volvo 1991 740 Model pg. 2:6 Front seats Height adjustment The front section of the driver's seat can be adjusted to three height positions and the rear section to four. Lever forward = front height adjustment Lever rearward = rear height adjustment Do not adjust the seat while driving.
  • Page 57 Volvo 1991 740 Model Rotate control clockwise to tilt seat back rearward. Rotate counterclockwise to tilt seat back forward. Note that body weight must be shifted to allow seat back to move forward or rearward. pg. 2:7 Rear/side-view mirrors Rear-view mirror...
  • Page 58 Volvo 1991 740 Model Use the lever to adjust. WARNING! The mirrors should always be adjusted prior to driving. Objects seen in the wide-angle right side-view mirror are closer than they appear to Switch for electrically-operated mirrors Electrically-operated side-view mirrors (Optional) The control switches are located in the driver's door armrest.
  • Page 59 Volvo 1991 740 Model Interior light 1 Light always on. 2 Light always off 3 Light is on when either of the front or rear doors are opened. Crank-operated sun roof Sun roof (Optional) The sun roof can be used in two ways: as a conventional sliding roof, or the rear edge can be raised or lowered to provide various ventilation positions.
  • Page 60 Volvo 1991 740 Model WARNING! For added safety, always have the crank folded during driving. Electrically-operated sun roof (Optional) To open the sun roof as a sliding roof, depress the top portion of the rocker switch. To raise the rear edge of the sun roof, depress the bottom portion of the switch.
  • Page 61 Volvo 1991 740 Model WARNING! Packages on the rear window shelf can obscure vision and may become dangerous projectiles in the event of a sudden stop or an accident. pg. 2:10 Trunk, Long load storage (sedan) file:///K|/ownersdocs/1991/1991_740/91740_07.htm (6 of 8)12/30/2006 8:57:57 AM...
  • Page 62 Volvo 1991 740 Model Trunk light A Light always off. B Light is on when trunk lid is opened. Long load storage In the panel behind the rear seat is a door which makes it possible to carry long loads such as skis, etc.
  • Page 63 Volvo 1991 740 Model WARNING! Always turn engine off and apply parking br file:///K|/ownersdocs/1991/1991_740/91740_07.htm (8 of 8)12/30/2006 8:57:57 AM...

  • Page 64: Occupant Safety, Reporting Safety Defects

    Despite our strongest recommendations, and your best intentions, not wearing a seat belt is like believing "It'll never happen to me!". Volvo urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
  • Page 65 Volvo 1991 740 Model Seat belts Always fasten the seat belts before you drive or ride. Two lights above the rear view mirror will be illuminated for 4-8 seconds after the starting (ignition) key is turned to the driving position. One light is located in the instrument panel and one in the console between the front seats.
  • Page 66 Volvo 1991 740 Model Before exiting the car, check that the seat belt retracts fully after being unbuckled. If necessary, guide the belt back into the retractor slot. WARNING! Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
  • Page 67 Volvo 1991 740 Model Center-rear belt adjustment (wagon) The center-rear seat belt is manually adjustable. It should always be adjusted to fit snugly across the lap. To unfasten Depress red pushbutton in receptacle (buckle) and let the belts rewind into their retractors.
  • Page 68 As the seat belts lose much of their strength when exposed to violent stretching, they should be replaced after any collision, even though they may appear to be undamaged. Never repair the belt on your own; have this done by an authorized Volvo dealer only. pg. 3:4 Volvo SRS...
  • Page 69 The system is designed to supplement the protection provided by the three-point seat belt system. The interior of an SRS-equipped Volvo looks very much the same as any other. The only indications of the system's presence are the "SRS" embossed on the steering wheel pad, and the knee bolster beneath the steering column.
  • Page 70 When installing any optional equipment make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo Dealer for inspection as soon as possible.
  • Page 71 WARNING! If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo Dealer for inspection as soon as possible. ATTENTION! SRS VEHICLE! THIS CAR IS EQUIPPED WITH A SUPPLEMENTAL RESTRAINT SYSTEM.
  • Page 72 3:6 Child safety Child safety Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car. Restraint systems for children are designed to be secured in the vehicle by lap belts or the lap portion of a lap-shoulder belt.
  • Page 73 A misused child restraint system can result in increased injuries for both the infant or child and other occupants in the vehicle. If your child restraint requires a top tether strap, consult your authorized Volvo dealer for top tether anchorage and installation information.

  • Page 74: Starting And Driving

    Volvo 1991 740 Model Starting and driving pg. 4:1 Starting and driving Starting and driving This section on starting and driving contains items such as starting the engine, operating gear selector, towing, trailers. pg. 4:2 Fuel requirements, Refueling pg. 4:3 Driving economy, Carbon deposits pg.
  • Page 75 4:2 Fuel requirements, Refueling Unleaded Fuel Each Volvo has a three-way catalytic converter and must use only unleaded gasoline. U.S. and Canadian file:///K|/ownersdocs/1991/1991_740/91740_09.htm (2 of 14)12/30/2006 8:57:58 AM...
  • Page 76 To meet seasonal air quality restrictions, some states require the use of "oxygenated" fuel in certain areas. Volvo allows the use of the following "oxygenated fuels"; however, the octane ratings listed on this page must still be met.
  • Page 77 Volvo 1991 740 Model When filling, position the cap in the special bracket on the door. After filling the tank, install the cap and turn until a "click" is heard. The fuel tank is designed to hold approximately 21 US gals (80 liters) sedan, and 15.8 US gal (60 liters) wagon, with sufficient volume left over to accommodate possible expansion of the fuel in hot weather.
  • Page 78 Deposit control gasoline Volvo recommends the use of gasoline containing deposit control additives. These additives have shown to be efficient in keeping injectors and intake valves clean. Consistent use of deposit control gasolines will help ensure good driveability and fuel economy. If you are not sure whether the gasoline contains deposit control additives, check with the service station operator.
  • Page 79 Volvo 1991 740 Model 2 Apply the parking brake, if not already set. 3 Depress the brake pedal firmly. 4 Place the gear selector lever in park (position P) on cars with automatic transmission). 5 Without touching the accelerator pedal, turn the ignition key to the starting position. Release the key as soon as the engine starts.
  • Page 80 Volvo 1991 740 Model Starting and stopping a car equipped with automatic transmission 1 Fasten the seat belt. WARNING! Before starting, check that the seat is adjusted properly. Make sure the brake/- clutch pedal can be depressed completely. Move the seat closer if necessary.
  • Page 81 Volvo 1991 740 Model WARNING! Always place gear selector securely in Park, and apply parking brake before leaving vehicle. Never leave car unattended with engine running. pg. 4:6 Automatic transmission (cont.) Gear selector positions P park R reverse N neutral...
  • Page 82 Volvo 1991 740 Model The transmission is mechanically locked when in position P. Also, apply the parking brake when parking on grades. The gear selector is locked in the Park position - SHIFT-LOCK. To release the selector, the ignition must be switched on and the brake pedal must be depressed. Manually releasing see page 6:18.
  • Page 83 Volvo 1991 740 Model pg. 4:7 Automatic transmission (cont.) 2 (intermediate position) Upshifts and downshifts of first two gears (low and intermediate) occur automatically. No upshift to 3rd or 4th gear occurs. Position 2 may be used to obtain forced downshift to 2nd gear for increased engine braking effect.
  • Page 84 Volvo 1991 740 Model Fully depressing the selector knob thus permits shifting freely between all positions. pg. 4:8 Automatic transmission (cont.) 4th gear disengagement: The 4th gear is engaged automatically after the transmission has shifted through 1st, 2nd and 3rd gears at certain speeds and loads.
  • Page 85 Volvo 1991 740 Model WARNING! Never select P or R while the car is in motion. When initially selecting positions D, 3, 2, 1, or R, your foot should press firmly on the brake pedal to ensure that the car is standing still with the engine idling.
  • Page 86 Volvo 1991 740 Model Depress the clutch fully when shifting gears, and when engaging/disengaging overdrive (5th gear). Remove foot from the clutch pedal after shifting. Overdrive (5th gear) The overdrive can be engaged in 4th gear only. The overdrive is engaged/disengaged by depressing the switch on top of the gear shift lever.
  • Page 87 Volvo 1991 740 Model Lift before selecting reverse Reverse gear The detent collar on the gear lever must be lifted prior to engaging reverse gear. This prevents unintentional selection of the gear. Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_09.htm (14 of 14)12/30/2006 8:57:58 AM...
  • Page 88 Do not use bias ply tires as this will adversely alter vehicle handling characteristics. WARNING! An extra non-Volvo mat on the driver's floor can cause the accelerator pedal to catch. Check that the movement of the accelerator pedal is not impeded.
  • Page 89 Roof racks (removable and permanent) Roof rails are available as Volvo accessories. Observe the following points when is use: Avoid single-point loads. Distribute the load evenly. Place heavier cargo at bottom of load.
  • Page 90 Volvo 1991 740 Model repeatedly into, or stays continually in, the red section) the following precautions should be taken: Switch off the air conditioning system. Stop the car and put the gear lever into neutral (position N). Do not stop the engine! Increase the engine speed to approx.
  • Page 91 Volvo 1991 740 Model WARNING! The Supplemental Restraint System is grounded under the driver's seat. Do not loosen the two screws grounding the unit. Do not ground other electrical components using these screws or any other points near them. Faults in the system could occur if it is improperly grounded.
  • Page 92 Volvo 1991 740 Model instructions. Maximum speed: 20 mph (30 km/h). Maximum distance with rear wheels on ground: 20 miles (30 km). NOTE: Cars equipped with automatic transmission/catalytic converters cannot be started by pushing or pulling the car. CAUTION: The towing eyelets must not be used for pulling another vehicle out of a ditch or any similar purpose involving severe strain.
  • Page 93 Volvo 1991 740 Model pg. 4:14 Jump starting CAUTION: Improper hook-up of jumper cables or use of other than 12-volt batteries could result in damage to equipment and/or battery. Check that cars are not touching to prevent premature completion of negative circuit. Note the position of the battery terminals and using jumper cables: First connect booster battery positive (+) terminal (1) to car battery positive (+) terminal (2).
  • Page 94 This gives protection against freezing down to -31°F (-35°C). See section "Coolant". The use of "recycled" antifreeze is not approved by Volvo. Try to keep the fuel tank well filled - this prevents the formation of condensation in the tank.
  • Page 95 Use a trailer hitch which meets Federal Safety Standards for rear end collisions (FMVSS 301-75) For trailer weights exceeding 2000 lbs. (908 kg), use only a trailer hitch offered as a Genuine Volvo Accessory. Since the automatic transmission is subject to increased load and temperature, certain vehicles are equipped with an extra oil cooler as standard equipment.
  • Page 96 WARNING! Never connect a trailer's hydraulic brake system directly to the vehicle brake system, nor a trailer's lighting system directly to the vehicle lighting system. Consult your nearest authorized Volvo dealer for correct installation. WARNING! Bumper-attached trailer hitches must not be used on Volvos, nor should safety chains be attached to the bumper.
  • Page 97 If the fluid level is below the MIN mark in either section of the reservoir: Do Not Drive. Tow the car to a Volvo dealer and have the brake system checked and any leakage repaired. If the fluid level is below the MIN mark in half of the reservoir: Drive carefully to a garage and have the brake system checked.
  • Page 98 Before a long distance trip It is always worthwhile to have your car checked at a Volvo dealer before driving long distances. Your dealer will also be able to supply you with bulbs, fuses, spark plugs and wiper blades for your use in the event that problems occur.
  • Page 99 Check all lights, including high beams. Reflective warning triangles are legal requirement in some countries. Have a word with your Volvo dealer concerning engine adjustments if you intend to drive in countries where it may be difficult to obtain correct fuel.
  • Page 100 Volvo 1991 740 Model Catalytic converter cautions Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three-way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating conditions, such as engine overheating or backfiring.
  • Page 101 Volvo 1991 740 Model NOTE: Unleaded fuel is required for cars with three-way catalytic converters. A label on the instrument panel and inside fuel tank filler door will remind owners and filling station attendants of this requirement. Important! It is unlawful to dispense leaded fuel into any vehicle labeled "unleaded gasoline only".

  • Page 102: Wheels And Tires

    Volvo 1991 740 Model Wheels and tires pg. 5:1 Wheels and tires Wheels and tires The handling and riding comfort of the vehicle is dependent on the inflation pressure and the type of tires fitted. Read the following pages carefully.
  • Page 103 Volvo 1991 740 Model When replacing tires, be sure that the new tires are the same size designation, type (radial) and preferably from the same manufacturer, on all four wheels. Otherwise there is a risk of altering the car's road-holding and handling characteristics.
  • Page 104 Suitable tire size: 185/65 TR (motor B230F, on all four wheels) or 195/60 HR (Turbo, on all four wheels). No rims from other Volvo models can be used on the 740. Do not mix tires of different design, as this could negatively affect overall tire road grip especially...
  • Page 105 Volvo 1991 740 Model The tires on your Volvo will perform to specifications at all normal loads when inflated as recommended on the tire information label located on the rear facing side on the right front door. This label lists both the tire and vehicle design limits.
  • Page 106 Volvo 1991 740 Model Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_11.htm (5 of 5)12/30/2006 8:58:00 AM...

  • Page 107: In Case Of Emergency

    Volvo 1991 740 Model In case of emergency pg. 6:1 In case of an emergency In case of emergency Even if you maintain your car in good running condition, there is always the possibility that something might go wrong and prevent you from driving, such as a punctured tire, blown fuse or bulb..
  • Page 108 Recommended tire pressures (see decal) should be maintained irrespective of which position on the car the Special Spare tire is used on. In the event of damage to this tire a new one can be purchased from your Volvo dealer. pg. 6:3 Wheel changing...
  • Page 109 Volvo 1991 740 Model Removal of wheel cap on aluminum wheel. Changing a wheel The spare wheel is located in the trunk, beneath the carpet (sedans), or beneath the rear cargo-area floor (wagons). Before using the jack, make sure the car is standing on firm, level ground. Apply the parking brake. On models with automatic transmission place the transmission selector lever in position P.
  • Page 110 Volvo 1991 740 Model ground with wooden blocks or large stones. Remove the wheel cap. With the car still on the ground, use the box wrench from the tool kit to loosen the wheel nuts 1/2 - 1 turn. Turn the nuts counterclockwise to loosen.
  • Page 111 Volvo 1991 740 Model attachment . Now raise the vehicle until the wheel is free of the ground. Unscrew the wheel nuts completely and carefully remove the wheel so as not to damage the tread of the studs. WARNING! The jack's hook engage the bar in the jack attachment (A). The car's weight must not rest on the jack's attachment (B).
  • Page 112 Volvo 1991 740 Model pg. 6:5 Replacing bulbs NOTE! The method for replacement of bulbs in the various lighting units is shown on the following pages. Make sure when installing bulbs, that the guide pin on the socket fits into its corresponding recess.
  • Page 113 Volvo 1991 740 Model Headlamps 1 Pull the connector out. 2 Loosen the ring by turning it counterclockwise. 3 Pull the bulb straight out. 4 Replace the bulb and reinstall the unit in the reverse order. Bulb Power US Bulb No.
  • Page 114 Volvo 1991 740 Model Replacing tail lights bulbs (sedan models) All tail lamp bulbs are replaced from inside of trunk. To avoid confusion, replace the bulbs one at a time. 1 Unscrew and remove tail lamp inside cover. Note that inside cover is hooked at the lower edge.
  • Page 115 Volvo 1991 740 Model All tail light bulbs are replaced from inside the vehicle Light Wattage Socket Fog light * 21W 32CP BA15s Back-up lights 21W 32CP BA15s Turn signals 21W 32CP BA15s Brake light and tail light 21/5W 32/3CP BAY15d White lamp holders on the right side, black holders on the left side.
  • Page 116 Volvo 1991 740 Model Check that the bulb lights Re-install cluster cover pg. 6:9 Replacing bulbs Trunk light (sedan models) Courtesy light (wagon models) Depress the catch with a screwdriver and remove the light assembly. Lift it out to remove.
  • Page 117 Volvo 1991 740 Model License plate light (sedan models) Open the trunk and insert a screwdriver in the opening in the lock frame. Depress the locking spring on the lamp assembly until it releases. Turn the bulb holder 1/4 turn counter-clockwise. Replace the bulb and check that the new bulb lights.
  • Page 118 Volvo 1991 740 Model Use phillips head screwdriver License plate light (wagon models) Remove the screws with a screwdriver. Remove lamp housing. Depress the bulb and rotate it counter-clockwise. Remove the bulb. Install a new bulb and re-install light housing.
  • Page 119 Volvo 1991 740 Model Depress catch with screwdriver High-level brake lights To remove: Turn off ignition. Depress catch with a screwdriver. Grasp the cover and pull it towards you. Bulb Power Socket High level brake light 21W 32cp Ba 15s (US bulb no.
  • Page 120 Volvo 1991 740 Model Removing cover (wagons) To remove: Turn off ignition. Grasp the cover with both hands and pull it towards you. pg. 6:11 Replacing bulbs (cont.) Depress catches Depress catches and fit new bulb. To fit: file:///K|/ownersdocs/1991/1991_740/91740_13.htm (9 of 11)12/30/2006 8:58:01 AM...
  • Page 121 Volvo 1991 740 Model Fit the reflector and check that the light works. Sedan models Press the cover into position, noting the position of the alignment pin at the top. Wagon models Align the catches and press the cover into position.
  • Page 122 Volvo 1991 740 Model Door warning lamps All doors are equipped with red warning lamps. To replace a bulb, insert a screwdriver as shown in picture and gently turn it to remove the lens. Withdraw the bulb, replace it and re-insert the lens Bulb Power Socket Door warning lamp 3W W2.1x9.5d...
  • Page 123 Volvo 1991 740 Model pg. 6:12 Fuses Fuse replacement A blown fuse is indicated by the failure of all the units protected by it, and it is caused by overloading the circuits. The fuses (and relays) are located in the central electrical unit behind the ashtray in the center console.
  • Page 124 Volvo 1991 740 Model It is necessary to remove the fuses to see if they are blown, see next page for information on fuses and related circuits. If you find it difficult to obtain access to the fuses, unclip the fuse tool on the right-hand side of the fuse compartment and use it to remove the fuse, see illustration.
  • Page 125 Volvo 1991 740 Model The fuses are removed by pulling them straight out. If they are defective, the metal wire is broken. When fitting a new fuse, be certain to use one with the same amperage and color as the one removed (see top of fuse)! Spare fuses are located on each side of the fusebox (1x15A, 1x25A, 1x30A).
  • Page 126 25 Rear fog light/lights 15 26 Radio 15 For more detailed information concerning function and location of relays, fuses, etc., refer to the Volvo Service Manuals. These can be purchased directly using the Service Literature Brochure/Order Form or through your Volvo dealer.
  • Page 127 Volvo 1991 740 Model Install new blade, installation is the reverse of removal and make sure that it is properly attached to the wiper arm. For reasons of safety, you should change the windshield wiper blades as soon as they start to leave marks on the windshield or fail to wipe efficiently and cleanly.
  • Page 128 Volvo 1991 740 Model Poor contact in the electrical system Check all leads to spark plugs, coil, distributor, battery and starter motor. No fuel reaching engine Check that there is fuel in the tank. Check that none of the hoses in the fuel system are loose.
  • Page 129 Volvo 1991 740 Model Level of oil in power-assisted steering pump too low Check and fill oil, see section "Power steering fluid". Engine overheats Radiator hose cracked or leaking Check and replace if necessary Insufficient coolant Check and fill coolant, see section "Cooling system".
  • Page 130 Volvo 1991 740 Model Manually releasing the gear selector (shiftlock release) If the car's electrical system is not functioning, the gear selector must be released manually. The catch is located under the brushes in the gear shift cover (see illustration). Push the catch gently forward. Select a gear.

  • Page 131: Car Care

    Volvo 1991 740 Model Car care pg. 7:1 Car care Car care includes not only maintaining the appearance of the car, but also protecting the car exterior from the effects of air pollution, rain and mud. The rustproofing compound under the car should be checked regularly and, if necessary, damaged areas should be repaired.
  • Page 132 Rustproofing, inspection and touching-up Your Volvo was carefully and thoroughly rustproofed at the factory. The underbody and wheelhousings were sprayed with a thick, durable rustproofing compound and the beams, internal cavities and end sections were sprayed with a low viscous, penetrating rustproofing agent.
  • Page 133 Volvo 1991 740 Model The visible (external) rustproofing must be inspected by an authorized Volvo dealer at least once a year. If it is necessary to touch-up the rustproofing, this should be done immediately to prevent moisture penetration. Wash and dry thoroughly before touching up. Use spray-on or brush-on rustproofing compounds.
  • Page 134 Minor scratches can be repaired by using Volvo touch-up paint. NOTE: When ordering touch-up paint from your Volvo dealer, use the paint code indicated on the model plate. The plate is located on the panel above the right-side head lights.
  • Page 135 Volvo 1991 740 Model Remove loose flakes of paint with masking tape 2 Thoroughly mix the primer and apply it with a small brush. When the primer surface is dry, the paint can be applied using a brush. Mix the paint thoroughly: apply several thin paint coats and let dry after each application.
  • Page 136 Volvo 1991 740 Model 3 If there is a longer scratch, you may want to protect surrounding paint by masking it off. Touching up damaged paint on fender edges and sills Material: Primer - spray Paint - spray Masking tape NOTE: When touching up the car, it should be well cleaned and dry and have a temperature exceeding 60°F...
  • Page 137 Volvo 1991 740 Model WARNING! Spray painting should be done in a well ventilated and dust-free area. When the primer has dried, apply the surface enamel in the same way. Spray on several times and allow the paint to dry a minute or so between each application.
  • Page 138 Volvo 1991 740 Model After washing the engine, the spark plug wells should be blown dry. A stiff-bristle brush and lukewarm soapy water can be used to clean the wiper blades. Frequent cleaning improves visibility considerably. NOTE: It is particularly important to wash the car frequently in the wintertime to prevent corrosion, when salt has been used on the roads.
  • Page 139 Volvo 1991 740 Model NOTE: When washing the car, remember to remove dirt from the drain holes in the doors and sills. pg. 7:7 Automatic car washing, Polishing and waxing, Chromed parts Automatic washing - simple and quick An automatic wash is a simple and quick way to clean your car. Keeping the underbody clean is most important, especially in the winter.
  • Page 140 7:8 Cleaning the upholstery Cleaning the upholstery Volvo recommends the use of Volvo approving cleaning products which are available at your authorized Volvo dealer. The fabric can be cleaned with soapy water or a detergent. For more difficult spots caused by oil, ice cream, shoe polish, grease, etc.., use a clothing/clothing fabric stain remover.
  • Page 141 Volvo 1991 740 Model Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_15.htm (11 of 11)12/30/2006 8:58:02 AM...
  • Page 142 Volvo 1991 740 Model Volvo service pg. 8:1 Volvo Service Service - an investment! An investment which will pay dividends in the form of improved reliability, durability, and resale value. pg. 8:2 Maintenance schedule pg. 8:4 Maintenance service pg. 8:5 Engine compartment pg.
  • Page 143 Volvo 1991 740 Model Maintenance Operation 0.6-1.2 thousand miles (1.0- (16) (25) (32) (40) (48) (56) (64) (72) (80) (88) (96) (thousand km) 2.0) EMISSION SYSTEM MAINTENANCE Engine oil and filter Engine drive belts tension Valve clearance Air cleaner filter...
  • Page 144 Volvo 1991 740 Model 0.6- Maintenance Operation thousand miles (1.0 - (16) (24) (32) (thousand km) (40) (48) (56) (64) (72) (80) (88) (96) 2.0) MISCELLANEOUS MAINTENANCE ENGINE Engine coolant Fuel (Line) Filter PCV Nipple (Orifice)/hoses, clean EGR valve, clean...
  • Page 145 Volvo 1991 740 Model BODY Trunk, hood hinges and latches 1) For services beyond the 60,000 miles (96,000 km), consult your "Maintenance records manual" "Maintenance Service Chart". ___________________________________________________________________________ The following items should be checked weekly by the driver (it takes only a few minutes):...

  • Page 146: Specifications

    Your Volvo has passed two major inspections before being delivered to you, according to Volvo specifications. After being driven 600-1,200 miles (1,000-2,000 km), your car should be brought to the Volvo dealer for a service inspection. Engine, manual transmission and rear axle oils will be changed at this time.
  • Page 147 Limited 5-year/50,000-mile Emission System Warranty (USA) 5-year/80,000-kilometer Emission System Warranty (Canada) Do not export your Volvo to another country before investigating the country's applicable safety and exhaust emission requirements. In some cases it may be difficult or impossible to comply with these requirements.
  • Page 148 Volvo 1991 740 Model When filling gas always check: Fuel: Recommended 91 (R+M)/2, 95 RON (unleaded). Minimum octane requirement 91 RON (unleaded) 87 (R+M/2). Canada: Unleaded regular 6 Check, without removing the cap, that the brake fluid level is above the MIN-mark. Brake fluid DOT 4 Oil level should be between the dipstick marks.
  • Page 149 Volvo 1991 740 Model freeze). Important! Change engine oil and oil filter at 5,000 mile (8,000 km) intervals. pg. 8:6 Engine compartment (cont.) 740 B 230 F- Turbo engine 1 Washer fluid reservoir 2 Expansion tank, coolant 3 Oil filler cap, engine...
  • Page 150 Volvo 1991 740 Model Canada: Unleaded regular 6 Check, without removing the cap, that the brake fluid level is above the MIN-mark. Brake fluid DOT 4 Oil level should be between the dipstick marks. The distance between the marks represents approx. 1 US qt.=1 liter.
  • Page 151 Volvo 1991 740 Model pg. 8:7 Engine oil Checking the oil level The oil level must be checked at least every 5,000 km (3,000 miles) or more frequently if needed. Be sure the oil level is maintained between the upper and lower marks on the dip-stick. Low oil level can cause internal damage to the engine and over-filling can result in high oil consumption.
  • Page 152 Volvo 1991 740 Model It is illegal to pollute drains, water courses and soil. Use authorized waste collection facilities, including approved recycling centers and garages providing facilities for disposal of used oil and used oil filters. If in doubt, contact your local authority for advice on disposal.
  • Page 153 Synthetic or semisynthetic oils may be used if their specifications comply with the oil quality requirements. Volvo does not recommend additional oil additives, as they can adversely affect the engine. Changing oil and oil filter Oil and oil filter are first changed at the 600-1,200 mile (1,000-2,000 km) service. Thereafter, changes should be made as specified by this table: file:///K|/ownersdocs/1991/1991_740/91740_18.htm (3 of 11)12/30/2006 8:58:05 AM...
  • Page 154 Volvo 1991 740 Model If driving conditions include: Then the correct oil/oil filter change interval is: Extended periods of idling and/or low-speed operation Frequent short trips (less than 7 miles = 11 km) EVERY 5,000 miles= 8,000 km OR EVERY 3...
  • Page 155 Check hoses and connections on distributor vacuum unit, connections on heater control servo systems and hydraulic brake servo. Checking and adjusting idle speed Your Volvo is equipped with an electronically-controlled idle speed system that requires no checking or adjustment. Fuel system cap, tank and lines, and connections The effectiveness of the fuel system to contain hydrocarbons is dependent largely on a leakfree system.
  • Page 156 Volvo 1991 740 Model recommend that the timing gear belt be replaced every 50,000 miles (80,000 km). pg. 8:10 Servicing (cont.) 1 Battery 2 Injection control unit 3 Ignition control unit 4 Fuel filter 5 Fuel pump 6 Fuel feed pump...
  • Page 157 Volvo 1991 740 Model Lambda-sond (oxygen sensor) system This is an emission control system designed to reduce emissions and improve fuel economy. The heated oxygen sensor monitors the composition of the exhaust gases leaving the engine. The exhaust gas analysis is fed into an electronic control module. This adjusts the air-fuel ratio to provide optimum conditions for combustion and efficient reduction of the three major pollutants (hydrocarbons, carbon monoxide and nitrous gases) by a 3-way catalytic converter.
  • Page 158 Volvo 1991 740 Model Intercooler The B230F-Turbo engine employs a turbocompressor to force air into the engine inlet manifold and a charge air cooler to cool the compressed inlet air. The resulting increase in air flow raises pressure in the intake manifold by approx.
  • Page 159 Volvo 1991 740 Model Evaporative control system The 740 is equipped with a gas-evaporative control system, which prevents gasoline fumes from being released into the atmosphere. The system is comprised of an expansion chamber in the fuel tank, and a charcoal canister with built-in vacuum valve under the left-front wheel housing.
  • Page 160 Volvo 1991 740 Model This system operates by returning some of the exhaust gases to the engine to be recombusted: since this lowers the combustion temperature the amount of nitrogen oxides released into the atmosphere is reduced. The EGR valve should be inspected at 60,000 miles (96,000 km) and thereafter cleaned every 20,000 miles (32,000 km).
  • Page 161 Batteries contain corrosive and toxic acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo dealer can assist you in this matter. Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_18.htm (11 of 11)12/30/2006 8:58:05 AM...
  • Page 162 15,000 miles (25,000 km) when driving under extremely hard conditions (mountain driving etc.) Check, without removing the cap, that the level is above the "MIN" mark of the fluid reservoir. Always entrust brake fluid changing to an authorized Volvo dealer. Power steering fluid The fluid level should lie between the MIN and MAX marks on the dipstick (cool engine).
  • Page 163 Volvo 1991 740 Model Fluid type: ATF type F Replace: No fluid change required. pg. 8:15 Automatic transmission Automatic transmission oil Capacity: See "Specifications" section Fluid type: Automatic Transmission Fluid type Dexron IID. Replace: Every 20,000 miles (32,000 km). Warning! Oil spilled on a hot exhaust pipe constitutes a fire risk.
  • Page 164 Volvo 1991 740 Model NOTE: The engine should be idling when checking transmission fluid level. Check the oil level as follows: Park the car on level surface with the engine idling. Slowly move the selector lever through all gear positions and then to position P. Wait 2 minutes before checking the oil level.
  • Page 165 Start the engine and run until hot. Check the cooling system connections for tightness. Also re-check the coolant level. Capacity: See "Specifications" Coolant: Volvo coolant type C (blue green) CAUTION! The cooling system must always be kept filled to correct level.
  • Page 166 3 Door stop and hinges Oil 4 Sun roof wind deflector Oil 5 Door lock catch plate Oil or low temperature grease 6 Trunk lid lock Volvo Teflon lock oil 7 Window regulator Oil, grease locking device silicone (on inside of door) grease...
  • Page 167 Volvo 1991 740 Model To avoid rattles and unnecessary wear, the body should be lubricated a few times per year. pg. 8:18 Drive belts Checking the belt tension The belt tension can be checked by depressing the fan belt (engine not running!) at a point midway between the generator and fan.
  • Page 168 Volvo 1991 740 Model The belts can be difficult to reach and it is advisable to let your Volvo dealer adjust the tension of the belts or replace them, if necessary. pg. 8:19 Washer nozzles, Washer fluid reservoir Adjusting washer nozzles The washer jets should spray the windshield as shown.
  • Page 169 Volvo 1991 740 Model Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_19.htm (8 of 8)12/30/2006 8:58:05 AM...
  • Page 170 Volvo 1991 740 Model Specifications pg. 9:1 Specifications Specifications pg. 9:2 Dimensions and weights pg. 9:3 Label information pg. 9:4 Oil specifications pg. 9:5 Engine specifications pg. 9:8 Electrical system specifications pg. 9:9 Capacities pg. 9:2 Specifications Dimensions and weights...
  • Page 171 WARNING! When adding accessories, equipment, luggage and other cargo to your vehicle, the total weight capacity of the vehicle must not be exceeded. Consult your Volvo dealer for information. All specifications are subject to change without notice. Gross Vehicle Weight...
  • Page 172 VIN plate is located on top left surface of dashboard. The VIN is also stamped on the right hand door pillar. 2 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emissions standards, as evidenced by the certification label on the left wheelhousing. For further information regarding these regulations, please consult your Volvo dealer.
  • Page 173 Oil with designation SG - CD, also comply with these demands. Synthetic or semi-synthetic oils may be used if their specifications comply with the above. Volvo recommends the use of fuel economy improving oils. Look for the API label. file:///K|/ownersdocs/1991/1991_740/91740_20.htm (4 of 6)12/30/2006 8:58:06 AM...
  • Page 174 Volvo 1991 740 Model Volvo does not recommend oil additives as they can adversely affect the engine. Capacity (including oil filter): 4.0 US qts. (3.85 liters);on Turbo models, add 0.7 US qts (0.6 liters) if oil cooler is drained. Capacity: (M46) 2.8 US qts (2.6...
  • Page 175 Volvo 1991 740 Model Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_20.htm (6 of 6)12/30/2006 8:58:06 AM...
  • Page 176 Volvo 1991 740 Model pg. 9:5 Engine specifications 740 B 230F Type designation Volvo B 234 F Output(SAE J 1349) 114 hp at 5400 rpm (85 kW at 90 rps) Max. torque(SAE J 1349) 136 ft. lbs. (184 Nm) at 2500 rpm Number of cylinders 4 Bore 3.78"...
  • Page 177 (GL) 189° F (87° C) (Turbo) 198° F (92° C) Fan belts, designation: (GL) HC47cog x 1013 (Turbo) HC47cog x 1000 Coolant: Volvo coolant type C (blue-green) Capacity: 10 US qts (9.5 liters) Ignition System Firing order 1-3-4-2 Ignition setting: (GL) 12°...
  • Page 178 Volvo 1991 740 Model POWER TRANSMISSION Manual or automatic transmission Hypoid type final drive Manual transmission M46 M47 Reduction ratios: 1st gear 4.03:1 4.03:1 2nd gear 2.16:1 2.16:1 3rd gear 1.37:1 1.37:1 4th gear 1:1 1:1 5th gear - 0.80:1 Overdrive 0.78:1 -...
  • Page 179 Volvo 1991 740 Model Rear axle ratio 3.73:1 3.54:1 3.31:1 1st gear 2nd gear 14.0 14.8 16.0 3rd gear 14.4 23.0 14.5 23.4 15.5 25.0 4th gear 19.4 31.0 19.9 32.1 21.3 35.0 Overdrive/5th 25.0 40.0 25.2 40.6 26.9 42.0...
  • Page 180 520 A/100 min California: 440A/85 min Electrolyte, specific gravity 1.28 Recharge at 1.23 Alternator, rated output 1120 W max. current 80 A The following bulbs may be obtained from your nearest Volvo dealer: US bulb Lights, 12 V Power Socket Headlights...
  • Page 181 Volvo 1991 740 Model Tail light/brake light * 1157 21/5W/32/3cp BA 15d High-mounted brake 21 W/32cp BA 15s light Back-up lights 1156 21 W/32cp BA 15s Rear fog light 1156 21 W/32cp BA 15s License plate light W 2.1 x 9.5 d...
  • Page 182 9:9 Specifications Vehicle Loading The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire information label. The label is located on the rear-facing edge of the right-front door. This label lists both tire and vehicle design limits. Do not load your car beyond the load limits indicated or maximum capacity of vehicle.
  • Page 183 Volvo 1991 740 Model Wheel nut wrench. 1 screwdriver with bits Pry bar 2 open end wrenches. Capacities Fuel tank (approx.) 15.8 US gal. 60 liters Cooling System 10 US qts. (9.5 liters) Engine 4.0 US qts. * at oil change 3.85 liters Manual transmission (M46) 2.8 US qts...
  • Page 184 All specifications are subject to change without notice. pg. 9:10 Service manuals Service Manuals for your Volvo are available for purchase. These are the same manuals used by competent Volvo technicians. Major sections within the Service Manual System include: 0-General Information; 1- Lubrication and Service;...
  • Page 185 Installation of accessories Incorrectly installed accessories, e.g. car telephones or modular telephones left in or used in close proximity to the car, can cause faultless in the car's electronic control systems. Consult your Volvo dealer before installing any such accessories.
  • Page 186 Volvo 1991 740 Model UNLEADED FUEL ONLY VOLVO Octane rating, see p. 4:2. Tire pressure, see label located on rear edge of right front door. US Bulb Bulbs Power Socket 45/65 9004 21/5 W 1157NA file:///K|/ownersdocs/1991/1991_740/91740_21.htm (11 of 12)12/30/2006 8:58:07 AM...
  • Page 187 Volvo 1991 740 Model BA 15s 21 W BA 15s 1156 21/5 W 1157 VOLVO Volvo Car Corporation Goteborg, Sweden TP 3135/2 (Canada & U.S.A.) 35000.11.90. Contents Top of Page file:///K|/ownersdocs/1991/1991_740/91740_21.htm (12 of 12)12/30/2006 8:58:07 AM...
