Jackson DELTA 115/1200 Operation Manual

MACHINE PREPARATION
Check Machine
Before operating the unit, verify the following:
• The strainers are clean and in place.
• The drain stopper is installed.
Wash Strainer Drain Stopper Rinse Strainer
PRE-SCRAPPING & WASHING
Pre-Scrapping
• Dump out any liquids or foodsoil left in the glasses.
CLEAN-UP
1. Turn the power switch to the "OFF" position.
2. Ensure glasses are removed from the carousel.
3. Remove and clean the wash strainer.
4. Remove and clean the drain stopper.
5. Remove the curtain, clean with a mild soap, and rinse.
DELIMING
1. Disconnect the detergent pump. 3. Add deliming solution per supplier's
2. Drain and refill the wash tank.
1.888.800.5672
WAREWASHING PROCEDURES
DELTA® 115/1200
Check Chemical Supplies
Check chemicals on or near the machine for adequate
supply of each product:
• Check detergent, rinse-aid, and sanitizer levels in
containers.
• Replace if empty and prime lines.
6. Remove and clean the drain boards.
7. Remove and clean the rack cylinder.
8. Hold paddle switch against wall of machine with one hand.
9. Remove carousel with other hand and clean the carousel.
10. Rotate top stop cap counter-clockwise until opening
aligns with the top rinse arm.
4. Run machine the period of time recommended by chemical supplier.
instructions.
5. Wait five minutes, then inspect the inside of the machine. If the machine is not delimed, run again.
Fill Machine
• Place the power switch in the "FILL" position.
• Machine will automatically fill.
Power Switch
• Turn the power switch to the "ON" position; the carousel
will begin to rotate.
• Place glasses on the carousel.
• When the glasses have completed the cycle, the paddle
switch will activate, turning off the water and carousel.
11. Remove the top rinse arm.
12. Rotate top stop cap counter-clockwise until opening
aligns with the top wash arm.
13. Remove the top wash arm.
14. Remove bottom stop cap.
Check Operating Temperatures
Verify temperatures:
Delta 115
• Wash Tank: 120 ° minimum.
Delta 1200
• Wash Tank: 130 ° minimum.
For the full Delta 115/1200 Manual, scan
the QR Code below or go to our website.
Washing Glasses
• Remove clean glasses which are against the paddle switch.
• The carousel will begin to rotate again.
15. Remove the bottom rinse arm.
16. Remove the bottom wash arm.
17. On all arms: remove end-caps, clean with a brush, and flush
with fresh water.
18. Remove and clean the separator and upper rinse strainer.
19. Remove and clean the rinse strainer.
20. When all components are clean, replace by performing
these steps in reverse order.
6. Run two cycles to remove residual deliming solution.
